Billy Goat KD510SP, TKD510SP Operator Owner's Manual

Billy Goat KD510SP, TKD510SP Operator Owner's Manual

The powerful kd or tkd termite self-propelled vacuum chipper
Hide thumbs
Table of Contents

Advertisement

Quick Links

OPTIONAL ACCESSORIES
2 2 2 2 2
SHREDDER KIT
P/N 890209.
Shreds
leaves, dramatically reducing
total volume.
HOSE KITS
For vacuuming in hard to
reach areas.
Heavy Duty Vacuum
Hose Kit P/N 900943.
4"
x 10'
(102mm)
(3.05m)
Homeowners Vacuum Hose
Kit P/N 900942.
4"
x 10'
(102mm)
(3.05m)
NOZZLE WEAR PLATES
P/N 890413.
Extends nozzle
life when used along curbs and
hard surfaces.
STANDARD TURF QUICK
DEBRIS BAG
P/N 890307.
Standard on TKD
models. For use in leaves and
grass in non-dusty conditions.
OPTIONAL DEBRIS BAGS
QUICK DEBRIS BAG
P/N 890305 for use in dusty
conditions.
DEBRIS BAG COVER
P/N 900801
Directs dust
downward away from operator.
ZIPPERLESS QUICK BAG
P/N 890309
For non dusty
conditions that are damaging
to zippers.
3 3 3 3 3
UNIT SIZE:
OVERALL LENGTH: 62"(1.57m) OVERALL WIDTH 26.75" (0.68m)
Part No. 890424
1 1 1 1 1
T h a n k Yo u f o r S e l e c t i n g
The Powerful KD or TKD TERMITE
SELF PROPELLED VACUUM CHIPPER
Operator Owner's Manual
KD510SP, TKD510SP

Specifications

ENGINE:H.P.
5.5 (4.1kW)
ENGINE:TYPE
B&S DIAMOND I/C
ENGINE:FUEL CAP.
1.5qt. (1.4L)
ENGINE:OIL CAP.
0.63qt. (0.6L)
WEIGHT:UNIT
117# (53.1 kg)
WEIGHT:SHIPPING
140# (63.5 kg)
ENGINE WEIGHT:
26# (11.8 kg)
Page 1 of 12
R
KD510SP
TKD510SP
5.5 (4.1kW)
B&S DIAMOND I/C
1.5qt. (1.4L)
0.63qt. (0.6L)
133# (60.3 kg)
156# (70.8 kg)
26# (11.8 kg)
OVERALL HEIGHT 42" (1.07m)
®
Form No. F011398A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KD510SP, TKD510SP and is the answer not in the manual?

Questions and answers

Related Manuals for Billy Goat KD510SP, TKD510SP

Summary of Contents for Billy Goat KD510SP, TKD510SP

  • Page 1: Specifications

    T h a n k Yo u f o r S e l e c t i n g The Powerful KD or TKD TERMITE SELF PROPELLED VACUUM CHIPPER Operator Owner's Manual KD510SP, TKD510SP Specifications KD510SP 5.5 (4.1kW) B&S DIAMOND I/C 1.5qt.

  • Page 2: Table Of Contents

    IN THE INTEREST OF SAFETY 5 5 5 5 5 BEFORE STARTING ENGINE, READ AND UNDERSTAND THE “ENTIRE OPERATOR'S MANUAL & EN- GINE MANUAL.” THIS SYMBOL MEANS WARNING OR CAUTION. DEATH, PERSONAL INJURY AND/OR PROPERTY DAMAGE MAY OCCUR UNLESS INSTRUCTIONS ARE FOLLOWED CAREFULLY. WARNING: to the State of California to cause cancer, birth defects or other reproductive harm.

  • Page 3: General Safety

    Read all safety and operating instructions before assembling or starting this unit. PUT OIL IN ENGINE BEFORE STARTING Your Billy Goat is shipped from the factory in one carton, completely assembled except for the upper handle, debris bag, and bag quick disconnect.

  • Page 4: Parts Bag & Controls

    Label Do Not Fill While Away Engine Is Hot Item 29 Part Item 63 Part No.400268 No.400424 Label Danger Chipper For Wood Only Item 48 Part No. 890152 (TKD MODELS ONLY) DANGER Label Ear Eye Breathing Label Danger Flying Material Item No.

  • Page 5: Operation

    (see fig 2.). When feeding forked branches, squeeze forks together and feed into chipper entrance (DO NOT overload). If forks are too large, use a pair of loppers to trim forks down to size. A lopper...
  • Page 6 OPERATION continued 16 16 16 16 Note: Dry wood is (fig. 2) harder to chip than green wood. MULCH 1 6 . 1 6 . 1 6 .9 9 9 9 9 1 6 . 1 6 . Wood chips made from branches in your own yard make excellent mulch.
  • Page 7 This can prevent any remaining wood from jamming in the chipper when machine is turned off. Do not leave tamper on the ground, store tamper in the chipper hopper. Tamper Storage Position PROPULSION 16.6...

  • Page 8: Maintenance

    If gap is more than 0.080"(2.03mm), remove one or more shim washers as needed to obtain correct gap (see fig. 6 & fig. 7). The chipper will function at up to a maximum of 0.125"(3.18mm) gap. Page 8 of 12 Chipper blade is sharp.

  • Page 9: Maintenance Schedule

    IMPELLER REMOVAL continued 17.1 18. If chipper blade properly clears anvil surface, proceed to step . If not, return to (step 14) and add or subtract shim washers as needed to obtain a correct gap. 19. Reinstall engine and impeller onto housing in reverse order of removal.

  • Page 10: Parts Drawing & List

    PARTS DRAWING 18 18 18 18 KD510SP, TKD510SP Part No. 890424 Form No. F011398A Page 10 of 12...
  • Page 11 Screw Self Tapping 10 - 24 x 1/2 Nozzle Frame (incl. one of items 29,44,42,55,64) Plug Label Oil Chain Blade Chipper Impeller Ass'y (incl items 46, 49, 50, 51, 59, 65, 66, 67) Impeller Ass'y (incl items 49, 50, 51) Label Chipper Key 3/16 Sq.

  • Page 12: Troubleshooting

    22 22 22 22 Please fill in the WARRANTY CARD and send the upper part to Billy Goat. The WARRANTY terms are stated on the lower part which remains with the user. Whenever a Billy Goat Machine is faulty due to a defect in material...
