AIRPLANE FLIGHT MANUAL
LBA Approved in Normal Category based on JAR-VLA.
This Airplane Flight Manual must be carried on board of the aircraft at all times and be kept
within the reach of the pilot during all flight operations. The amendment history and revision
status of each section of the Airplane Flight Manual are provided in the list of effective pages
and in the list of revisions.
This aircraft must be operated in compliance with the procedures and operating limits specified
herein.
SERIAL NO.:
REGIST. NO.:
Revision A.01 was approved by the Luftfahrt-Bundesamt (LBA) on 30/08/2002 within the scope
of the type-certification. All revisions of section 2, 3, 4 and 5 beyond the scope of documentary
changes are subject to EASA-approval.
Doc. No.
First Issued:
Cover Page Issue No.:
Aviation by Excellence AG
AQUILA AT01
AQUILA AT01-
FM-AT01-1010-100E
05/06/2002
A.18
