Aquila AT01 Manual

Mvp fuel pressure limit adaptation
Hide thumbs Also See for AT01:

Advertisement

Quick Links

Download this manual
MVP Fuel Pressure limit adaptation
This instruction explains how to adjust the Fuel Pressure-Limit.
The instruction is divided into steps and additionally illustrated with pictures.
1.) General requirements
a.) Send the Unit ID and Software level to Aquila.
b.) You will receive a Level 2 PW from Aquila.
This password is only valid for one day and one device.
2.) Guidance
Step 1.) Power on the Master-Switch and Start the MVP-50P.
Step 2.) After the MVP-50P has powered up, press the "Menu" -Button.

Advertisement

loading
Need help?

Need help?

Do you have a question about the AT01 and is the answer not in the manual?

Questions and answers

Related Manuals for Aquila AT01

Summary of Contents for Aquila AT01

  • Page 1 The instruction is divided into steps and additionally illustrated with pictures. 1.) General requirements a.) Send the Unit ID and Software level to Aquila. b.) You will receive a Level 2 PW from Aquila. This password is only valid for one day and one device.
  • Page 2 Step 3.) After pressing the "Menu" button, you will see the "Flight Data Screen" menu. Turn the left knob clockwise until the arrow points to "CLOCK AND HOUR METERS".
  • Page 3 Step 4.) Press the left button twice to set the date which has been announced by us (corresponding to level 2 password). Step 5.) If you have the correct date Entered, press the "EXIT" button. This will return you to the "Flight Data Screen" menu.
  • Page 4 Step 6.) Turn the left knob clockwise until the arrow points to "SYSTEM CONFIGURATION SCREENS MENU”. Step 7.) Press the left knob. Then a window will appear to enter the Level 1 password. Please enter here the level 2 password, by turning and pressing the left knob. The Level 2 password you received from us.
  • Page 5 Step 8.) Now the "System Configuration Screens Menu" appears. Turn the left knob clockwise until the arrow points to "Redlines, Limits and Color Setup" Step 9.) Press the left knob, so that the “Redlines, Limits and Color Setup" menu appears.
  • Page 6 Step 10.) Turn the left knob so that the arrow points to "Function". Press the left knob until the scripture right, has a yellow background. Step 11.) Turn the left knob so that "FUEL P" has a yellow background. Right next to it must appear "FUEL P"...
  • Page 7 Step 12.) Press the “EXIT” knob twice. The arrow should point again "Function". Step 13.) Turn the left knob so that the arrow points to "Operating Range" Press the left knob to change the settings. After that, by pressing and turning the left knob, you have to set the new END for the Operating Range .
  • Page 8 Step 17.) Press the "EXIT" button again, and you will be guided back to the "Flight Data Screens Menu". Step 18.) Turn the left knob counter-clockwise until the arrow points to "CLOCK AND HOUR METERS".
  • Page 9 Step 19.) Press the left button twice to set the correct date of today. Step 20.) If you have the correct date Entered, press the "EXIT" button.
  • Page 10 This will return you to the "Flight Data Screen" menu. Step 21.) Press the “EXIT” button until the Main screen is displayed.
