PC2300 Operations Manual
SPECIFICATIONS AND DIMENSIONS
PC2315A SPECIFICATION
System
I/O Ports
Storage Space
Expansion
Display
Touch Screen
Electrical
Mechanical
Environmental
Operating System
Notes
PC2300 Operations Manual
CPU
System Chipset
System Memory
USB
Serial
LPT
Audio
Digital I/O
VGA
LAN
Power
HDD/SSD
CFast Card Slot
Expansion Slot
Wi-Fi
Display Type
Max. Resolution
Max. Color
Luminance (cd/m²)
View Angle (H°/V°)
Contrast Ratio
Backlight Lifetime (hours)
Type
Interface
Light Transmission
Input Voltage
Input Power
Construction
Rating
Mounting
Dimension
Net Weight
Operating Temperature
Storage Temperature
Storage Humidity
Certification
Type
* Refer to the product price list to select one of the required input power options
** 32-bit or 64-bit must be specified at the time the order is placed.
Base Model: Intel® Core™ Mobile i3-3120ME processor
Upgrade Options: Intel® Core™ Mobile i5-3610ME or i7-3610QE
processor
Intel QM77
Base Model: 4 GB DDR3L SO-DIMM
Upgrade Options: 8 GB or 16 GB DDR3L SO-DIMM
4 x USB 3.0 type A
3 x DE9P COM1/3/4: RS-232
1 x DE9P COM2: RS-422
1x DB25S parallel port
1 x 3.5 mm line out
1 x 3.5 mm mic in
1 x DB25S, 8 in/8 out
1 x DE15S video output
2 x RJ-45 GbE
1 x DIN4 connector, DC power input
Base Model HDD: 1 x 2.5" SATA 3, 500 GB
HDD Upgrade Options: 1 x 2.5" SATA 3, 1 TB
SSD Upgrade Options: 1 x 2.5" SATA 3, MLC, 64 GB, 128 GB, 256 GB
Yes
Optional 1 x PCI or PCIe (10W max)
Optional
15" TFT-LCD
1024 x 768
16.7M
400
160/160
600:1
50,000 hours
5-wire resistive touch
USB
80% ±5%
9~36 VDC (Power supply or power cable not included*)
39
W (Base model)
Aluminum front bezel and chassis
IP65 front panel / NEMA4X
Panel mounting, VESA 100 x 100
16.06 x 12.13 x 5.05 inches [408 x 308 x 128 mm]
16.53 lbs. [7.5 kg]
32~113°F [0~45°C]
-4~158°F [-20~60°C]
10 to 90%
CE / FCC Class A / RoHS
Microsoft Windows© 7 Pro for Embedded 32-bit or 64-bit (FES 7
Pro)**
7
___ 7
