Page 1: User Manual
USER MANUAL MNPG53-02 Edition 10/05/2011 Magnetotherapy model MAG2000 PLUS I.A.C.E.R. Srl www.iacer.it www.itechmedicaldivision.com... - Page 2 I.A.C.E.R. Srl Via S. Pertini 24/A – 30030 Martellago (VE) ITALY Tel. +39 041 5401356 – Fax +39 041 5402684 e-mail: iacer@iacer.it - http://www.itechmedicaldivision.com...
-
Page 3: Table Of Contents
Summary Summary Introduction Magnetotherapy Technical specifications Manufacturer Declaration of Conformity Specifications Purpose Technical features Labeling Label details Symbols description Kit contents How to use Warnings Electromagnetic interference Contraindications and side effects Quick use of the device with presetted parameters Therapeutic belt and solenoids couple positioning Adjustable programs instructions MAG2000 PLUS free memories use Stored programs list... -
Page 4: Introduction
Introduction Magnetotherapy It’s a long time that low frequency and high intensity pulsed electromagnetic fields have met maximum scientific consent in chronic and degenerative diseases treatment. Magnetotherapy uses low frequency and high intensity pulsed electromagnetic fields induced by electric current on a bobbin; characteristics, electromagnetotherapy universally recognized as the most suitable technique for the... -
Page 5: Technical Specifications
Tel. +39 0415401356 • Fax +39 0415402684 www.iacer.it • iacer@iacer.it IACER S.r.l. is an Italian medical devices manufacturer (CE medical certificate n° MED24021 issued by Cermet notified b ody n° 0476). Declaration of Conformity IACER S.r.l., headquartered in Italy, via S. Pertini 24/A 30030... -
Page 6: Specifications
Specifications MAG 2000 PLUS has the following specifications: • Class IIa equipment (Directive 93/42/CEE, Annexed IX, rule 9 and following modifications); • Class II applied part type BF (Classif. CEI EN 60601-1); • Equipment not protected against liquid penetration; • Equipment and accessories not subjected to sterilization;... -
Page 7: Technical Features
MAG2000 PLUS is particularly suitable for the treatment and the care of the osteoporosis and all the pathologies on bony tissue, for dermatologic applications (varicose ulcers, phlebitis ulcers, arteropatic ulcers, acne, burn sore, not healed wounds, cellulite, skin illnesses: in these cases we recommend a low treatment intensity, lower than 40). -
Page 8: Labeling
Environmental conditions of operation temperature from+5 to + 40 ° C rel. humidity from 30 to 80% pressure from 500 to 1060 hPa Labeling Label 2 Label 3 Label 4 Label 1 (back) Label details Label 1 I.A.C.E.R. Srl MNPG53-02... -
Page 9: Symbols Description
N° 1 user and maintenance manual; • N° 1 elastic therapeutic belt with 3 solenoids; • N° 1 professional solenoids couple; • N° 1 carriage bag Magnetotherapy carpet is available as accessory on demand. Visit website www.iacer.it to obtain more information. I.A.C.E.R. Srl MNPG53-02... -
Page 10: How To Use
How to use Warnings Please read carefully the user manual before using MAG2000 PLUS. We recommend to visit magnetotherapy section on website www.iacer.it order to obtain other information. Take care of what follows: • Take care of position and meaning of the labels on MAG2000 PLUS;... -
Page 11: Electromagnetic Interference
• The electric plant of the environment in which MAG2000 PLUS is inserted it is conforming to the national laws. • The instrument is employed in conformity to the instructions contained in this manual. Electromagnetic interference The device doesn’t produce and doesn’t receive interferences from other equipments. - Page 12 6. Press OK. Screen will display base setting with therapy time (2 hours) and magnetic field intensity (50 int.). These mean values are recommended by IACER in order to start immediately the treatment. 7. Press button highlighting magnet icon on left down position;...
-
Page 13: Therapeutic Belt And Solenoids Couple Positioning
9. At the end of therapy the screen will display automatically the menu programs. Attention: it’s possible to stop temporary the therapy at any time by pressing OK key at least for 2 seconds. Press again OK key to continue the treatment. - Page 14 Cervical Elbow Shoulder Wrist Knee Ankle Tibia/fibula Femur head Femur Shoulder Vertebral column Lumbar I.A.C.E.R. Srl MNPG53-02...
-
Page 15: Adjustable Programs Instructions
Suggestions for a correct use: • In P1-P20 programs a longed treatment with an intensity higher than 60 can warm the 3 solenoids belt and this aspect makes therapy less comfortable: we recommend to space out treatments and to not go over 2 consecutive hours of therapy; •... - Page 16 6. Press OK. Screen will display base setting with therapy time (2 hours) and magnetic field intensity (50 int.). These parameters can be modified as follows: a) Press OK button: screen displays a moving key icon on the left side; b) Press keys to adjust the desired therapy hours (from 0 to 24) and confirm by pressing OK key.
- Page 17 c) Press keys to adjust the desired therapy minutes (from 0 to 59) and confirm by pressing OK key. Screen will highlight treatment intensity; d) Press keys to adjust the treatment intensity (from 5 to 100 Gauss on P1-P20 programs, from 5 to 150 Gauss on P21-P35 programs) and confirm by pressing OK key;...
-
Page 18: Mag2000 Plus Free Memories Use
the treatment. During pause time green led turns off till the treatment restarts. Attention: it’s possible to get out from the treatment at any time by pressing once key, screen will display the base setting (step 6). By pressing key again screen will display programs menu (step 5). Attention: MAG2000 PLUS recognizes applicators correct connection. - Page 19 6. Press OK. Screen will display base setting with therapy time (2 hours) and magnetic field intensity (50 int.). These parameters can be modified as follows: a) Press OK button: screen displays a moving key icon on the left side; b) Press keys to adjust the desired therapy hours (from 0 to 24) and confirm by pressing OK key.
- Page 20 c) Press keys to adjust the desired therapy minutes (from 0 to 59) and confirm by pressing OK key. Screen will highlight treatment intensity; d) Press keys to adjust the treatment intensity (from 0 to 200) and confirm by pressing OK key; 7.
- Page 21 9. At the end of therapy screen will display automatically the menu program. Attention: it’s possible to stop temporary the therapy at any time pressing OK key at least for 2 seconds. Press again OK key to continue the treatment. During pause time green led turns off till the treatment restarts.
-
Page 22: Stored Programs List
Stored programs list Pre-adjusted values Recommended values N° Pathology Time Treatment Treatment cycles interval hours Osteoporosis 2 - 6 24 hours Arthrosis 2 - 6 24 hours Arthritis 2 - 6 24 hours Headache 2 - 6 24 hours Neuralgias 2 - 6 24 hours Cervicalgias... -
Page 23: Set Up (Language Selection)
Treat. 15 Hz free free 24 hours Treat. 20 Hz free free 24 hours Treat. 30 Hz free free 24 hours Treat. 40 Hz free free 24 hours Treat. 50 Hz free free 24 hours Treat. 60 Hz free free 24 hours Treat. -
Page 24: Maintenance
Maintenance Functioning control Mag2000 PLUS equipment offers a magnet in order to control the device functioning. Control procedure: 1. switch on the device in according to user manual safety prescriptions; 2. start a treatment in according to user manual instructions; 3. -
Page 25: Carriage And Storage
Carriage and storage Carriage precautions MAG2000 PLUS is a portable device, so it does not need any particular carriage precautions. However we recommend to put away MAG2000 PLUS and its accessories in their own bag after every treatment. We recommend to not roll up power supply and applicators cables. Storage precautions MAG 2000 PLUS is protected till following environmental conditions: Outside of the packaging... -
Page 26: Assistance
Via S. Pertini, 24/a • 30030 Martellago (VE) - ITALY Tel. +39 0415401356 • Fax +39 0415402684 www.iacer.it • iacer@iacer.it Assistance Every intervention on device must be performed by manufacturer. For any assistance intervention contact the National Distributor or the manufacturer at the following address: I.A.C.E.R. -
Page 27: Spare Parts
Warranty Make reference to the national laws for any warranty conditions by contacting the national distributor (or directly the manufacturer IACER). MAG2000 PLUS. All rights reserved. MAG2000 PLUS and logos are owned by I.A.C.E.R Srl and are registered.
