Summary of Contents for IACER I-TECH T-ONE COACH

  • Page 1 USER MANUAL Electrotherapy model T-ONE COACH...
  • Page 3 Index INDEX TECHNICAL INFORMATION ANUFACTURER ECLARATION OF CONFORMITY LASSIFICATION URPOSE AND SCOPE ECHNICAL CHARACTERISTICS EVICE AND COMMANDS DESCRIPTION ABELS Packaging content HOW TO USE ONTRAINDICATIONS ARNING EVICE USE Main menu and single/multi patient selection Preliminary settings Single patient pre-set programs Tips on how to adjust the intensity IST AND CHARACTERISTICS OF THE PROGRAMS AVAILABLE IN SINGLE PATIENT MODE TENS Programs...
  • Page 4 ARRANTY Support Spare part LECTROMAGNETIC INTERFERENCES AND ELECTROMAGNETIC COMPATIBILITY TABLES...

  • Page 5: Declaration Of Conformity

    I.A.C.E.R. S.r.l. Via S. Pertini, 24/a • 30030 Martellago (VE) Tel. 041.5401356 • Fax 041.5402684 IACER S.r.l. is an Italian manufacturer of medical devices (certified CE no. 0068/QCO-DM/234-2020 from the Notified Body n° 0068 MTIC InterCert S.r.l.). Declaration of conformity I.A.C.E.R.

  • Page 6: Purpose And Scope

    Technical characteristics Characteristics Specifica Power supply Batteries Ni-MH, 4.8V, 2300mAh Model AKN1G-0680030VW Recharger Input AC 100-240V, 50-60Hz, 0.2A Output DC 6.8V 0.3A Isolation class (EN 60601-1) Applied part (EN 60601-1) Dimensions (length x depth x 153x91x38 mm IACER Srl MNPG239-03...
  • Page 7 Expected useful life of the device is set in 3 years, meanwhile the expected useful life of the electrodes is set in 10/15 uses. Device and commands description 1. Front panel 2. Colour graphic display 3. Keypad Start and return to program selection menu button OK, end of program key IACER Srl MNPG239-03...
  • Page 8 Increase intensity on channel 3 (red) Decrease intensity on channel 3 (red) Increase intensity on channel 4 (white) Decrease intensity on channel 4 (white) 4. Charging port 5. Battery compartment 6. Channel ports (1-4) Labels Symbol Description Manufacturer’s logo. IACER Srl MNPG239-03...
  • Page 9 1 battery pack (inside the device); n°1 battery charger; n° 4 cables for electro-stimulation; n° 1 sets of 4 square pre-gelled electrodes; n° 1 set of 4 rectangular pre-gelled electrodes; n° 1 set of 8 round electrodes; IACER Srl MNPG239-03...
  • Page 10 1 bag for the transportation; n° 1 user manual; n° 1 user manual of the electrodes’ positions. IACER Srl MNPG239-03...
  • Page 11 (e.g. a black electrode on the chest and a red electrode on the shoulder blade); to position the electrodes on or close to skin injuries or cuts; • • to position the electrodes on the carotid sinuses (carotid) or genitals; IACER Srl MNPG239-03...

  • Page 12: Device Use

    (chosen from a list of 10 programs) on channels 1-2 and 3- Main menu and single/multi patient selection Start the device from key , open the menu and use the selection keys to choose between SINGLE PATIENT, MULTI PATIENT AND LAST 10 PROGRAMS modes. IACER Srl MNPG239-03...

  • Page 13: Intensity Adjustment

    , and then select the desired program using the selection keys ; confirm the selection by pressing 2. INTENSITY ADJUSTMENT Use the coloured CH1/CH2/CH3/CH4 up arrow keys to increase the current intensity on the 4 channels. The value changes by 1mA IACER Srl MNPG239-03...
  • Page 14 Some programs allow you to select the muscular area to be treated (upper limbs, trunk, lower limbs) and they also come with special MALE/ FEMALE modes. After choosing the program, the display will show a screen similar to the following: IACER Srl MNPG239-03...
  • Page 15 This setting is indicated by the icon in the lower right corner of the screen, as shown below: Icon represents a contraction, while icon represents a recovery. See the following chapters for more details on program features, specifications and settings available. IACER Srl MNPG239-03...
  • Page 16 T-ONE. This voluntary contraction shall be carried out with the limb locked (technically in isometry), in other words, without moving the limb. BEAUTY: the indications are similar to those given for NEMS programs. IACER Srl MNPG239-03...
  • Page 17 Total time30min Frequency Frequency 90Hz Backache/Sciatica Pulse Pulse width 60µs width 150µs Total time 30min (6s 100Hz–175µs + 6s 2-100Hz Sprains / Bruises modulated–250µs + 6s 150Hz–60- 200µs modulated) Total time 20min Vascularisation Frequency 2Hz Pulse width 200µs IACER Srl MNPG239-03...
  • Page 18 200µs modulated) Total time 10min (7s 3Hz– Total time 30min 200µs + 3s Periarthritis Frequency 90Hz 1Hz– Pulse width 50µs 200µs + 5s 30Hz– 200µs) Total time 30min Frequency 2Hz Tens Burst Pulse width 80µs Burst impulses IACER Srl MNPG239-03...
  • Page 19 This type of stimulation produces two types of effects according to how the electrodes are positioned: positioning the electrodes in the dorsal region, see photo 10 in the Positions Manual, promotes the endogenous production of morphine-like substances capable of raising the pain perception threshold; positioning the IACER Srl MNPG239-03...
  • Page 20 TENS 5 • Neck pain (medical program) Special program for neck pain relief. The first benefits can be seen after 10 to 15 treatments carried out on a daily basis; continue the treatment until the symptoms disappear. Session duration: 40 minutes. IACER Srl MNPG239-03...
  • Page 21 Has a vascularizing effect on the treated area. Vascularization increases arterial flow and consequently aids the removal of allogenic substances and helps to restore normal physiological conditions. Do not position the electrodes close to inflamed areas. Daily application is recommended, the IACER Srl MNPG239-03...
  • Page 22 Intensity: just a little bit over the perception threshold. TENS 12 • Epicondylitis (medical program) Also known as “tennis elbow”, it is an insertional tendinopathy concerning insertion of the elbow bone into the epicondylar muscles, those enabling finger and wrist extension (bending backwards). IACER Srl MNPG239-03...
  • Page 23 Intensity: to be adjusted above the perception threshold with small muscle contractions at the end of the program (10 minutes before the end). TENS 15 • TENS Burst (medical program) The stimulation produces an analgesic effect similar to TENS endorphinic. Widely used in pain management. IACER Srl MNPG239-03...
  • Page 24 Cruralgia TENS6 15/20 Daily, even twice a day the inside of the thigh Epicondylitis TENS12/ 15/20 Daily, even twice a day Photo 29 TENS13 Epitrocleitis TENS1 10/20 Daily, even twice a day Photo 30 IACER Srl MNPG239-03...
  • Page 25 The indications of the electrodes’ positioning are available in the Positions manual. IMPORTANT: FOR ALL THESE PROGRAMS, THE STIMULATION INTENSITY MUST BE ADJUSTED BETWEEN THE THRESHOLD OF PERCEPTION OF THE PULSE AND THE MOMENT WHEN THE PULSE STARTS TO CAUSE DISCOMFORT. IACER Srl MNPG239-03...
  • Page 26 8min (5s strength (14s 6Hz + Adjustable 4Hz + 5s 6s 70Hz) pulse 70Hz) width Total time Total time Total Total time Explosive 3min 10min time 5min strength Frequency (24s 2Hz + 10min Frequency 6s 90Hz) (24s 2Hz IACER Srl MNPG239-03...
  • Page 27 3min Sequential Frequency 2min Frequency tonic 50Hz Freque- contrac- Pulse cy 3Hz Pulse tions width 40- Pulse width 300µs width 300µs 300µs Sequential Total time Total time Total phasic 3min 20min time contrac- Frequency Frequency 2min IACER Srl MNPG239-03...
  • Page 28 For the active recovery pulses, between a contraction and the other, the intensity should be set to a value lower than the contraction intensity by about 15 20%. During the recovery phase (the last phase) the intensity IACER Srl MNPG239-03...
  • Page 29 (photo 04), Hand flexors (photo 05), Deltoid (photo 06). Abdominals (photo 01/20), Pectoralis major/breast (photo 07/17), Trapezius (photo 08), Latissimus dorsi (photo 09), Glutes (photo 19). Quadriceps/thighs (photo 11/18), Biceps femoris (photo 12), Calves (photo 13) Tibialis anterior (photo 14). IACER Srl MNPG239-03...
  • Page 30 Total program duration: 30 minutes Biceps (photo 02/15), Triceps (photo 03/16), Hand extensors (photo 04), Hand flexors (photo 05), Deltoid (photo 06). Abdominals (photo 01/20), Pectoralis major/breast (photo 07/17), Trapezius (photo 08), Latissimus dorsi (photo 09), Glutes (photo 19). IACER Srl MNPG239-03...
  • Page 31 Session duration: 26 minutes. Electrodes’ positioning: photo from 01 to 20 of the Positions manual. IACER Srl MNPG239-03...
  • Page 32 Prolonged use of this program develops the intramuscular capillary network of fast-twitch fibers. The effect obtained is an increase in the capacity of fast- twitch fibers to withstand strain over extended periods of time. For an athlete IACER Srl MNPG239-03...
  • Page 33 Quadriceps/thighs (photo 11/18), Biceps femoris (photo 12), Calves (photo 13) Tibialis anterior (photo 14). NEMS9 • Agonist/Antagonist (no-medical program) The electronic stimulator produces alternated contractions on 2 channels: during the first 4 minutes of warm-up the 4 channels work simultaneously, IACER Srl MNPG239-03...
  • Page 34 It stimulates mainly slow-twitch fibres. NEM11 • Sequential phasic contractions (no-medical program) This program produces rhythmic contractions with a stimulation frequency typical of fast-twitch fibres. Thanks to the high stimulation frequency, it is IACER Srl MNPG239-03...
  • Page 35 Session duration: short, 5 minutes. Electrodes’ positioning: photo from 01 to 20 of the Positions manual. Intensity: enough to produce good muscle contractions during the treatment, but not enough to cause any soreness. It mainly works on slow-twitch fibers. IACER Srl MNPG239-03...
  • Page 36 NEMS7 strength Arm triceps basic 3/16 NEMS4 NEMS8+NEMS4 NEMS4 NEMS7 strength The indications of the electrodes’ positioning are available in the Positions manual. ATTENTION: moderat eintensity during the first two weeks, increasing it over the following weeks. IACER Srl MNPG239-03...
  • Page 37 3Hz width Total time 30min (4min 8Hz + 1min Modelling 3Hz) Adjustable pulse width Total time 15min Frequency Microlifting 12Hz Pulse width 100µs Total time Total time Total time Lipolysis 5min 20min 5min abdomen Frequency Contr. Frequency IACER Srl MNPG239-03...
  • Page 38 (7s 40Hz 250µs CH3/4), 250µs Total time 20min Total time Total time Contr. 5min 5min alternate Frequency Frequency (6s 8Hz Lipolysis arms CH1/2/3/4) Pulse Pulse + (7s 40Hz width width CH1/2) + 200µs 200µs (7s 40Hz CH3/4), IACER Srl MNPG239-03...
  • Page 39 250µs Total time 15min Microlifting Frequency face with 25Hz Pulse handpiece width 100µs Total time 15min Microlifting Frequency seno with 18Hz Pulse handpiece width 100µs Total time Microlifting 15min décolleté Frequency with 50Hz Pulse handpiece width 100µs IACER Srl MNPG239-03...
  • Page 40 4. during the program and over the next few days the intensity should be increased gradually without causing pain; 5. during the contraction generated by the machine, contract the muscle voluntarily. IACER Srl MNPG239-03...
  • Page 41 4. during the program and over the next few days, the intensity should be gradually increased so that muscle contractions are not painful; 5. during contraction generated by the unit, contract the muscle voluntarily. IACER Srl MNPG239-03...
  • Page 42 4. during the program and over the next few days, the intensity should be gradually increased so that muscle contractions are not painful; 5. during contraction generated by the unit, contract the muscle voluntarily. IACER Srl MNPG239-03...
  • Page 43 3 cm between the electrode and the eyeball. IMPORTANT: take care when adjusting the intensity as facial muscles are particularly sensitive; intensity should be increased gradually, starting with a very low level of stimulation (just above IACER Srl MNPG239-03...
  • Page 44 Session duration: 30 minutes. Electrodes’ positioning: place the electrodes to form a square around the area to be treated as show in Figure 1. IACER Srl MNPG239-03...
  • Page 45 IMPORTANT: the intensity level should not be so as to cause discomfort! The equation more pain = more benefit is completely misleading and counterproductive. IACER Srl MNPG239-03...
  • Page 46 3÷5mA) and increasing with care until reaching a good level of stimulation, represented by good muscle activation. IMPORTANT: the intensity level should not be so as to cause discomfort! The equation more pain = more benefit is completely misleading and counterproductive. IACER Srl MNPG239-03...
  • Page 47 BEAUTY BEAUTY BEAUTY8 glutes 23 (CH1 on right BEAUTY BEAUTY BEAUTY Lipolysis hips hip CH2 BEAUTY8 on left hip sx) 15+16 (4 electro- Lipolysis des on BEAUTY BEAUTY BEAUTY BEAUTY9 arms right arm and 4 ch2 electro- IACER Srl MNPG239-03...
  • Page 48 Total time 30 min, Frequency 3 Hz Muscle relaxant Pulse width 250 µs Total time 30 min, Frequency 4 Hz Massage Pulse width 250 µs Total time 30 min (4 min 8 Hz + 3 Hz Deep capillarisation repeat – 250 µs) IACER Srl MNPG239-03...
  • Page 49 (the name of the program will turn white) and you will be able to select a different program from the list. The status bar at the bottom of the screen shows the channels (CH1+CH2) or (CH3+CH4) to which the program being changed belongs. IACER Srl MNPG239-03...
  • Page 50 Refer to the specifications and instructions for use reported in this manual for BEAUTY 3 program. Session duration: 30 minutes. Modelling (no-medical program) Refer to the specifications and instructions for use reported in this manual for BEAUTY 4 program. Session duration: 30 minutes. IACER Srl MNPG239-03...
  • Page 51 Select the relevant icon from the main menu using the selection keys , and confirm by pressing ; on the screen will appear a list with the last 10 programs used. Scroll through the list using the selection keys , and confirm your choice by pressing IACER Srl MNPG239-03...
  • Page 52 (MEM programs settings, language settings, last 10 programs used etc.), open the selection screen by pressing the keys at the same time, press to select “Reset to factory settings” and confirm by pressing . The device will show the following screen: IACER Srl MNPG239-03...

  • Page 53: Maintenance

    T-ONE COACH does not start and/or the display does not turn on. • Check the batteries level and replace them if exhausted (see chapter “Replacing the batteries”). Make sure the batteries are correctly inserted. If the problem persists, contact the manufacturer. IACER Srl MNPG239-03...
  • Page 54 Replace the batteries and start the treatment again. If the problem persists, contact the manufacturer. On the display appears “EEPROM ERROR”. Reset the device • following the instructions in the paragraph “Selecting the language and restoring the device to factory settings”. IACER Srl MNPG239-03...
  • Page 55 Replacing the batteries To replace the battery, proceed as follows: Turn off the device by pressing • • Open the rear battery compartment by removing the 2 screws that hold the cover, use a cross-head screwdriver. IACER Srl MNPG239-03...
  • Page 56 The correct disposal of obsolete equipment, accessories and most of all of batteries contributes in preventing possible negative consequences on human and environmental health. The user must dispose of scrap equipment by taking it to a recognized center for recycling of electrical and electronic equipment. IACER Srl MNPG239-03...

  • Page 57: Warranty

    Warranty IACER Srl guarantees a warranty period from the purchasing date for T-ONE COACH device, unless information contained in this manual regarding installation, use and maintenance is strictly adhered. The wearing parts (batteries and electrodes) are not included in the warranty, unless of visible manufacturing defects.

  • Page 58: Technical Standard

    The equipment does not generate significant radio frequency energy and is adequately immune to radiated electromagnetic fields. Therefore, it does not detrimentally interfere with radio-electric communications, electro-medical equipment for monitoring, diagnosis, therapy and surgery, office electronic IACER Srl MNPG239-03...

  • Page 59: Compatibility Tables

    Gruppo 1 negli apparecchi elettronici vicini RF emissions Group 1 T-ONE COACH uses RF energy only CISPR 11 for its internal function. Therefore, its RF emissions are very low and likely cause interference in nearby electronic equipment. IACER Srl MNPG239-03...
  • Page 60 (ESD) ±8kV; +15kV in ±8kV; +15kV in dovrebbe essere almeno aria / on air aria / on air 30%. Floors should be IEC 61000-4-2 wood, concrete ceramic tile. If floors are covered with synthetic IACER Srl MNPG239-03...
  • Page 61 / for 0,5 cicli ambiente commerciale o di ingresso / cycles / cycles ospedaliero. dell’alimentazione l’utilizzatore T-ONE Voltage dips, short <5% U <5% U COACH richiede interruptions and (>95% buco in / (>95% buco in / funzionamento IACER Srl MNPG239-03...
  • Page 62 (50/60 Hz) caratteristici Power frequency località tipica in ambiente 30A/m 30A/m (50/60 Hz) magnetic commerciale field ospedaliero. Power frequency IEC 61000-4-8 magnetic fields should be at levels characteristic of IACER Srl MNPG239-03...
  • Page 63 Portable and mobile RF communications equipment should not be used near any part of the device (including cables) except when the recommended separation distance is respected. This distance is calculated from the equation applicable to the frequency of the transmitter. Distanza di separazione raccomandata – Recommended separation distance IACER Srl MNPG239-03...
  • Page 64 800MHz a 2,7GHz / from 800MHz to 2,7GHz 3V/m irradiate   da 80 MHz a 6   dispositivi 3V/m   comunicazione ] V/m da 80MHz a 6GHz / from from 80MHz to radio 80MHz to 6GHz 6GHz IACER Srl MNPG239-03...
  • Page 65 T-ONE COACH is used exceeds the applicable RF compliance level above, T-ONE COACH should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as re- orienting or relocating T-ONE COACH. IACER Srl MNPG239-03...
  • Page 66 ���������������� 150������������ ���������������� 150������������ ���������������� 80������������ ���������������� 800������������ (banda ISM) radio) �������� 800 ������������ �������� 800 ������������ �������� 800 ������������ �������� 6������������ Rated maximum output (ISM band) wireless power of radio transmitter communication devices) 0,01 0,12 0,12 0,23 IACER Srl MNPG239-03...
  • Page 67 Queste linee guida potrebbero non applicarsi in tutte le situazioni. La propagazione elettromagnetica è influenzata dall’assorbimento e dalla riflessione di strutture, oggetti e persone / These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people. IACER Srl MNPG239-03...
