X-CUBE-LED1
18
Evaluate using X-CUBE-LED1
From
X-CUBE-LED1
1
SW resource package
Drag and drop
X-CUBE-LED1.bin
on STM32 Nucleo drive
Connect power supply and LED load using input/output connectors
2
