- Page 1 TechBook Y series whatever the spa, this is your control system Total Flexibility Total Compatibility Total Satisfaction...
-
Page 2: Table Of Contents
Table of contents Warnings 2 Introduction 3 Features 4 Overview - inye overview 5 - inye dimensions 5 - inyt overview 6 - inyt dimensions 6 Y Series installation - Floor installation procedure with optional guide plate 7 ... -
Page 3: Warnings
Warnings WARNINGS: Before installing or connecting the unit, please read the following * FOR UNITS FOR USE IN OTHER THAN SINGLE-FAMILY DWELLINGS, A CLEARLY LABELED EMERGENCY SWITCH SHALL BE PROVIDED AS PART OF THE INSTALLATION THE SWITCH SHALL BE READILY ACCESSIBLE TO THE OCCUPANTS AND SHALL BE INSTALLED AT LEAST 5' (152 M) AWAY, ADJACENT TO, AND WITHIN SIGHT OF THE UNIT * ANY DAMAGED CABLE MUST BE IMMEDIATELY REPLACED * TURN POWER OFF BEFORE SERVICING OR MODIFYING ANY CABLE CONNECTIONS IN THIS UNIT * TO PREVENT ELECTRIC SHOCK HAZARD AND/OR WATER DAMAGE TO THIS CONTROL, ALL UNUSED BUSHING CONDUITS MUST BE PLUGGED WITH THE ATTACHED NIPPLE * THIS CONTROLLER MUST NOT BE INSTALLED IN PROXIMITY OF HIGHLY FLAMMABLE MATERIALS * LOW SUPPLY VOLTAGE OR IMPROPER WIRING MAY CAUSE DAMAGE TO THIS CONTROL SYSTEM READ AND FOLLOW ALL WIRING INSTRUCTIONS WHEN CONNECTING TO POWER SUPPLY * THIS PACK CONTAINS NO USER SERVICEABLE PARTS CONTACT AN AUTHORIZED SERVICE CENTER FOR SERVICE * ALL CONNECTIONS MUST BE MADE BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH THE NATIONAL ELECTRICAL CODE AND ANY STATE, PROVINCIAL OR LOCAL ELECTRICAL CODE IN EFFECT AT THE TIME OF THE INSTALLATION * PRODUCT MUST BE DISPOSED OF SEPARATELY IN ACCORDANCE WITH LOCAL WASTE DISPOSAL LEGISLATION Aeware®, Gecko®, and their respective logos are Registered Trademarks of Gecko Alliance Group Inyt™, inye™, inkeys™, intouch™, ink200™, ink300™, in.k400™, in.k450™, ink500™, in.k600™, K-19™, K-35™, K-8™, K-4, in.k800™, inflo™, input™, inseal™, inlink™, intcip™, instik™, heatwav™, Y Series™, and their respective logos are Trademarks of Gecko Alliance Group All other product or company names that may be mentioned in this publication are tradenames, trademarks or registered trademarks of their respective owners... -
Page 4: Introduction
Introduction Y Series whatever the spa, this is your control system The Y Series offers the kind of simplicity that makes for a genuine top-of-its-class product It is the natural choice for anyone who wants an easy-to-understand multi-application solution You don't have to wonder about compatibility; instead, there’s just the comforting certainty that when you invest in the Y Series, all spa configurations are supported What's more, it also takes into account future compatibility, so you can have peace of mind knowing that you can enjoy your spa pack for years to come... -
Page 5: Features
Features The Y Series systems boast a long list of technical features Each of them contributes to bringing the most advanced solutions available to Y Series equipped spa owners: in.seal in.flo watertight protection dry-fire protection Inseal provides an extra level of protection A heater safety system located on the heatwav against water infiltration Connectors and power heater with an all-electronic dry-fire protection box are designed to be watertight so that no water can be in direct contact with electrical components (IPX5) in.stik in.t.cip automated software upload water temperature algorithm The instik is a pen drive with an inlink connector Intcip is an intelligent water temperature refresh very similar to a USB memory stick It connects algorithm that calculates optimal time to start to the spa pack and contains data to program or pumps and get water temperature readings configure its system The system executes Intcip continuously readjusts the heater start time the data upload automatically in.touch in.link you're always in touch with your relaxation ingenious plugs and connectors All Y Series packs support the intouch WiFi The Y Series is only compatible with the low- interface, allowing you to use your favorite iOS voltage family of inlink connectors, such as device to communicate with your spa those used by keypads and similar low-voltage accessories... -
Page 6: Overview
Overview in.ye overview Industry-standard AMP connectors for outputs Watertight strain relief system Main power Enough outputs for all entry connection your spa needs Ground input Light outputs connection (1 direct, 1 switched) (European Main keypad connector version shown) Communications link Access to heater connections heatwav heater with inflo technology Mounting feet Accessible bonding lugs in.ye dimensions Side view Front view 1655" (420 mm) 1075" (273 mm) 238 " (603 mm) 288 " (73 mm) 1960"... -
Page 7: InYt Overview
Overview in.yt overview Communications link (intouch or instik) Industry-standard AMP Watertight strain connectors for outputs relief system Enough outputs for all your spa needs Main power Light outputs entry connection (1 direct, 1 switched) Main keypad connector Access to heater Communications link connections heatwav heater with inflo technology Accessible Mounting feet bonding lugs in.yt dimensions Front view Side view 1662" (422 mm) 145" (368 mm) 238 " (603 mm) 288" (73 mm) 2" 1960" (51 mm) (498 mm) 516"... -
Page 8: Y Series Installation
OD x15 mm) Guide plate Select the location on Slide back side of the Now firmly attach unit to the floor for spa pack unit's feet into the guide wooden base by using Part numbers: and firmly attach guide plate It should easily slide the remaining 2 screws 9917-102148 (in.ye guide plate) 9917-100873 (in.yt guide plate) plate to wooden base into place backed by 2 washers to with 2 screws backed attach the front feet by 2 washers Floor installation procedure without guide plate The following material is recommended: 4- # 10 screws with round, truss or pan ... -
Page 9: Wall Installation Procedure With Optional Wall Mounting Brackets
Y Series installation Wall installation procedure with optional wall mounting brackets Install mounting brackets The following material is Firmly attach, one at a Firmly attach lower on both sides of rear of recommended: time, upper mounting mounting holes on each unit, using the screws holes on each side of the side of the pack with 4- # 10 screws of provided with the bracket spa pack with 2 screws the 2 remaining screws appropriate length with backed by 2 washers and 2 washers round, truss or pan head Torque screws Lower mounting holes to 13 inlb max (149 Nm) are 2" (51 mm) below 4- washers 1/2" OD x 1/16” upper holes thickness (12 mm OD x 15 mm) Part number: Use 2 standard 2" x 4" or ... -
Page 10: Y Series Connections
Y Series connections Connecting the main keypad to the spa pack To connect the keypad, remove the cover, then insert the inlink connector into the appropriate keypad connector (as illustrated) Route the cable through one of the molded strain relief channels on the bottom right side of the spa pack (as illustrated) Fill the remaining space with the foam gaskets supplied Don’t forget to replace the cover and all screws (torque to 8 inlb max [09 Nm]) Note: always shut power down before connecting an accessory to the in.ye or in.yt. keypad Connect the main keypad as indicated here ... -
Page 11: Heater Connections
Y Series connections Heater connections Live Return Ground Regulation probe inflo heat.wav heater All Y Series systems come with a high performance The heatwav heater is factory configured for heatwav heater With no pressure switch, it features 240 V / 4 kW, but it can be converted to a dedicated inflo integrated dry-fire protection 120 V / 1 kW by simply adding a cable connection (120 V conversion is available on North American inye-3 models only) heatwav specification summary: • Supports 120 V or 240 V • Protected by external breaker (not fused)* • Incoloy® heater element • Optional 55 kW, 240 V heater is available *Note: European models are 230-240 V only, and are fuse protected Part numbers: 9917-101959 (cable for conversion) 9920-101449 (5.5 kW heat.wav heater) -
Page 12: High Voltage Accessory Connections
Y Series connections High voltage accessory connections Two options are available with Y Series spa packs for connecting high voltage accessories: 0250” quick-connect terminals, or AMP pins and housings Connection high voltage accessories: in.ye These tabs require high-voltage accessories to have straight, non-insulated, female quick-connect terminals for all connections, including ground Depending on where the connections are made on the inye pack PCB, 120 V and 240 V accessories are supported Refer to the following tables for correct connections Note that all female terminals must be correctly and completely seated on the PCB tab for proper current ratings 120V 240V P43 P44 120V DIRECT WHITE 20A/600VAC TIME-DELAY CLASS G BLACK GREEN 30A/480VAC TIME-DELAY CLASS G HEATER LIGHT, DIRECT 0.5A/250VAC GROUND 3AG FAST-ACT. - Page 13 Y Series connections Connection high voltage accessories: in.yt These tabs require high-voltage accessories to have straight, non-insulated, female quick-connect terminals for all connections, including ground Depending on where the connections are made on the spa pack PCB, 120 V and 240 V accessories are supported Refer to the following tables for correct connections Note that all female terminals must be correctly and completely seated on the PCB tab for proper current ratings Direct output 1 (A4) Voltage 120 V 240 V Green / ground Black / line White / common Direct output 2 (C1) (in.yt only) Voltage 120 V 240 V Green / ground Black / line P133 P133 White / common Auxiliary (B1) (in.yt-12 only) Voltage...
- Page 14 Y Series connections Connection high voltage accessories: in.ye-ce (European) These tabs require high-voltage accessories to have straight, non-insulated, female quick-connect terminals for all connections, including ground On -ce packs, only 230V accessories are supported Refer to the following tables for correct connections Note that all female terminals must be correctly and completely seated on the PCB tab for proper current ratings Direct output 1 (in.ye-5 ce only) Pump 1 (A3) Pump 3 (A4) (in.yt-5 ce only) Ozonator* (A1) (Floating connector) Voltage 230 V Voltage 230 V Voltage 230 V...
- Page 15 Y Series connections Connection high voltage accessories: in.yt-ce (European) These tabs require high-voltage accessories to have straight, non-insulated, female quick-connect terminals for all connections, including ground On -ce packs, only 230V accessories are supported Refer to the following tables for correct connections Note that all female terminals must be correctly and completely seated on the PCB tab for proper current ratings Direct output 1 (A4) Voltage 230 V Green / ground Black / line White / common Direct output 2 (C1) (in.yt only) Voltage 230 V Green / ground Black / line P133 White / common Auxiliary (B1) (in.yt-12 only) Voltage 230 V Green / ground...
- Page 16 Y Series connections Connection high voltage accessories: in.yt-7-ce (European), part # 0611-221009 only These tabs require high-voltage accessories to have straight, non-insulated, female quick-connect terminals for all connections, including ground On -ce packs, only 230V accessories are supported Refer to the following tables for correct connections Note that all female terminals must be correctly and completely seated on the PCB tab for proper current ratings Pump 1 (A3) Pump 3 (A1) Circ. pump (C2) Ozonator (A4) Voltage 230 V Voltage 230 V Voltage 230 V Voltage 230 V Green / ground Green / ground Green / ground...
-
Page 17: Y Series Wiring
Y Series wiring Electrical wiring for North American models Warning! For units for use in other than single-family dwellings, a clearly labeled emergency switch shall be provided as part of the installation The s witch shall be readily accessible to the occupants and shall be installed at least 5' (152 m) away, adjacent to, and within sight of the unit ----- This product must always be connected to a circuit protected by a ground fault interrupter Main electrical box GFCI panel Proper wiring of the electrical service box, GFCI and Y Series terminal block is essential! Check your electrical code for local regulations Only copper wire should be used, never ... -
Page 18: Electrical Wiring: North American Model
Refer to wiring diagram in the enclosure box lid for more information 2-phase used from 3-phase 3-phase 1-phase 2-phase L1 current returns through neutral with single neutral with single neutral Delta — no neutral Connect PJ1 between P7 L1+L2 currents return through neutral L1, L2+L3 currents return Use 2-phase setting through neutral Connect PJ1 between and P13 Connect PJ2 L1+L2 currents return through L3 Connect PJ1 between P7 and P10 Connect PJ2 Connect PJ1 between between P10 and P74 P7 and P10 Connect PJ2 P7 and P10 Connect PJ2 between P13 and P74 between P11 and P13 between P13 and P74 in.ye.ce 230 V or 230/400 V Warning! inyece models must always be connected to a Correct wiring of the electrical service box, RCD, circuit protected by a Residual-Current Device and pack terminal block is essential! (RCD) having a rated operating residual-current not Call an electrician if necessary exceeding 30 mA... -
Page 19: Electrical Wiring: InYt-Ce (European)
Y Series wiring Electrical wiring: in.yt-ce (European) Refer to wiring diagram in the enclosure box lid for more information 1-phase 2-phase 3-phase 2-phase used from 3-phase with single neutral L1 current returns through neutral with single neutral Delta — no neutral L1, L2+L3 currents return Connect PJ1 between L1+L2 currents return through neutral through neutral Use 2-phase setting Connect PJ1 between P7 and P13 Connect PJ2 Connect PJ1 between L1+L2 currents return through L3 P7 and P10 Connect PJ2 P7 and P10 Connect PJ2 between P10 and P74 Connect PJ1 between between P13 and P74 P7 and P10 Connect PJ2 between P11 and P13 between P13 and P74 in.yt.ce 230 V or 230/400 V ... -
Page 20: Power-Up & Breaker Setting
Power-up & breaker setting IMPORTANT! Read before starting Turn off the breaker. Make sure all accessories are linked to the bonding connector and connected to pack. A minimum flow rate of 18 GPM is required. Make sure that all valves are open in the spa plumbing and that you have good water flow circulation from the primary pump into the heater. -
Page 21: Programming The Y Series
Programming the Y Series communications port Programming the Y Series using the in.stik Follow these simple At power-up the spa pack Press the Prog key to will upload all the different confirm the selected steps to upload new configurations from the configuration pre-determined low-level instik memory program configurations If the Prog key is not into the spa pack The unit will then enter pressed within 25 seconds, the low-level configuration the unit will exit this menu Shut electrical power off menu without changing any Remove the cover to settings The keypad display will access the low-voltage show L xx where "xx" inlink connectors inside, represents the previous connect the instik to the ... - Page 22 Programming the Y Series Please refer to the Quick Start Card for your model to set the proper low level and connector location. Contact your OEM for specific configurations. Model Quick Start Card Number inye-3 9919-101202 inye-3-ce 9919-101203 inye-5 9919-101192 inye-5-ce 9919-101193 inyt-7...
-
Page 23: Typical Output Configurations
Typical output configurations Individual configuration will depend on the low level selected Refer to low level table and wiring diagram in.ye-3 in.ye-5 (FL) Di 1 (120 V) P1 (2-spd) P2 O3/CP O3/CP Output 3 Top AMP connector unavailable P3 (1-speed) - see note Output 2 (Output 4 on CE) Output 2 (Output 4 on CE) Output 5 Output 5 P1 (2-speed) P1 (2-speed) Output 1 Output 5 Output 3 P2 (2-speed) P2 (1-speed) - see note Output 4 (Output 2 on CE) Output 4 (Output 2 on CE) O3/CP O3/CP Note: If P2 is used, P1L cannot be used. - Page 24 Typical output configurations in.yt-7 , part # 0611-221009 only C1 Di P1 (2-spd) C2 CP C3 (1-spd) P2 (2-spd) P3 (1-spd) Output 14 Output 3 Output 4 Output 5 Output 6 P1 (2-speed) Output 1 Output 3 Output 8 P2 (2-speed) P4 (1-spd) Output 2 P3 (1-spd)
- Page 25 Typical output configurations in.yt-12 C1 Di 2 B P5 (1- spd) C2 CP C3 P3 (2 spd) P4 (2-spd) A1 (240 V) Di 1 (120 V) P1 (2-spd) P2 (2-spd) O3 Output 14 Output 11 Output 13 Di 2 Di 1 Blower Output 12 Output 2 (Output 4 on CE) Output 7 Output 5 P5 (1-speed) P1 (2-speed) Output 9 Output 1...
-
Page 26: Output Cables
(∅ 0365" (∅ 0305" to 0425") to 0425") to 0375") For 14-3/18-3 For 14-4/14-3 cable size For 14-4 only cable size (∅ 0305" cable size (∅ 0365" to 0375") (∅ 0410" to 0425") to 0425") in.ye For 14-4/14-3 cable size For 14-3/18-3 (∅ 0365" cable size to 0425") (∅ 0305" to 0375") Output cable installation Output cable Strain relief bracket 1/8" (3mm) max The cable jacket must not exceed the strain relief bracket more than 1/8" (3mm)... -
Page 27: Amp Pins And Housings
Y Series field programming options AMP pins and housings A special PP-1 splitter can be ordered (Part #: 9920-401369) and used to split an output into 2 parallel outputs (ie a single O3 output could be used for an ozonator and UV generator, 03 or CP) Both accessories driven must be of the same operating voltage (120 V or 240 V) Pin #1 (Black) Pin #2 (N/A) Pin #3 (White) Pin #4 (Green) Pin #1 (Black) Pin #2 (N/A) Pin #3 (White) Pin #4 (Green) -
Page 28: Custom Configurations
Y Series field programming options Custom configurations In the event that none of the predetermined low-level program configurations built in the unit's system suit your spa equipment assembly, it's possible to custom configure the system by manually entering key parameter settings (see Table 1) To access this menu, press and hold the Prog (or Light key) for 30 seconds Use the Up/Down keys to choose settingPress the Prog key (or Light key) to go to the next parameter Parameters available will depend on your model Table 1 Parameter Display Options Description --,1H,1L,2H,2L,3H,3L,4H, Output 1 Accessory connected to relay Output 1 4L,P5,BL,CP,O3,L2,H, ON --,1H,1L,2H,2L,3H,3L,4H, Output 2 Accessory connected to relay Output 2 4L,P5,BL,CP,O3,L2,H, ON --,1H,1L,2H,2L,3H,3L,4H, Output 3 Accessory connected to relay Output 3 4L,P5,BL,CP,O3,L2,H, ON --,1H,1L,2H,2L,3H,3L,4H, Output 4 Accessory connected to relay Output 4 4L,P5,BL,CP,O3,L2,H, ON --,1H,1L,2H,2L,3H,3L,4H, Output 5 Accessory connected to relay Output 5 4L,P5,BL,CP,O3,L2,H, ON --,1H,1L,2H,2L,3H,3L,4H, ... - Page 29 Y Series field programming options Table 1 (Continued) Parameter Display Options Description Cool down 30 to 240 seconds Cool down of the heating element in seconds Output 1 current 0 to 15 amperes Current draw of Output 1 accessory Output 2 current 0 to 15 amperes Current draw of Output 2 accessory Output 3 current 0 to 15 amperes Current draw of Output 3 accessory Output 4 current 0 to 15 amperes Current draw of Output 4 accessory Output 5 current 0 to 15 amperes Current draw of Output 5 accessory Output 6 current 0 to 15 amperes Current draw of Output 6 accessory Output 7 current 0 to 15 amperes Current draw of Output 7 accessory Output 8 current 0 to 15 amperes Current draw of Output 8 accessory Output 9 current 0 to 15 amperes Current draw of Output 9 accessory Output A current...
-
Page 30: Keypad Overview
Keypad overview The following instructions are generic and provide a quick overview of the main keypad functions Please refer to your own QRC for specific functions The Y Series spa pack is compatible with the following keypads: ink200, ink300, ink400, ink450, ink500, ink600 (streamlined), K-4, K-19, K-35, K-8 (with inlink connector) and ink800 (color display)... -
Page 31: Function Description
Keypad overview Function description Smart Winter Mode Pump 1 Pump 2 Blower Light Filter Heater Set Point indicator indicator indicator indicator indicator indicator indicator indicator Key 1 Key 2 Light key Up/Down key Instructions Key 1 Key 2 Key 2 Light key (single pump or blower) (single pump & blower) Press Key 1 to turn pump ... - Page 32 Keypad overview Programming the system Up/Down key Off Mode Setting filter cycle duration Use Up/ keys This mode allows you Depending on system Press and hold or Down the Prog to stop all outputs for configuration the system to set desired water Light key until the display performs either purge temperature The 30 minutes to perform a shows , with " " d xx cycles or filter cycles temperature setting will quick spa maintenance representing the duration be displayed for 5 seconds in hours Press and hold ...
-
Page 33: Typical Settings
Keypad overview If the readings received Smart Winter Mode Cool down Water temperature from the system are not regulation valid, blanks (- - -) will be Our Smart Winter Mode After heating the spa water displayed until normal In a regulation cycle, protects your system to the desired Set Point, readings have been the system first generates from the cold by turning the heater is turned off, successfully recorded water flow through the pumps on several times a but its associated pump heater housing and the day to prevent water from (Pump 1 low-speed or CP) After verifying pump plumbing, in order to freezing in pipes remains on for a certain activation and taking ensure accurate water The Smart Winter Mode amount of time to ensure a water temperature ... -
Page 34: Troubleshooting
Troubleshooting Y Series error codes Error codes indicate a failure condition or a problem which needs to be corrected to ensure proper functioning of the system Both the error code and the water temperature are alternatively displayed All errors codes will be displayed on the keypad display An internal hardware error has been detected in the spa pack The Prr error message indicates a problem with the regulation probe The system is constantly verifying if temperature probe reading is within normal limits Water temperature at the heater has reached 119°F Do not enter spa water! The system did not detect any water flow while the main pump was running No low-level configuration software has been downloaded into the system Temperature inside the spa skirt is too high, causing the internal temperature in the spa pack to go above normal limits Water temperature in the spa has reached 108°F Do not enter spa water! -
Page 35: Hr Error Message
Troubleshooting Hr error message An internal hardware error has been detected • Restart the spa pack and start & stop all pumps and blower • If error reappears, replace the spa pack Prr error message Regulation probe issue Regulation probe • Verify if regulation • Replace heater if probe (located above problem persists the heater) is properly • Replace spa pack, connected if problem persists... -
Page 36: Hl Error Message
Troubleshooting HL error message The system has shut down because the temperature at the heater has reached 119°F (48°C). Regulation probe • Measure the temper- If reading is below 119°F: If reading is 119°F or If reading is 119°F or higher and does not higher and weather is ature with a DIGITAL ... -
Page 37: Flo Error Message
Troubleshooting FLO error message The system did not detect any water flow while the primary pump was running. Make sure that the low-level programming has been properly set, with or without circulation pump (depending on your system configuration) inflo cable • Make sure water valves • If problem persists are open and that water replace heatwav level is high enough • If the problem is • Check and remove not solved replace anything obstructing the spa pack the filter • Make sure there is adequate flow (minimum 18 GPM) • ... -
Page 38: Oh Error Message
Troubleshooting OH error message Water temp. in the spa has reached 108°F • Measure water If temperature reading is If temperature on display If temperature on display temperature with a different: is correct (above 108°F) is correct (above 108°F) DIGITAL thermometer and weather is hot: and hot weather is not a • ... -
Page 39: Pump 1 Doesn't Work
Troubleshooting Pump 1 doesn't work Pump 1 is not working. • Check for an error • Check if the Pump 1 If the Pump 1 indicator does not appear: message on keypad indicator appears on • Use a spare keypad to verify if keypad is defective display If there is one, keypad display when refer to the specific sec- you press Key 1 • If it is, replace keypad tion indicated by the error message • If not, replace spa pack • Verify low-level programming ... -
Page 40: Pump 2 Or Blower Doesn't Work
Troubleshooting Pump 2 or blower doesn't work Pump 2 or blower is not working. • Check for an error • Check if the Pump2 If the indicator does not appear: message on keypad or Blower indicator • Use a spare keypad to verify if keypad is defective display If there is one, appears on keypad refer to the specific sec- display when you press • If it is, replace keypad tion indicated by the the corresponding key error message • ... -
Page 41: Circulation Pump Doesn't Work
Troubleshooting Circulation pump doesn't work Circulation pump is not working. in.yt model Pin 1 Pin 3 Circulation pump fuse (F21) in.ye model Pin 1 Pin 3 Circulation pump fuse (F2) If circulation pump is not • Take voltage reading If you don't get a voltage working: on the corresponding reading: AMP connector: ... -
Page 42: Ozonator Doesn't Work
Troubleshooting Ozonator doesn't work Ozonator is not working. Ozonator output will be shut down when Pump 1, Pump 2 or blower have been turned on manually Ozonator fuse (F2) Pin 1 Pin 3 If the ozonator is not working: • Check if Filter Cycle • If ozonator does not If you don't get a voltage indicator appears reading, replace the work even when Filter steady on keypad accessory fuse. Cycle indicator is on, or indicator does not light If changing the fuse does • ... -
Page 43: Nothing Seems To Work: North American Models
Troubleshooting Nothing seems to work: North American models Verify that all screws are properly tightened on the terminal block. Turn power off and make sure that all cables hold firmly in the terminal block if you pull on them. Once done, turn power back on. • ... -
Page 44: Nothing Seems To Work: European Models
Troubleshooting Nothing seems to work: European models Verify that all screws are properly tightened on the terminal block. Turn power off and make sure that all cables hold firmly in the terminal block if you pull on them. Once done, turn power back on. For 1-phase system For 2-phase system For 3-phase system... -
Page 45: Spa Not Heating
Troubleshooting Spa not heating Heater fuse (F1) Set Point indicator Heater indicator Live Return Ground (CE Model only) • Check for an error • Check if Heater If Heater indicator lights If Heater indicator up on the display: does not light up on message on keypad indicator appears on the display, measure display If there is one, keypad display • Take voltage reading water temperature refer to specific section ... -
Page 46: Gfci/Rcd Trips
Troubleshooting GFCI/RCD trips Main electrical box Important connections: Neutral of GFCI /RCD must be connected to neutral bus. Ground Neutral from wire spa must be From From To spa connected to electrical box To spa electrical box GFCI/RCD breaker. panel Warning! Total current output cannot exceed total current input rating! There are different ... -
Page 47: Step-By-Step Field Replacement Procedure
Step-by-step field replacement procedure Y Series Step-by-step field replacement procedure As part of our technical support services, this section provides proper step-by-step methods to facilitate the replacement of Y Series spa packs in the field Tools needed: • Phillips & flat screwdrivers • Multimeter • Open-ended adjustable wrench • Scraper tool • Pliers • GFCI tester All procedures described in this service manual must only be performed by qualified personnel, in accordance with the standards applicable in the country of installation How to remove a spa pack from the spa piping. Carefully revise the spa Remove the cable strain Warning! Disconnect incoming plumbing schematics relief cover (3 screws) ... - Page 48 Step-by-step field replacement procedure Unplug all low-voltage Disconnect the grounding Using a tongue and outputs eg: main cable from the bonding groove plier loosen both keypad, light or any other lug of the spa pack plastic nuts at each end accessory of the unit's heater, as illustrated Remove the 2 screws that Release the heater nuts Once that is done, remove When removing the old from both ends of the spa the old keypad from keypad, make sure to note hold the front of the unit's feet attached to the spa piping the spa the exact model, available floor options etc Ideally, Release the spa pack by the new replacement Note: the procedure on sliding the unit away from keypad should be of keypad replacement shown Note: the unit can also be the guide plate that holds ...
- Page 49 Step-by-step field replacement procedure With a scraper tool, gently Feed the cable of the new Insert the keypad in Peel off the protective clean the installation keypad through the hole the opening layer from the adhesif on surface of the new keypad, opening in the spa the back of the keypad then use an alcohol Orient the cable's Make sure that the keypad saturated paper towel to connector towards the is well aligned and rests remove any unwanted spa pack to facilitate its perfectly in the recess of residue left over from the connection later the spa old keypad Secure the keypad in Place a rubber 2" O-ring When installing the new Install the new spa pack in place Ensure that its gasket at the end of each spa pack, slide the back the spa plumbing adhesive strip is properly heater nut, to prevent side of the unit's feet into glued by pressing evenly water leakage between ...
-
Page 50: How To Replace The Heater
Step-by-step field replacement procedure How to replace the heater HL Probe & inflo Live Return Ground Temp Probe Using a Phillips Manually remove the Warning! screwdriver, loosen the inflo connector Before starting removal procedure be sure to: screws that hold the cover Be careful not to damage in place Use a Phillips any connector by twisting • Turn off electric power to the unit screwdriver to loosen the or pulling too hard • Ensure spa water valves are closed terminals and remove (or that the spa is drained) all electrical heater connections: Return, Live and Ground Manually remove the HL probe & Temp probe connector ... -
Page 51: How To Replace The Main Control Board On InYe
Step-by-step field replacement procedure How to replace the main control board on in.ye Warning! Using a Phillips Use a Phillips screwdriver Manually remove the Before starting screwdriver, loosen the to loosen the terminals transformer connector 4 screws that hold the and remove all electrical removal procedure Manually remove the cover in place Disconnect heater connections: be sure to: topside cable and incoming power lines Return, Live and Ground • Turn off electric the inlink cables by loosening the screws Manually remove the HL power to the unit on the terminals of the probe & Temp probe ... -
Page 52: How To Replace The Main Control Board On InYt
Step-by-step field replacement procedure How to replace the main control board on in.yt Warning! Loosen the 6 screws that Use a Phillips screwdriver Manually remove the Before starting hold the cover in place to loosen the terminals transformer connector removal procedure Disconnect incoming and remove all electrical Manually remove the be sure to: power lines by loosening heater connections: topside cable and • Turn off electric the screws on the Return, Live and Ground the inlink cables power to the unit terminals of the terminal Manually remove the HL block probe & Temp probe connector Manually ... -
Page 53: How To Replace The Upper Extension Board On The InYt
Step-by-step field replacement procedure How to replace the upper extension board on the in.yt Warning! Using a Phillips screwdriver, Identify each wire coming Remove the control cable from the upper board Before starting loosen the 6 screws that from the main board and removal procedure hold the cover in place remove them from the Disconnect the incoming be sure to: extension board conductors from the • Turn off electric screw lug terminal power to the unit Remove the inlink cables Remove the inlink Reinstall the 2 AMP Identify and remove all bracket Remove the assembly brackets and the the output power cord ... -
Page 54: Specifications
Specifications Environmental ratings: Operating temperature: 32˚F (0°C) to 136˚F (58˚C) Storage temperature: -13°F (-25°C) to 185°F (85°C) Humidity: Up to 85% RH, non condensing IPx5 level of waterproofing Mechanical: in.ye Weight: Up to 97 lbs (44 kg) Dimensions (W x H x D): 19598" x 1075" x 498" (497 x 273 x 126 mm) in.yt Weight: Up to 12 lbs (445 kg) Dimensions (W x H x D): 1958" x 145" x 51" (497 x 368 x 130 mm) Model Y Series UL/CSA electrical specifications Input rating: ... -
Page 55: North American Models
Specifications North American Models * 7 * 8 Device Voltage Maximum current ye-5 ye-3* yt-7 yt-12 • • • • Pump 1 (2-spd) 120 or 240 V 15 FLA/60 LRA (inrush) • • • • * 2 * 4 Pump 2 (2-spd) 120 or 240 V 15 FLA/60 LRA (inrush) • • • * 5 Pump 3 (2-spd) 120 or 240 V 15 FLA/60 LRA (inrush) • Pump 4 (2-spd) 120 or 240 V 15 FLA/60 LRA (inrush) •... -
Page 56: European Models
Specifications European Models * 6 * 7 Device Voltage Maximum current ye-3* ye-5 yt-7 yt-12 • • • • Pump 1 (2-spd) 230 V 15 FLA/60 LRA (inrush) • • • • * 1 * 3 Pump 2 (2-spd) 230 V 15 FLA/60 LRA (inrush) • • • * 4 Pump 3 (2-spd) 230 V 15 FLA/60 LRA (inrush) • Pump 4 (2-spd) 230 V 15 FLA/60 LRA (inrush) •... - Page 57 9919-101184-C Gecko Alliance Rev. 04-2014 450 des Canetons, Quebec City (Qc), G2E 5W6 Canada, 1.800.78.GECKO 9225 Stellar Court, Corona, CA 92883 USA, 951.667 .2000 © Groupe Gecko Alliance Inc., 2014 All trademarks or registered trademarks www.geckoalliance.com are the property of their respective owners.
