Steelcase Verb Manual page 2

®
Attaching Access Legs to a Media Worksurface
1.
Place worksurface upside down
on a clean, scratch resistant surface,
such as on a table.
2.
Align the marked identification holes
on the leg top plate with the pilot holes as
shown. Install #10 x 1" wood screws into
the three (3) pilot hole locations (2a).
Install six (6) wood screws in the
remaining hole locations on the leg
top plate (2b).
Example of a marked
identification hole.
2a 2b
Align the marked identification holes with the inward
most pilot holes.
NOTICE: DO NOT install Access (Fixed Height) legs in
the hole pattern for the Post (Height-Adjustable) legs.
A properly installed leg will have a caster or glide that
does not extend past the edge of the worksurface.
Page 2 of 6
24450602 Rev A
