Adsl Compliance; Atm And Ppp Protocols; Network Protocols And Features; Hardware Specification - Billion Modem/Router ADSL BIPAC-7100S Specifications

ADSL Compliance

•
Compliant with ADSL Standards
- Full-rate ANSI T1.413 Issue 2
- G.dmt (ITU G.992.1)
- G.hs (ITU G.994.1)
- ADSL over ISDN/U-R2
•
Sync. Rate: up to 8Mbps for download rate and
1Mbps for upload rate

Network Protocols and Features

•
NAT, static routing and RIP-1/2
•
Universal Plug and Play (UPnP) Compliant
•
Dynamic Domain Name System (DDNS)
•
Virtual Server and DMZ
•
SNTP, DNS relay and IGMP proxy
•
POP3 (email account checking)

Hardware Specification

Physical Interface
•
WAN: ADSL port
•
Factory default reset button
•
LAN: 10/100M auto-crossover (MDI/MDI-X)
•
Power jack
•
Power switch
Physical Specification
•
Dimensions: 7.28" x 5.0" x 1.85"
(185mm x 127mm x 47mm)
Power Requirement
•
Input: 12V DC, 1A
Feature & Specification

ATM and PPP Protocols

•
ATM Adaptation Layer Type 5 (AAL5)
•
Multiple Protocol over AAL5 (RFC 2684,
formerly RFC 1483)
•
Bridged or routed Ethernet encapsulation
•
VC and LLC based multiplexing
•
PPP over Ethernet (PPPoE)
•
PPP over ATM (RFC 2364)
•
Classical IP over ATM (RFC 1577)
•
OAM F4/F5
Firewall
•
Built-in NAT firewall
•
Prevent DoS attacks including IP Spoofing,
Land Attack, Ping of Death, TCP SYN
Flooding, etc.
•
E-mail alert whenever detect attacks
•
Packet filtering based-on MAC address, IP
address & port number
•
URL blocking – string or domain name
detection in URL string
Virtual Private Network (VPN)
•
Embedded IPSec/IKE
•
DES and 3DES encryption for IPSec
•
L2TP/PPTP/IPSec pass-through
Management
•
Ease of use with Quick Start setup
•
Web-based GUI for remote and local
management
•
Firmware upgraded via Web-based GUI and
FTP/TFTP
•
System & intrusion detection log
•
SNMP MIB support
•
Support DHCP server/client/relay
•
Diagnostic test utility

Operating Environment

•
Operating temperature: 0 ~ 45 ºC
•
Storage temperature: -20 ~ 70 ºC
•
Humidity: 20 ~ 95% non-condensing
Specifications are subject to change without notice.
Billion Electric Co., Ltd.
8F, No.192, Sec.2, Chung Hsing Road,
Hsin Tien City, Taipei Hsien, Taiwan
www.billion.com
TEL : +886-2-2914-5665
FAX : +866-2-2918-6731,+886-2-2918-2895
E-mail : sales@billion.com
