- Page 1 BIPAC-7100S / 7100 ADSL Modem/Router Quick Start Guide...
-
Page 3: Package Contents
For more detailed instructions on configuring and using the ADSL Modem/ Router, please refer to the on-line manual. Package Contents Billion BIPAC-7100S/7100 ADSL Modem/Router One CD-ROM containing the driver and online manual One Quick Start Guide One RJ-11 ADSL/telephone cable... -
Page 4: The Front Panel Leds
Quick Start Guide The Front Panel LEDs 7100S ADSL DSLAM and working properly. Meaning Lit green when power adapter is connected. When flash, it indicates that the device is working properly. Lit green when the LAN link is connected. Flashes green when collision happens When lit, it indicates that the ADSL (Line) port is connected to the... - Page 5 Lit green when the LAN3 link is connected. LAN4 Lit green when the LAN4 link is connected. When lit, it indicates that the ADSL (Line) port is connected to the ADSL DSLAM and working properly. Billion BIPAC-7100S/7100 ADSL Modem/Router Meaning...
-
Page 6: The Rear Ports
Quick Start Guide The Rear Ports 7100S Port Power Switch Power ON/OFF switch (connector RJ-45) RESET LINE (connector RJ-11) BIPAC-7100 has 4 LAN Ports, each of them has the same function as that of 7100S Connect the supplied power adapter to this jack. Connect the supplied crossover cable to this port when connecting to a NIC (Network Interface card) in PC. -
Page 7: Connecting Your Adsl Router
3. Make sure the PWR and SYS LEDs are lit steadily and that the relevant LAN LED is lit. 4. Follow the “Configuring the Network Properties on a PC” section on page 8 to modify the network settings. 7100S 7100 Billion BIPAC-7100S/7100 ADSL Modem/Router... -
Page 8: Configuring Pc In Windows Xp
Quick Start Guide Configuring PC in Windows XP 1. Go to Start / Control Panel (in Classic View). In the Control Panel, double-click on Network Connections 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window, click Properties. 4. -
Page 9: Configuring Pc In Windows 2000
3. In the Local Area Connection Status window click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties. 5. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons. 6. Click OK to finish the configuration. Billion BIPAC-7100S/7100 ADSL Modem/Router... -
Page 10: Configuring Pc In Windows 98/Me
Quick Start Guide Configuring PC in Windows 98/Me 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab. 2. Select TCP/IP -> NE2000 Compatible, or the name of your Network Interface Card (NIC) in your PC. - Page 11 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties. 3. Select the Obtain an IP address from a DHCP server radio button and click OK. Billion BIPAC-7100S/7100 ADSL Modem/Router...
- Page 12 Quick Start Guide Configuring Your ADSL Modem/Router To configure this device, you must have IE 5.0 / Netscape 4.5 or above installed Verifying Your Local Network Connection with the Device To see if this ADSL Router is visible on the local network, go to Start / Run.
-
Page 13: Product Support And Contact Information
Contact Billion AUSTRALIA http://www.billion.com.au Hotline: 1300 139 159, 7 days a week. ©2003 Billion Electric Co Ltd., PC Range P/L. All Rights Reserved. WORLDWIDE http://www.billion.com Mac OS is a registered Trademark of Apple Computer, Inc. Windows 98, Windows NT, Windows 2000, Windows Me and Windows XP are registered Trademarks of Microsoft Corporation.
