USER MANUAL
Ultra Low Power RTU and Datalogger, with quad band GSM/GPRS modem and
SENECA s.r.l.
Via Austria 26, PADOVA – ITALY
Tel. +39.049.8705355 – 8705359 Fax. +39.049.8706287
Web site:
www.seneca.it
Customer service:
(Other)
Commercial information:
(Other)
This document is property of SENECA srl. Duplication and reproduction of its are forbidden
(though partial), if not authorized. Contents of present documentation refers to products and
technologies described in it. Though we strive for reach perfection continually, all technical data
contained in this document may be modified or added due to technical and commercial needs;
it's impossible eliminate mismatches and discordances completely. Contents of present
documentation is anyhow subjected to periodical revision. If you have any questions don't
hesitate to contact our structure or to write us to e-mail addresses as above mentioned.
RTU-LP
embedded I/O
supporto@seneca.it
(IT),
commerciale@seneca.it
MI004690_101_EN
Page 1
support@seneca.it
(IT),
sales@seneca.it
Advertisement
Table of Contents
Related Manuals for Seneca RTU-LP
Summary of Contents for Seneca RTU-LP
- Page 1 (Other) This document is property of SENECA srl. Duplication and reproduction of its are forbidden (though partial), if not authorized. Contents of present documentation refers to products and technologies described in it. Though we strive for reach perfection continually, all technical data contained in this document may be modified or added due to technical and commercial needs;...
- Page 2 USER MANUAL – RTU-LP-ST Date Version Changes 03/04/2017 1.00 First Revision 12/06/2017 1.01 Added info on Alarms. Modified Chapter “Power control for external sensors”...
-
Page 3: Table Of Contents
USER MANUAL – RTU-LP-ST Table of contents SENECA RTU-LP ........................ 6 PRELIMINARY INFORMATION ..................6 1. CHARACTERISTICS ....................8 1.1. RTU-LP characteristics ............................ 8 1.2. Digital Inputs ..............................9 1.3. Digital outputs ............................... 9 1.4. Analog Inputs ..............................9 1.5. - Page 4 CT - Change Address book Telephone numbers .....................32 10.5. AZ – Action Command ...........................32 10.6. AZ – Synchronize DATE/HOUR ........................33 10.7. CL - Change Events Label ..........................34 10.8. ES - SMS 0 EXTERNAL EVENT .........................36 SOFTWARE CONFIGURATION: EASY RTU-LP ........... 36 FIRMWARE UPDATE....................37...
- Page 5 USER MANUAL – RTU-LP-ST ENERGY ANALYSIS ....................37...
-
Page 6: Seneca Rtu-Lp
CAUTION! -Contact your telephone service provider for GSM and GPRS service costs especially when using RTU-LP with a sim issued by a country other than the one in which it is used (international roaming). -It is best to estimate telephone costs before setting up LP-RTU. - Page 7 (from 5 to 30 seconds) and the time due to any server login attempts. -Check the data quantity sent via internet and SMS before using RTU-LP. Please remember that mobile phone service providers also consider the entire communication that permits file transmission (and thus data transmission overhead, the number of connection attempts, etc.) and not just the dimensions as data traffic in each transaction.
-
Page 8: Characteristics
USER MANUAL – RTU-LP-ST 1. CHARACTERISTICS 1.1. RTU-LP characteristics Supply voltage 8..30 Vdc Digital Inputs isolation 500 Vdc MODEM: GSM/GPRS quad-band 850/900/1800/1900 MHz GPRS multi slot class 10 GPRS max. 86 kbps (DL) Coding scheme CS-1, CS-2, CS-3, CS-4 ... -
Page 9: Digital Inputs
USER MANUAL – RTU-LP-ST 1.2. Digital Inputs Channels number Rated Voltage 7 Vdc Rated Current 4 mA Maximum acquisition speed (frequency) 1 Hz Isolation from other circuits 500 V 1.3. Digital outputs Channels number Output type Bistable Relay (Reset and Set) -
Page 10: Communication Port
USER MANUAL – RTU-LP-ST 1.5. Communication Port RS232 DB9 PORT Protocol Modbus RTU Slave 1.6. Storage units Internal Flash 2 Mbytes for datalogger Internal EEprom 64 Kbytes for configuration 1.7. Power supply Voltage 8...30 Vdc Average Power consumption 3.7 mW Average (*) -
Page 11: Regulations
USER MANUAL – RTU-LP-ST No RS232 transmission 1.8. Regulations EN61000-6-4/2002-10 Electromagnetic emission, industrial environment. EN61000-6-2/2006-10 Electromagnetic immunity, industrial environment. EN 301 511 Harmonized standard for mobile stations in the 900 and 1800 bands. EN 301 489-1 ElectroMagnetic Compatibility standard for radio equipment and services. -
Page 12: Analog Input Connections
USER MANUAL – RTU-LP-ST 2.2. Analog input connections Voltage and current connections can be connected like in picture: 2.3. Auxiliary voltage connections The device can provide up to 100mA (protected) to an external sensor connected to terminals (+) and (-). -
Page 13: Serial Communication Rs232 Ports Connections
USER MANUAL – RTU-LP-ST 2.4. Serial communication RS232 ports connections The RS232 PORT is in standard DB9 format: PIN 5 = GND PIN 3 = TX PIN 2 = RX 2.5. Digital outputs connections The output relay is connected between terminals like in picture:... -
Page 14: Power Control For External Sensors
Seneca recommends to use an external battery (rechargeable) for power up external sensors, the power is connected to the sensor 1 through the DO1 and to the sensor2 through DO2. There is no need to command the DO because the firmware can power up autonomously the sensors before reading. -
Page 15: Signal Leds
USER MANUAL – RTU-LP-ST A 32 bits counters is available for each digital input. The maximum acquisition speed is 1 Hz. Digital Inputs have a 500V galvanic isolation between others circuits. 3. SIGNAL LEDS 3.1. GSM led The GSM status led has the following meanings:... -
Page 16: Device Overview
USER MANUAL – RTU-LP-ST 4. DEVICE OVERVIEW The RTU-LP-ST is an ultra low power device, the RTU is always sleeping (with the modem OFF) but when an event is registered the RTU can Wake-up and send data. It’s also possible to configure the device to send data at a time interval or wake up the board at fixed time leaving the modem ON for minutes (for receiving commands). -
Page 17: Wake Up Window
USER MANUAL – RTU-LP-ST 5. WAKE UP WINDOW When the RTU is in sleep mode the SMS cannot be reached because the modem is switched off for energy saving purpose. For sending command SMS to the RTU it’s possible to configure a wake-up window where the RTU can switch ON the modem and read/execute the command SMS. - Page 18 USER MANUAL – RTU-LP-ST T: totalizers values: dddddddddd = Totalizer 1 value eeeeeeeeeee = Totalizer 2 value ffffffffff = Totalizer 3 value gggggggggg= Totalizer 4 value BAT: Battery Voltage xx.xV battery Voltage measured with modem in ON state TEMP: Temperature xx.xC Temperature in °C...
-
Page 19: Real Time Events
USER MANUAL – RTU-LP-ST Battery Voltage = 10.6V Temperature = 22.4°C GSM Field Minimum Value =1 GSM Field Medium Value =1 GSM Field Maximum Value =1 Send Timestamp = 04 /May /2017 at 15:55 6. REAL TIME EVENTS Real Time events can be configured for to be sent immediately afterwards the event, or to be logged in a “FILE1”... - Page 20 USER MANUAL – RTU-LP-ST DIN4 : Switched to logic level 0 DIN1 : Switched to logic level 1 DIN2 : Switched to logic level 1 DIN3 : Switched to logic level 1 DIN4 : Switched to logic level 1 AIN1 < MIN AIN2 <...
- Page 21 USER MANUAL – RTU-LP-ST a=in1 value b=in2 value c= in3 value d= in4 value e=Out1 value f= Out2 value 1> AIN1 value gggggg= AIN1 value in % from 0 (0%) to 10000 (100.00%) 2> AIN2 value Hhhhhh = AIN2 value in % from 0 (0%) to 10000 (100.00%)
-
Page 22: Real Time Events Ftp File
USER MANUAL – RTU-LP-ST For example: EV 31 REBOOT D> 11110010 1> +1797 2> -2500 T: 0 3354 1144 0 BAT:10.6V TEMP:22.4C CSQ 1,1,1 / 0405171555:0001 This means: Event 31 = RTU RESET Text Label for Event 31 = “REBOOT”... - Page 23 USER MANUAL – RTU-LP-ST Where: RTUNAME: is the RTU Name configured with Easy RTU-LP Software RTUCODE: is the numerical RTU code configured with Easy RTU-LP Software YYYY-MM-DD_HH-MM: it’s the date/hour of the event KKKK: is a progressive alphanumerical code A file name example is: MRTU10001_2017-05-08_11-49_042B.csv...
-
Page 24: Analog Inputs Log Ftp File (File0)
120*2=240 Rows of data, so will be created 4 files). The FTP file name is : RTUNAMERTUCODE_YYYY-MM-DD_HH-MM_KKKK_File0.csv Where: RTUNAME: is the RTU Name configured with Easy RTU-LP Software RTUCODE: is the numerical RTU code configured with Easy RTU-LP Software YYYY-MM-DD_HH-MM: it’s the date/hour of the dispatch... -
Page 25: Analog Inputs Log Data Buffering
USER MANUAL – RTU-LP-ST KKKK: is a progressive alphanumerical code File0: is a constant An example file name is: MRTU10001_2017-05-08_13-48_042C_File0.csv The File contents is of this type: DATE TIME AIN1 AIN2 08/05/2017 13.48.09 1797 2500 08/05/2017 13.48.39 1797 2500 08/05/2017 13.49.09... - Page 26 RTUNAMERTUCODE_YYYY-MM-DD_HH-MM_KKKK_File1.csv Where: RTUNAME: is the RTU Name configured with Easy RTU-LP Software RTUCODE: is the numerical RTU code configured with Easy RTU-LP Software YYYY-MM-DD_HH-MM: it’s the date/hour of the dispatch KKKK: is a progressive alphanumerical code File0: is a constant An example file name is: MRTU10001_2017-05-08_13-48_042C_File1.csv...
- Page 27 USER MANUAL – RTU-LP-ST EVENT EQUIVALENT EVENT NR DESCRIPTION DIN1 : Switched to logic level 0 DIN2 : Switched to logic level 0 DIN3 : Switched to logic level 0 DIN4 : Switched to logic level 0 DIN1 : Switched to logic...
-
Page 28: Events Log Data Buffering
USER MANUAL – RTU-LP-ST 40 0000 TOT3 Reset/Overflow (0000) 80 0000 TOT4 Reset/Overflow (0000) 100 0000 SMS 0 (event SMS0) 400 0000 Timer Seconds (count of seconds) 2000 0000 Timer Day 4000 0000 RTU LOW BATTERY 8000 0000 RTU RESET 8.1. -
Page 29: Modbus Rtu Addresses Table
USER MANUAL – RTU-LP-ST 16 Write Multiple Registers (Max 16 registers) 9.1. MODBUS RTU ADDRESSES TABLE ADDRRESS OFFSET REGISTER TYPE RO/RW INFO Analog Channel 1 value (in Scale CH01_MEASURE 40001 Signed 16 bits From -10000 (-100.00%) to +10000 (+100.00 %) -
Page 30: Supported Sms Commands
USER MANUAL – RTU-LP-ST 40007 TOTALIZER 1 LSW Unsigned 32 Bits Totalizer 1 value 40008 TOTALIZER 1 MSW 40009 TOTALIZER 2 LSW Unsigned 32 Bits Totalizer 2 value 40010 TOTALIZER 2 MSW 40011 TOTALIZER 3 LSW Unsigned 32 Bits Totalizer 3 value... -
Page 31: Setting The Telephone Sms Character Alphabet
Setting the Telephone SMS Character Alphabet Some Smartphones send SMS with UNICODE characters instead of using the GSM alphabet. RTU-LP only runs SMS commands with GSM alphabet. In most cases, SMS characters are set to AUTO alphabet by default. If the RTU does not recognise any SMS command, check the alphabet used by the phone. -
Page 32: Ct - Change Address Book Telephone Numbers
USER MANUAL – RTU-LP-ST eeeee = Analog 1 MINIMUM THRESHOLD (in % of the scale, for example 8000 = 80.00%) fffff = Analog 2 MAXIMUM THRESHOLD (in % of the scale, for example 8000 = 80.00%) kkkkk = Analog 2 MINIMUM THRESHOLD (in % of the scale, for example 8000 = 80.00%) -
Page 33: Az - Synchronize Date/Hour
USER MANUAL – RTU-LP-ST ACTION CODE INFO OUT 1 RESET OUT 2 RESET OUT 1 SET OUT 2 SET OUT 1 TOGGLE OUT 2 TOGGLE OUT 1 START PULSE OUT 2 START PULSE TOTALIZER 1 RESET TO 0 TOTALIZER 2 RESET TO 0... -
Page 34: Cl - Change Events Label
USER MANUAL – RTU-LP-ST Add or subtract ±aaaa years to actual date Add or subtract ±MM months to actual date Add or subtract ±dd months to actual date Add or subtract ±hh hours to actual time Add or subtract ±mm minutes to actual time Add or subtract ±ss seconds to actual time... - Page 35 USER MANUAL – RTU-LP-ST DIN4 : Switched to logic level 0 DIN1 : Switched to logic level 1 DIN2 : Switched to logic level 1 DIN3 : Switched to logic level 1 DIN4 : Switched to logic level 1 AIN1 < MIN AIN2 <...
-
Page 36: Es - Sms 0 External Event
ES 0 1005171102 Generate an external real time event NR 24 SOFTWARE CONFIGURATION: EASY RTU-LP For configuring the RTU-LP-ST you must use the Easy RTU LP software and the “CONF” cable (supplied). You can download the free software from the www.seneca.it... -
Page 37: Firmware Update
FIRMWARE UPDATE In order to include new functions, the system includes a firmware update option. For updating the firmware use the Easy RTU-LP software and the “UPDATE” cable (supplied). For updating the firmware the firmware update cable must be used. - Page 38 USER MANUAL – RTU-LP-ST 0.525 mAh + (0.375mA*24h)=9.525 mAh And so, sending one SMS every day the total consumption is : 10400 mAh/9.525mAh for day= more than 1091 days = about 3 years CAUTION! If the GSM field is low the RTU can try up to 3 times to send a SMS or a file in FTP.
