Proscend 130
ADSL2+/VDSL2 WLAN Router
User Manual
Version 0.02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 130 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Proscend 130

Summary of Contents for Proscend 130

  • Page 1 Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual Version 0.02...

  • Page 2: Table Of Contents

    DHCP ..............................30 ADVANCED SETUP ..........................31 ............................ 32 AYER NTERFACE 5.1.1 ATM Interface ..........................32 5.1.2 PTM Interface ..........................32 5.1.3 ETH WAN INTERFACE ........................32 WAN ..............................34 LAN ................................ 36 Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 3 ..........................73 OWER ANAGEMENT WIRELESS ..............................74 ............................... 74 ASIC ..............................76 ECURITY 6.2.1 WPS ............................... 78 MAC F ............................. 84 ILTER ............................85 IRELESS RIDGE ............................... 86 DVANCED ............................90 TATION Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 4 LAN Interface ..........................141 9.6.4 WLAN Interface ........................... 141 9.6.5 ATM Attributes ..........................142 9.6.6 PTM Attributes ..........................142 9.6.7 Management ..........................142 9.6.8 Network Protocol ........................142 9.6.9 QoS .............................. 142 Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 5 NAT/NAPT ........................... 143 9.6.12 Security Functions........................143 9.6.13 Application Layer Gateway ......................143 9.6.14 Power Supply ..........................143 9.6.15 Environment Condition ........................ 143 9.6.16 Dimensions ..........................143 9.6.17 Kit Weight ............................ 143 Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 6: Introduction

    WLAN switch on the front panel. 1.1.2 Fast Wired Connections The Proscend 130 features ADSL2+ and VDSL2 (17a) with auto-switching based on DSLAM settings. Four fast Ethernet ports support LAN traffic at speeds of up to 100 Mbps, and the integrated USB 2.0 Host port supports printer server.

  • Page 7: Remote Management

    Other management options include telnet, ssh and a web user interface with advanced functionality. Application The following diagram depicts a typical application of the Proscend 130 Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 8: Installation

    If the problem persists, contact for technical support. Caution 2: Before servicing or disassembling this equipment, disconnect all power cords and telephone lines from their outlets. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 9: Front Panel

    NOTE: If pressed down for more than 20 seconds, the Proscend 130 will go into a firmware update state (boot mode). The firmware can then be updated using an Internet browser pointed to the default IP address.

  • Page 10: Led Indicators

    WPS push button mode. When WPS is available the WPS LED will be ON. LED Indicators The front panel LED indicators are shown below and explained in the following table. This information can be used to check the status of the device and its connections. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 11 ADSL2+/VDSL2 Link is not established. A/VDSL Green Blink ADSL2+/VDSL2 Link is training. An Ethernet Link is established. Green Gb ETH An Ethernet Link is not established. Blink Data transmitting or receiving over LAN. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 12: Web User Interface

    The factory default configuration can be restored either by pushing the reset button for more than five seconds until the power indicates LED blinking or by clicking the Restore Default Configuration option in the Restore Settings screen. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 13: Ip Configuration

    IP Configuration 3.2.1 DHCP MODE When the Proscend 130 powers up, the onboard DHCP server will switch on. Basically, the DHCP server issues and reserves IP addresses for LAN devices, such as your PC. To obtain an IP address from the DCHP server, follow the steps provided below.

  • Page 14: Static Ip Mode

    STEP 3: Change the IP address to the 192.168.1.x (1<x<255) subnet with subnet mask of 255.255.255.0. The screen should now display as shown below. STEP 4: Click OK to submit these settings. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 15: Login Procedure

    3.1 Default Settings. Click OK to continue. NOTE: The login password can be changed later. STEP 3: After successfully logging in for the first time, you will reach the start screen. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 16 Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 17: Device Information

    Device Info is the first selection on the main menu so it will be discussed first. Subsequent chapters will introduce the other main menu options in sequence. The Device Info Summary screen displays at startup. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 18 This screen shows hardware, software, IP settings and other related information. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 19: Wan

    Shows Internet Group Management Protocol (IGMP) status Shows Multicast Listener Discovery (MLD) status Shows Network Address Translation (NAT) status Firewall Shows the status of Firewall Status Lists the status of DSL link IPv4 Address Shows WAN IPv4 address Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 20: Statistics

    Number of Bytes - Pkts Number of Packets - Errs Number of packets with errors - Drops Number of dropped packets 4.2.2 WAN Statistics This screen shows data traffic statistics for each WAN interface. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 21: Atm Statistics

    PTI values are discarded, they are also counted here. In Hec Errors Number of cells received with an ATM Cell Header HEC error In Invalid Vpi Vci Errors Number of cells received with an unregistered VCC address. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 22 Number of PDUs discarded because the PDU length was less than the size of the AAL5 trailer Length Errors Number of PDUs discarded because the PDU length did not match the length in the AAL5 trailer Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 23: Xdsl Statistics

    4.2.4 xDSL Statistics The xDSL Statistics screen displays information corresponding to the xDSL type. The two examples below (VDSL2 & ADSL2+) show this variation. VDSL2 Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 24 G.Dmt, G.lite, T1.413, ADSL2, ADSL2+ Traffic Type Channel type Interleave or Fast Status Lists the status of the DSL link Link Power State Link output power state. Line Coding (Trellis) Trellis On/Off Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 25 Ratio of FEC over PMD Data Frame length Number of bits in PMD Data Frame The interleaver depth Delay The delay in milliseconds (msec) DMT symbol In G.DMT mode, the following section is inserted. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 26 Total number of ATM data cells Bit Errors Total number of bit errors Total ES Total Number of Errored Seconds Total SES Total Number of Severely Errored Seconds Total UAS Total Number of Unavailable Seconds Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 27 Click Start to start the test or click Close to cancel the test. After the BER testing is complete, the pop-up window will display as follows. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 28 TONE GRAPH Click Draw Tone Graph on the xDSL Statistics screen and a pop-up window will display the xDSL bits per tone status, as shown below. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 29: Route

    Route Choose Route to display the routes that the Proscend 130 has found. Field Description Destination Destination network or destination host Gateway Next hub IP address Subnet Mask Subnet Mask of Destination Flag U: route is up ! : reject route...

  • Page 30: Arp

    Click ARP to display the ARP information. Field Description IP address Shows IP address of host pc Flags Complete, Incomplete, Permanent, or Publish HW Address Shows the MAC address of host pc Device Shows the connection interface Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 31: Dhcp

    Shows the device/host/PC network name MAC Address Shows the Ethernet MAC address of the device/host/PC IP Address Shows IP address of device/host/PC Expires In Shows how much time is left for each DHCP Lease Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 32: Advanced Setup

    5.4 IPv6 LAN Host 5.5 NAT 5.6 Security 5.7 Parental Control 5.8 Quality of Service (QoS) 5.9 Routing 5.10 DNS 5.11 DSL 5.12 UPnP 5.13 DNS Proxy 5.14 Interface Grouping 5.15 Certificate 5.16 Power Management Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 33: Layer 2 Interface

    Click Add to create a new connection . To remove a connection, select its Remove column radio button and click Remove. 5.1.3 ETH WAN INTERFACE This screen displays the Ethernet WAN Interface configuration. NOTE: This option only applies to models with an Ethernet WAN port. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 34 Click Add to create a new connection. NOTE: One Ethernet WAN interface can be created and saved in flash memory. To remove a connection, select its Remove column radio button and click remove. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 35: Wan

    Remove Select interfaces to remove To remove a connection, select its Remove column radio button and click Remove. To Add a new WAN connection, click the Add button and follow the instructions. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 36 NOTE: Up to 16 PVC profiles can be configured and saved in flash memory. Also, ETH and PTM/ATM service connections cannot coexist. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 37: Lan

    – even if IGMP snooping is enabled. Blocking Mode: In blocking mode, the multicast data traffic will be blocked and not flood to all bridge ports when there are no client subscriptions to any multicast group. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 38 DHCP server will provide the IP address. This option is hidden if NAT is enabled or when the router is configured with only one Bridge PVC. LAN INTERFACE To configure a secondary IP address, tick the checkbox outlined below. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 39 IP Address: Enter the secondary IP address for the LAN port. Subnet Mask: Enter the secondary subnet mask for the LAN port. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 40: Ipv6 Lan Host

    – even if snooping is enabled. Blocking Mode: In blocking mode, the multicast data traffic will be blocked and not flood to all bridge ports when there are no client subscriptions to any multicast group. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 41: Nat

    LAN side. A maximum of 32 entries can be configured. To add a Virtual Server, click Add. The following will be displayed. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 42 When a service is selected the port ranges are automatically configured Internal Port End Enter the internal port ending number (when you select Custom Server). When a service is selected, the port ranges are automatically configured. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 43: Port Triggering

    LAN side using the 'Open Ports'. A maximum 32 entries can be configured. To add a Trigger Port, click Add. The following will be displayed. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 44 Open Port End Enter the ending open port number (when you select custom application). When an application is selected, the port ranges are automatically configured. Open Protocol TCP, TCP/UDP, or UDP. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 45: Dmz Host

    Virtual Servers table to the DMZ host computer. To Activate the DMZ host, enter the DMZ host IP address and click Save/Apply. To Deactivate the DMZ host, clear the IP address field and click Save/Apply. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 46: Security

    By default, all outgoing IP traffic is allowed, but IP traffic can be blocked with filters. To add a filter (to block some outgoing IP traffic), click the Add button. On the following screen, enter your filter criteria and then click Apply/Save. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 47 Enter destination subnet mask. Destination Port (port or port:port) Enter destination port number or range. INCOMING IP FILTER By default, all incoming IP traffic is blocked, but IP traffic can be allowed with filters. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 48 At the bottom of this screen, select the WAN and LAN Interfaces to which the filter rule will apply. You may select all or just a subset. WAN interfaces in bridge mode or without firewall enabled are not available. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 49: Mac Filtering

    Each network device has a unique 48-bit MAC address. This can be used to filter (block or forward) packets based on the originating device. MAC filtering policy and rules for the Proscend 130 can be set according to the following procedure.
  • Page 50 Destination MAC Address Defines the destination MAC address Source MAC Address Defines the source MAC address Frame Direction Select the incoming/outgoing packet interface WAN Interfaces Applies the filter to the selected bridge interface. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 51: Parental Control

    User Name: A user-defined label for this restriction. Browser's MAC Address: MAC address of the PC running the browser. Other MAC Address: MAC address of another LAN device. Days of the Week: The days the restrictions apply. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 52: Url Filter

    A maximum of 100 entries can be added to the URL Filter list. Tick the Exclude radio button to deny access to the websites listed. Tick the Include radio button to restrict access to only those listed websites. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 53: Quality Of Service (Qos)

    Default Differentiated Services Code Point (DSCP) Mark: This specifies the per hop behavior for a given flow of packets in the Internet Protocol (IP) header that do not match any other QoS rule. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 54: Queue Configuration

    This function follows the Differentiated Services rule of IP QoS. You can create a new Queue entry by clicking the Add button. Enable and assign an interface and precedence on the next screen. Click Save/Reboot on this screen to activate it. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 55 Interface: Assign the entry to a specific network interface (QoS enabled). Precedence: Configure precedence for the Queue entry. Lower integer values for precedence imply higher priority for this entry relative to others. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 56: Qos Classification

    IP header DSCP byte. A rule consists of a class name and at least one logical condition. All the conditions specified in the rule must be satisfied for it to take effect. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 57 Mark 802.1p Priority Select between 0-7. Lower values have higher priority. Tag VLAN ID Enter a 802.1Q VLAN ID tag [2-4094] Set Rate Control The data transmission rate limit in kbps. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 58: Routing

    5.9.2 Static Route This option allows for the configuration of static routes by destination IP. Click Add to create a static route or click Remove to delete a static route. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 59: Policy Routing

    This option allows for the configuration of static routes by policy. Click Add to create a routing policy or Remove to delete one. On the following screen, complete the form and click Save/Apply to create a policy. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 60: Rip

    Click Add to create a static route or click Remove to delete a static route. After clicking Add the following screen will display. Enter Destination IPv6 Address, Subnet Prefix Length, Gateway IPv6 Address, and/or WAN Interface before clicking Save/Apply to add a routing entry. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 61: Dns

    The Dynamic DNS service allows you to map a dynamic IP address to a static hostname in any of many domains, allowing the Proscend 130 to be more easily accessed from various locations on the Internet. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 62 Enter the name of the dynamic DNS server Interface Select the interface from the list Username Enter the username of the dynamic DNS server Password Enter the password of the dynamic DNS server Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 63: Dsl

    5.11 DSL The DSL Settings screen allows for the selection of DSL modulation modes. For optimum performance, the modes selected should match those of your ISP. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 64 Tone Selection. Click Apply to implement these settings and return to the previous screen. On this screen you select the tones you want activated, then click Apply and Close. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 65 Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 66: Upnp

    5.12 UPnP Select the checkbox provided and click Apply/Save to enable UPnP protocol. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 67: Dns Proxy

    This can be used to access the WUI with a local name rather than by using the router IP address. The figure below shows an example of this. In the browser address bar (circled in red) the prefix “http://" is added to the local name “proscend.Home” [Host.Domain] for WUI access. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 68: Interface Grouping

    IP interface. To add an Interface Group, click the Add button. The following screen will appear. It lists the available and grouped interfaces. Follow the instructions shown here. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 69 IP set-top box (video). The LAN interfaces are ENET1, ENET2, ENET3, and ENET4. The Interface Grouping configuration will be: 1. Default: ENET1, ENET2, ENET3, and ENET4. 2. Video: nas_0_36, nas_0_37, and nas_0_38. The DHCP vendor ID is "Video". Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 70 DHCP server. The Interface Grouping configuration will automatically change to the following: 1. Default: ENET2, ENET3, and ENET4. 2. Video: nas_0_36, nas_0_37, nas_0_38, and ENET1. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 71: Certificate

    Enter the required information and click Apply to generate a private key and a certificate-signing request. The following table is provided for your reference. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 72 Click Import Certificate to paste the certificate content and the private key provided by your vendor/ISP/ITSP into the corresponding boxes shown below. Enter a certificate name and click Apply to import the local certificate. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 73: Trusted Ca

    Click Import Certificate to paste the certificate content of your trusted CA. The CA certificate content will be provided by your vendor/ISP/ITSP and is used to authenticate the Auto-Configuration Server (ACS) that the CPE will connect to. Enter a certificate name and click Apply to import the CA certificate. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 74: Power Management

    5.16 Power Management This screen allows for control of hardware modules to evaluate power consumption. Use the buttons to select the desired option, click Apply and check the response. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 75: Wireless

    (also known as SSID, Service Set Identifier) and restrict the channel set based on country requirements. Click Save/Apply to apply the selected wireless options. Consult the table below for descriptions of these options. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 76 “Clients Isolation” and “Disable WMM Advertise”. Similarly, for Enable WMF, Max Clients and BSSID, consult the matching entries in this table. NOTE: Remote wireless hosts cannot scan Guest SSIDs. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 77: Security

    Select the wireless network name from the drop-down box. SSID stands for Service Set Identifier. All stations must be configured with the correct SSID to access the WLAN. If the SSID does not match, that client will not be granted access. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 78 RADIUS Server IP address, Port and Key fields. WEP Encryption will also be enabled as shown below. The settings for WPA authentication are shown below. The settings for WPA-PSK authentication are shown next. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 79: Wps

    Every WPS certified device has both a PIN number and a push button, located on the device or accessed through device software. The Proscend 130 has both a WPS button on the device and a virtual button accessible from the web user interface (WUI).
  • Page 80 Unconfigured is used when an external client assigns security settings to the Proscend 130. NOTES: Your client may or may not have the ability to provide security settings to the Proscend 130. If it does not, then you must set the WSC AP mode to Configured. Consult the device documentation to check its capabilities.
  • Page 81 Step 6: First method: WPS button Press the WPS button on the rear panel of the router. The WPS LED will blink to show that the router has begun searching for the client. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 82 Go to your WPS wireless client and activate the push-button function. A typical WPS client screenshot is shown below as an example. Now go to Step 8 (part IV. Check Connection) to check the WPS connection. IIIb. WPS – PIN CONFIGURATION Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 83 This is different from the External Registrar function provided in Windows Vista. The figure below provides an example of a WPS client PIN function in-progress. Now go to Step 8 (Check Connection) to check the WPS connection. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 84 The client software should show the status. The example below shows that the connection established successfully. You can also double-click the Wireless Network Connection icon from the Network Connections window (or the system tray) to confirm the status of the new connection. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 85: Mac Filter

    Every network device has a unique 48-bit MAC address. This is usually shown as xx.xx.xx.xx.xx.xx, where xx are hexadecimal numbers. After clicking the Add button, the following screen appears. Enter the MAC address in the box provided and click Save/Apply. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 86: Wireless Bridge

    Selecting Enabled or Enabled (Scan) enables wireless bridge restriction. Only those bridges selected in the Remote Bridges list will be granted access. Click Refresh to update the station list when Bridge Restrict is enabled. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 87: Advanced

    RTS threshold, set the wakeup interval for clients in power-save mode, set the beacon interval for the access point, set XPress mode and set whether short or long preambles are used. Click Save/Apply to set new advanced wireless options. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 88 Control Sideband Select Upper or Lower sideband when in 40GHz mode. 802.11n Rate Set the physical transmission rate (PHY). 802.11n Protection Turn Off for maximized throughput. Turn On for greater security. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 89 (and learn whether there are buffered frames at the access point). Global Max Clients The maximum number of clients that can connect to the router. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 90 Refers to the acknowledge policy used at the MAC level. Enabling no Acknowledgement Acknowledgement can result in more efficient throughput but higher error rates in a noisy Radio Frequency (RF) environment. WMM APSD This is Automatic Power Save Delivery. It saves power. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 91: Station Info

    If a station is idle for too long, it is removed from this list. Authorized Lists those devices with authorized access. SSID Lists which SSID of the modem that the stations connect to. Interface Lists which interface of the modem that the stations connect to. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 92: Diagnostics

    If a test displays a fail status, click the button to retest and confirm the error. If a test continues to fail, click Help and follow the troubleshooting procedures. The second Diagnostics screen (Fault Management) is used for VDSL diagnostics. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 93: Management

    This option recovers configuration files previously saved using Backup Settings. Enter the file name (including folder path) in the Settings File Name box, or press Browse… to search for the file, then click Update Settings to recover settings. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 94: Restore Default

    IP configuration to match any new settings. NOTE: This entry has the same effect as the Reset button. The Proscend 130 board hardware and the boot loader support the reset to default. If the Reset button is continuously pressed for more than 5 seconds, the boot loader will erase the configuration data saved in flash memory.

  • Page 95: System Log

    Indicates whether the system is currently recording events. The user can enable or disable event logging. By default, it is disabled. To enable it, select the Enable radio button and then click Apply/Save. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 96 When either Remote mode or Both modes is configured, the WEB UI will prompt the user to enter the Server IP address and Server UDP port. STEP 3: Click View System Log. The results are displayed as follows. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 97: Client

    URL. An HTTPS URL indicates that the ACS supports SSL. The “host” portion of this URL is used by the CPE for validating the certificate from the ACS when using certificate-based authentication. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 98 Password used to authenticate an ACS making a Connection Request to the CPE. IP address and port the ACS uses to connect to Proscend 130. The Get RPC Methods button forces the CPE to establish an immediate connection to the ACS. This may be used to discover the set of methods supported by the ACS or CPE.

  • Page 99: Internet Time

    Internet Time must be activated to use Parental Control. In addition, this menu item is not displayed when in Bridge mode since the router would not be able to connect to the NTP timeserver. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 100: Access Control

    Access Control 8.5.1 Passwords This screen is used to configure the user account access passwords for the device. Access to the Proscend 130 is controlled through the following three user accounts: root - unrestricted access to change and view the configuration.

  • Page 101: Update Software

    It is recommended that you compare the Software Version on the Device Information screen with the firmware version installed, to confirm the installation was successful. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 102: Reboot

    To save the current configuration and reboot the router, click Save/Reboot. NOTE: You may need to close the browser window and wait for 2 minutes before reopening it. It may also be necessary, to reset your PC IP configuration. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 103: Appendix

    This filter will Drop all TCP packets coming from the LAN with IP Address/Subnet Mask of 192.168.1.45/24 having a source port of 80 irrespective of the destination. All other packets will be Accepted. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 104 : UDP Policy : Allow Source IP Address : 218.168.219.45 Source Subnet Mask : 255.255.0.0 Source Port : 5060:6060 Dest. IP Address : 192.168.1.45 Dest. Sub. Mask : 255.255.255.0 Dest. Port : 6060:7070 Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 105 00:12:34:56:78:90 and Source MAC Address of 00:34:12:78:98:56. All other frames on this interface are dropped. DAYTIME PARENTAL CONTROL This feature restricts access of a selected LAN device to an outside Network through the Proscend 130, as per chosen days of the week and the chosen times. Example:...
  • Page 106 With this rule, a LAN device with MAC Address of 00:23:46:78:63:26 will have no access to the WAN on Mondays, Wednesdays, and Fridays, from 2pm to 7pm. On all other days and times, this device will have access to the outside Network. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 107: Ssh Client

    For LAN access, type: putty -ssh -l root 192.168.1.1 For WAN access, type: putty -ssh -l support WAN IP address NOTE: The WAN IP address can be found on the Device Info WAN screen Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 108: Wsc External Registrar

    Open the Network folder and look for the BroadcomAP icon. Step 3: On the Wireless Security screen, enable WSC by selecting Enabled from the drop down list box and set the WSC AP Mode to Unconfigured. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 109 Now return to the Network folder and click the BroadcomAP icon. A dialog box will appear asking for the Device PIN number. Enter the Device PIN as shown on the Wireless Security screen. Click Next. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 110: Printer Server

    Printer name and Make and model NOTE: The Printer name can be any text string up to 40 characters. The Make and model can be any text string up to 128 characters. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 111 Go to the Printers and Faxes application in the Control Panel and select the Add a printer function (as located on the side menu below). STEP 3: Click Next to continue when you see the dialog box below. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 112 Select Connect to a printer on the Internet and enter your printer link. (e.g. http://192.168.1.1:631/printers/hp3845) and click Next. NOTE: The printer name must be the same name entered in the ADSL modem WEB UI “printer server setting” as in step 1. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 113 STEP 6: Click Have Disk and insert the printer driver CD. STEP 7: Select driver file directory on CD-ROM and click OK. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 114 STEP 8: Once the printer name appears, click OK. STEP 9: Choose Yes or No for default printer setting and click Next. STEP 10: Click Finish. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 115 STEP 11: Check the status of printer from Windows Control Panel, printer window. Status should show as Ready. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 116: Connection Setup

    However, unlike the multiple connection modes described below, it supports all five connection types. The figure below shows the five connection types available in ATM default mode. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 117: Ptm Interfaces

    After adding WAN connections to an interface, you must also create an Interface Group to connect LAN/WAN interfaces. 9.5.2 PTM Interfaces Follow these procedures to configure a PTM interface. STEP 1: Go to Advanced Setup Layer2 Interface PTM Interface. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 118 To add WAN connections to one interface type, you must delete existing connections from the other interface type using the remove button. There are many settings that can be configured here including: DSL Latency, PTM Priority, Connection Mode and Quality of Service. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 119: Atm Interfaces

    This Router supports up to 16 ATM interfaces. STEP 4: Go to Advanced Setup Layer2 Interface ATM Interface. This table is provided here for ease of reference. Heading Description Interface WAN interface name. ATM VPI (0-255) ATM VCI (32-65535) Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 120 STEP 5: Click Add to proceed to the next screen. NOTE: To add WAN connections to one interface type, you must delete existing connections from the other interface type using the remove button. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 121: Ethernet Wan Interface

    0/35 in Default Mode with an EoA Link type is shown below. 9.5.4 Ethernet WAN Interface Some models of the Proscend 130 support a single Ethernet WAN interface over the ETH WAN port. Follow these procedures to configure an Ethernet WAN interface.
  • Page 122 STEP 3: Select a Connection Mode from the options shown above. STEP 4: Click Apply/Save to confirm your choice. The figure below shows an Ethernet WAN interface configured in Default Mode. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 123: Wan Connections

    9.5.5 WAN Connections In Default Mode, the Proscend 130 supports one WAN connection for each interface, up to a maximum of 8 connections. VLAN Mux and MSC support up to 16 connections. To setup a WAN connection follow these instructions.

  • Page 124: Ppp Over Ethernet (Pppoe)

    (6) IP over ATM (IPoA) The subsections that follow continue the WAN service setup procedure. 9.5.6 PPP over ETHERNET (PPPoE) STEP 1: Select the PPP over Ethernet radio button and click Next. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 125 IP address and port are mapped to the same external IP address and port. An external host can send a packet to the internal host, by sending a packet to the mapped external address. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 126 DIAL ON DEMAND The Proscend 130 can be configured to disconnect if there is no activity for a period of time by selecting the Dial on demand checkbox . You must also enter an inactivity timeout period in the range of 1 to 4320 minutes.
  • Page 127 When Enabled, this creates local PPPoE connections to the WAN side. Enable this option only if all LAN-side devices are running PPPoE clients, otherwise disable it. The Proscend 130 supports pass-through PPPoE sessions from the LAN side while simultaneously running a PPPoE client from non-PPPoE LAN devices...

  • Page 128: Ip Over Ethernet (Ipoe)

    You can select the Obtain an IP address automatically radio button to enable DHCP (use the DHCP Options only if necessary). However, if you prefer, you can instead use the Static IP address method to assign WAN IP address, Subnet Mask and Default Gateway manually. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 129 IP address and port are mapped to the same external IP address and port. An external host can send a packet to the internal host, by sending a packet to the mapped external address. ENABLE FIREWALL Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 130 Click Next to continue or click Back to return to the previous step. STEP 4: Select a WAN interface or enter a static IP address to the DNS Server. Click Next to continue or click Back to return to the previous step. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 131: Bridging

    The WAN Setup - Summary screen shows a preview of the WAN service you have configured. Check these settings and click Apply/Save if they are correct, or click Back to return to the previous screen. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 132: Ppp Over Atm (Pppoa)

    If this bridge connection is your only WAN service, your PC IP settings will need to be assigned statically, since the on-board DHCP server is not active in bridge mode. Similarly, the Proscend 130 cannot be accessed from the WAN, for remote management or technical support, since no WAN IP address is available.
  • Page 133 DIAL ON DEMAND The Proscend 130 can be configured to disconnect if there is no activity for a period of time by selecting the Dial on demand checkbox .
  • Page 134 Internet Group Membership Protocol (IGMP) multicast. IGMP is a protocol used by IP hosts to report their multicast group memberships to any neighboring multicast routers. STEP 3: Select a WAN interface as the preferred default gateway route. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 135 Click Next to continue or click Back to return to the previous step. STEP 4: Select a WAN interface or enter a static IP address to the DNS Server. Click Next to continue or click Back to return to the previous step. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 136: Ip Over Atm (Ipoa)

    To activate it you must reboot. Go to Management Reboot and click Reboot. 9.5.10 IP over ATM (IPoA) STEP 1: Click Next to continue. STEP 2: Enter the WAN IP settings provided by your ISP. Click Next to continue. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 137 Internet Group Membership Protocol (IGMP) multicast. IGMP is a protocol used by IP hosts to report their multicast group memberships to any neighboring multicast routers. STEP 4: Select a WAN interface as the preferred default gateway route. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 138 The WAN Setup - Summary screen shows a preview of the WAN service you have configured. Check these settings and click Apply/Save if they are correct, or click Back to modify them. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 139: More About Msc Mode

    The procedure for WAN connection setup in MSC mode is as follows: STEP 1: Create a Layer2 interface in MSC connection mode. STEP 2: Add WAN connections to the interface (IPoE or PPPoE). Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 140 Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 141 If a MSC connection is removed every other MSC connection should be removed to avoid potential configuration problems. STEP 3: Add an interface Grouping (MSC1) to connect LAN and WAN interfaces. See the instructions in Interface Grouping for help with this final step. Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 142: Specifications

    11 Channels (US, Canada)/ 13 Channels (Europe)/ 14 Channels (Japan) Up to 300Mbps data rate Multiple BSSID MAC address filtering, WDS, WEP, WPA, WPA2, IEEE 802.1x 10,25,50,100mW@22MHz channel bandwidth output power level can be selected according to the environment Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

  • Page 143: Atm Attributes

    DHCP Server/Client/Relay, DNS Relay, Dynamic DNS, IPv6 subset 9.6.9 QoS Packet level QoS classification rules priority queuing using ATM TX queues IP TOS/Precedence 802.1p marking DiffServ DSCP marking Src/dest MAC addresses classification Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...
  • Page 144 9.6.16 Dimensions 205mm(W) X 48mm(H) X 145mm(D) 9.6.17 Kit Weight (1*Proscend 130, 2* Antenna, 1*RJ11 cable, 1*RJ45 cable, 1*power adapter, 1*CD-ROM) = 1.0 kg NOTE: Specifications are subject to change without notice Proscend 130 ADSL2+/VDSL2 WLAN Router User Manual V0.02...

Table of Contents
