SPECIFICATIONS
LEGEND II PLUS
Channels
Modulation
Frequency Range
Frequency Tolerance
Input Voltage
Dimensions
Weight
Antenna Impedance
Maximum Output Power
Transmission Interference
Audio Response
Emitted Power in the Adj. Channel
Microphone Sensitivity
Modulated Signal Distortion
Max. Sensitivity at 20dB Sinad
Frequency Image Rejection Rate
Adjacent Channel Selectivity
Intermediate Frequency Rej. Rate
Squelch Sensitivity
Frequency Response
Maximum Audio Power
All stated specifi cations are subject to change without notice or obligation.
All stated specifi cations are subject to change without notice or obligation.
16
Drain
Drain
General
26.965 - 27.405 MHz
13.2V DC
125(L) x 38(H) x 126.5(D) mm
Approx. 0.6 kg
Transmitter
300Hz to 3KHz
<1.8A (with modulation)
Receiver
Min. <0.5µV; Max. =1mV
300Hz to 3KHz
40
FM/AM
+/-200Hz
50Ω
4W
<4nW
<20µW
7mW
3%
<1µV
>60dB
>60dB
>60dB
<700mA
>2W
