4.4 S/RF meter

S/RF meter indicates the receiving signal strength in RX mode, and it is
used as RF power indicator in TX mode. S/RF meter indicators have 4
steps from 1 (weak) to 4 (strong).

4.5 Channel select

➥ Push or push and hold
channel switch knob either clockwise or counterclockwise.

4.6 Adjusting RF gain

Reduce the reception
of strong signals

4.7 Emergency channel select

➥ Push and hold the
instantly these emergency channels.
NOTE:
The channel selector unable to select the channel once emergency
channel selected.

4.8 Hi-Cut select

Switch Hi-Cut mode select switch to ON to reduce high frequency
noise when reception is noisy due to long distance.
/
keys on the microphone or turn the
[UP]
[DN]
Turn the RF gain knob counterclockwise
to reduce the reception of strong signals.
key in the microphone to activate
[CH9/19]
BASIC OPERATION
13
