Imensions; Sh090-105-120-140* & 161 - Danfoss Performer SH090 Selection & Application Manuallines

A
PPLICATION GUIDELINES
SH090-105-120-140* & 161*
(* except code 3)
117
235
(1)
278
(2)
137
(1)
189
(2)
4 x hole
Ø 19.05
230
190.5
Ø 29
(1)
Ø 35
(2)
60°
8
D

IMENSIONS

Ø 224
Oil sight glass
94
(1)
101
(2)
230
190.5
30°
180
158
(1)
173
(2)
30°
Ø 22
FRCC.PC.007.B5.02
Equalisation line
94
(1)
101
(2)
154
SH090
(1)
SH105 - 120 - 140* & 161*
(2)
* except code 3
All dimensions in mm
Flexible grommet
Lock washer
Flat washer
Steel mounting
sleeve
Rubber grommet
482
(1)
540
(2)
451
(1)
509
(2)
Ø 243
HM 8 bolt
Nut
15 mm
