Card Capture Reader
IC-05
ASSEMBLY AND OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IC-05 and is the answer not in the manual?

Questions and answers

Related Manuals for PERCo IC-05

Summary of Contents for PERCo IC-05

  • Page 1 Card Capture Reader IC-05 ASSEMBLY AND OPERATION MANUAL...
  • Page 2 Card Capture Reader IC-05 Assembly and Operation Manual...

  • Page 3: Table Of Contents

    Troubleshooting ......................20 Maintenance ......................20 Appendix 1. Configuring the ACS-controller to work with the card reader in the PERCo-Web software ..............21 Appendix 2. Configuring in the Web interface CT/L-04.2, CT-03.2 for working with the card capture reader ..........26...

  • Page 4: Application

    OD – operating device. 1 APPLICATION The IC-05 card capture reader (hereinafter – the card capture reader) is designed to operate within PERCo-Web system as a device for reading, capturing and keeping proximity cards issued to visitors and meant for return at exit (hereinafter – guest cards). It allows you to withdraw cards along with the standard clips for badges.

  • Page 5: Technical Specifications

    Assembly and Operation Manual 3 TECHNICAL SPECIFICATIONS DC operating voltage ..................12±1.2 V DC Current consumption ................not more than 1.8 Power consumption .................... max. 22 W Card container capacity ..................350 cards Interface of the reader’s connection with a controller ....... RS-485, Wiegand Mean time before failure ...............

  • Page 6: Delivery Set

    IC-05 Card Capture Reader 4 DELIVERY SET 4.1 Standard delivery set Main equipment: Card capture reader ....................1 Container lock key ....................2 Mounting hardware: Nylon cable tie 100 mm ................... 4 Self-adhesive cable tie mount ................. 3 Technical documentation: Certificate ........................
  • Page 7 Assembly and Operation Manual Figure 2. Overall view Standard delivery set: 1 – housing; 2 – cover; 3 – card container; 4 – card container lock; 5 – slot for guest cards capture; 6 – base; 10 – cover fixing screws (located under the container) Not included in the standard delivery set: 7 –...

  • Page 8: Design

    IC-05 Card Capture Reader 5.2 Design The design of the card capture reader is shown in Figure 2. Numbers of the items hereinafter refer to the item numbers as shown in Figure 2. The housing of the card capture reader (1) is fixed on the base (6) with the screws. The front side of the housing holds the container for receiving cards (3) and has a lock (4).

  • Page 9: Parameters Of Signals

    Assembly and Operation Manual XT9 – connection for the power supply of the reader of the card capture reader (contacts +12V and GND). Figure 4. Card capture reader control board 5.3 Parameters of signals “Capture card” input (contact 1of XT1 connector block) is controlled by the output of the ACS-controller, type “dry contact"...

  • Page 10: Operation Algorithm

    ..........not more than 1.5 mA Note: If PERCo turnstile is used as an OD, then it is possible to control “LED” inputs of the card capture reader directly from the external indicator control output (XT5 “Light B”...

  • Page 11: The Use Of The Card Capture Reader In A Third-Party Acs (With Wiegand)

    In this case, it is recommended to contact your nearest PERCo service center. The list of PERCo service centers is given in the datasheet.

  • Page 12: Marking And Packaging

    IC-05 Card Capture Reader 6 MARKING AND PACKAGING The card capture reader has a marking - a label placed on the internal side of the back panel. It contains the name of the product, designation, the date of manufacture, the serial number.

  • Page 13: Installation Instructions

    Assembly and Operation Manual 8 INSTALLATION INSTRUCTIONS Attention! The manufacturer will not accept liability for any damage to the card capture reader or otherwise loss caused as a result of improper installation, and will dismiss any claims by the customer should the installation work be carried out not in accordance with this Manual.

  • Page 14: Cables Parameters

    IC-05 Card Capture Reader 8.3 Cables parameters The cables used for connection of the card capture reader are given in Table 1. Table 1. Recommended cable types № Connection Max. length, m Cable type Example Twisted pair cable with AWG 18; HO3VV-F 2×0.75 cross section min.
  • Page 15 Attention! Built-in reader should be purchased separately. Inside the card capture reader, it is possible to mount all PERCo readers. It is also possible to mount the readers by third-party manufacturers if they comply to the following technical requirements: - dimensions (length - width - height) .....

  • Page 16: Connection Layouts

    IC-05 Card Capture Reader After installation, turn on the power of the card capture reader (see sect. 9.1) and configure the ACS-controller in accordance with the card capture reader operation algorithm (see sect. 5.4) and with the service documentation of the ACS-controller.
  • Page 17 RS-485 interface Attention! If PERCo turnstile is used as an OD, then it is possible to control the indication of passage permission directly from the control board of the turnstile. In this case, connect the turnstile CLB Board output XT5, "Light B" (or XT4 "Light A" depending on the direction of the passage) to the input of the card capture reader XT4 "LED"...
  • Page 18 IC-05 Card Capture Reader Figure 8. Diagram for connecting the card capture reader to the ACS-controller via Wiegand interface The list indicated elements is given in the Table 2.

  • Page 19: Operation Instructions

    ACS-controller. The configuration procedure is described in the service documentation for the controller and ACS software, the card capture reader operation algorithm – see sect. 5.4. Configuration in the system PERCo – see Appendix 1. and Appendix 2. 9.2 Presenting an access card The access card is presented by inserting it into the slot (5) of the cover (2) in card capture reader.

  • Page 20: Permanent Card Of Staff

    IC-05 Card Capture Reader After withdrawal of the card, the indication of the slot will switch to the initial constant light mode, the green arrow will light up on the indication module – the passage permission indication, OD will unblock in the direction of the passage.

  • Page 21: Transportation And Storage

    11 TROUBLESHOOTING Possible faults to be corrected by the customers themselves are listed in Table 3. For faults not listed in Table 3 we advise to consult PERCo Technical Support Department. Table 3. Possible failures and troubleshooting Fault Probable cause...

  • Page 22: Appendix 1. Configuring The Acs-Controller To Work With The Card Reader In The Perco-Web Software

    1. Log into the system by using a Web browser (see PERCo-Web Administrator's manual). 2. Go to “Administration”  “Configuration” section by using the navigation bar.
  • Page 23 Assembly and Operation Manual 8. Switch to "Additional inputs" tab. 9. If the card capture reader acts as an external verification device for the controller (“Card captured” signal is sent to a separate input of the controller), then select "Additional input №…" (number of the input of the controller that is physically connected to the “Card captured”...
  • Page 24 IC-05 Card Capture Reader  configure response of the controller to the activation of the input number 5 by using the activation or normalization parameters of the outputs, for example, the activation of an additional output of the controller number 5 that is connected to...
  • Page 25 Assembly and Operation Manual - set "Remote control" value, if the “Card captured” output of the card capture reader is connected to the controller in parallel with the RC. In this case, it is also necessary to check "In “Control” mode" box from the left side of the "Remote control permission"...
  • Page 26 IC-05 Card Capture Reader  in the appeared list of additional outputs check "Additional output № 3" (number of the output that is connected to the “Capture card” input of the card capture reader): 18. In the left part of the tab, select "Withdraw the identificators of the visitors after the...

  • Page 27: Appendix 2. Configuring In The Web Interface Ct/L-04.2, Ct-03.2 For Working With The Card Capture Reader

    CT-03.2 for working with the card capture reader Attention! You can configure the most basic algorithm of cards withdrawal by using the Web interface. Advanced options are available in PERCo-Web software. CT/L-04 (CT- 03) controllers don't support operation with the card capture reader via Web- interface.
  • Page 28 IC-05 Card Capture Reader - "Direction:" – "1" or "2" (depending on the passage direction that is controlled by the card capture reader):  Set the following parameter values for the output that is physically connected to the “Capture card” input of the card capture reader: - "Normal state:"...
  • Page 29 Assembly and Operation Manual 4. Any free input of the controller can be used for receiving the “Alarm” signal sent by the card capture reader. It is necessary to set the type of response on the activation of this input, for example, blocking of the reader in the passage direction that is controlled by the card capture reader:...
  • Page 30 IC-05 Card Capture Reader Attention! If the passage permission indication of the card capture reader is controlled directly from the control board of the turnstile, then, it is not necessary to fulfill the requirements of this paragraph. Set the following values in the "Configuration"  "Edit"  "Physical contacts"...
  • Page 31 Assembly and Operation Manual Example of a overview of the sections "Internal response" and "Physical contacts" after configuration (template – “Turnstile” card capture reader controls the direction number “1”, “Input 6” and “Output 3” are used to control the card capture reader, “Input 5” is used receive the “Alarm”...
  • Page 32 IC-05 Card Capture Reader 6. Temporary cards for visitors can be issued in "Access cards" section of the Web- interface. First, include them into the main list of cards in the "Input" subsection, then in the "List" subsection, select the access card that should be issued for a visitor, and in the appeared window: ...
  • Page 33 PERCo Polytechnicheskaya str., 4, block 2 194021, Saint Petersburg Russia Tel: +7 812 247 04 64 E-mail: export@perco.com support@perco.com www.perco.com...
