- Page 1 Card Capture Reader IC02.1 ASSEMBLY AND OPERATION MANUAL...
- Page 2 Card Capture Reader IC-02.1 Assembly and Operation Manual...
-
Page 3: Table Of Contents
CONTENT Application........................3 Operation conditions ....................3 Technical specifications ....................4 Delivery set........................4 Standard delivery set ..................4 Optional equipment supplied on request.............4 Product description......................5 Main features ......................5 Design.........................7 ... -
Page 4: Application
The IC-02.1 card capture reader (hereinafter – the card capture reader) is designed to operate within PERCo-Web system as a device for reading, capturing and keeping proximity cards issued to visitors and meant for return at exit (hereinafter – guest cards). -
Page 5: Technical Specifications
Assembly and Operation Manual 3 TECHNICAL SPECIFICATIONS DC operating voltage ..................12±1.2 V DC Power consumption .................... max. 12 W Card container capacity ..................350 cards Access cards type ..................HID, EM-Marin Interface of the reader’s connection with a controller ..........RS-485 Card reading distance at the rated operating voltage: HID ...................... -
Page 6: Product Description
IC-02.1 card capture reader Figure 1. Overall dimensions of the card capture reader 5 PRODUCT DESCRIPTION 5.1 Main features Supports permanent cards (without capturing) and guest cards. The card capture reader is supplied with the safe voltage – no more than 14 V. ... - Page 7 Assembly and Operation Manual Figure 2. Overall view Standard delivery set: 1 – base; 2 – housing; 3 – panel; 4 – cover; 5 – indication module; 6 – slot for guest cards capture; 7 – electric drive with a shutter; 8 –...
-
Page 8: Design
IC-02.1 card capture reader 5.2 Design The design of the card capture reader is shown in Figure 2. Numbers of the items hereinafter refer to the item numbers as shown in Figure 2. The cover (4) houses: on the external side – an indication module (5) with 3 mnemonic indicators, (shown in Figure 3), on the internal side –... - Page 9 Assembly and Operation Manual Figure 4. Card capture reader control board...
-
Page 10: Control
If the container is free from cards but the card capture reader is still blocked a likely reason for this could be failure of the card capture reader units. It is recommended to apply to the PERCo Technical Support Department. -
Page 11: Marking And Packaging
Assembly and Operation Manual 6 MARKING AND PACKAGING The card capture reader has a marking - a label placed on the internal side of the back panel. It contains the name of the product, designation, the date of manufacture, the serial number. -
Page 12: Installation Instructions
IC-02.1 card capture reader 8 INSTALLATION INSTRUCTIONS 8.1 Installation details When installing the equipment, observe precautions (see Clause 7.1). Proper installation is critical to performance and serviceability of the card capture reader. We strongly advise to study this section before installation work, and follow the instructions to the latter. -
Page 13: Installation
Assembly and Operation Manual 8.4 Installation Further installation instructions are given with the earlier mentioned recommendations (see Clause 8.1) taken into account. Recommendations on preparation of mounting holes in the mounting surface are given with regard to “SORMAT” PFG IR 10 anchor bolts for solid concrete floors. - Page 14 IC-02.1 card capture reader the panel to the cover (4). Use the cables given in Table 1. The length of the cables ends that remain inside the card capture reader after their pulling should be enough for their further connection. It is recommended to secure all cables on the internal sides of the base (1) with cable ties and self-adhesive cable tie mounts Attention! Be extra cautious and careful when carrying out further works, make sure the card...
- Page 15 Assembly and Operation Manual Wiring diagram card capture reader - Figure 7. CT/L-04 controller Wiring diagram elements Table 2. Position Name Q-ty RC panel IC-02 card capture reader CT/L-04 controller Power supply Reader for opposite to the card capture reader direction Card capture reader power cable Cable for ACS controller connection Cable for connection of the reader installed in a card capture reader (RS-485)
-
Page 16: Software Configuration
IC-02.1 card capture reader 9 SOFTWARE CONFIGURATION After the card capture reader installation and power up it should be configured in PERCo- Web network software. In the connected controller Section «Administration» the following parameters should be set: 1. For controller Auxiliary output № 3, parameter Type set as Standard. Parameter Normal state set as Not energized: 2. - Page 17 Assembly and Operation Manual 2.2. Set the Waiting period for verification confirmation. Within that time the controller will wait for the “Card captured” signal. 2.3. For parameter Auxiliary outputs activated on VISITORS valid identifiers presentation set the Activation criterion as For the operation time. After that mark by flag Auxiliary output №...
-
Page 18: Power-Up
IC-02.1 card capture reader 10 POWER-UP 1. Connect power supply unit to the mains with voltage and frequency given in its Certificate. 2. Switch on the power supply unit. 3. The indication module will light up in accordance with operating mode set by ACS controller. -
Page 19: Presenting A Permanent Card
If the container is free from cards but the card capture reader is still blocked a likely reason for this could be failure of the card capture reader units. It is recommended to apply to the PERCo Technical Support Department. 11.4 Removal and installation of the card container To take out the card container (9) from the card capture reader proceed as follows: 1 Switch off the power supply of the card capture reader. -
Page 20: Transportation And Storage
13 TROUBLESHOOTING Possible faults to be corrected by the customers themselves are listed in Table 3. For faults not listed in Table 3 we advise to consult PERCo Technical Support Department. Table 3. Possible failures and troubleshooting Fault Probable cause... - Page 21 PERCo Polytechnicheskaya str., 4, block 2 194021, Saint Petersburg Russia Tel: +7 812 247 04 64 E-mail: export@perco.com support@perco.com www.perco.com...
