- Page 1 Proximity Card Reader RP-15.2 CERTIFICATE AND OPERATION MANUAL...
- Page 2 Proximity Card Reader RP-15.2 Certificate and Operation Manual ТС RU C-RU.МЛ02.В.00073 ТУ 4372-015-88226999-2013...
-
Page 3: Table Of Contents
7. INSTALLATION PROCEDURE ..................9 7.1. Features of installation ..................9 7.2. Tools and equipment required for installation..........10 7.3. The cables used.....................10 7.4. Assembly order ....................11 8. TROUBLESHOOTING....................12 9. PERCO WARRANTY.....................13 WARRANTY CARD ......................15 ... -
Page 4: General Information
RP-15.2 Proximity Card Reader 1. GENERAL INFORMATION Proximity card reader RP-15.2 (hereinafter – the reader) is designed for use in systems of identification, computing, access control etc. Operation of the reader is allowed at ambient air temperature from –40°С to +40°С and at relative air humidity of up to 95% at +30°С. -
Page 5: Technical Specifications
Resistance to mechanical factors, according to GOST17516-72 ........M4 Reader dimensions (without cable) ............. 1454623 mm Reader weight ....................max. 220 g 3. DELIVERY SET Reader RP-15.2 ......................1 Metal base-plate ......................1 Assembly set: Plastic dowels ..................... 4 ... -
Page 6: Product Description
RP-15.2 Proximity Card Reader 4. PRODUCT DESCRIPTION 4.1. Design Reader consists of a unit in plastic housing with two-color LED indicator on the front panel. For reader mounting a metal base-plate is included in delivery set. Reader protection from environmental exposures is ensured by covering its board with compound. Shield cable for reader connection is output on its rear side. -
Page 7: Operation Of The Reader Under Wiegand Interface
Certificate & Operation Manual Depending on the selected operation mode one of Wiegand interface formats supported by the reader is used for connection with external controller. Read er can be simultaneously used with controllers of different types. 4.3. Operation of the reader under Wiegand interface Data is transmitted to the external controller at one time, a synchronously, at the moment of first positive signal receipt from identifier. - Page 8 RP-15.2 Proximity Card Reader The identifier encoded signal includes the uneven number of bits (N/2 – non integer) The structure of output coded mark in Wiegand 26 (H10301) format is presented in Figure: 1 – Control bit (corresponds with the even parity for the next 12 bit data) 2 –...
-
Page 9: Configuration
Certificate & Operation Manual 5. CONFIGURATION 5.1. Indication setting Reader comes with a sound and LED indication. Two operation modes of LED indication are possible: «double line» – two line control and «single line» – one line control. As standard reader comes with a «single line» mode selected (one line control). Code reading is confirmed by momentary change of LED indicator colour from red to green (in «single line»... -
Page 10: Safety Requirements
Reader installation must be carried out by circuit installer. Before mounting and first switch-on carefully study the reader manual, order and details of reader adjustment to different PERCo units stipulated in corresponding sections of their operation manuals. Operation of the reader must be made in compliance with environmental requirements and power supply parameters stipulated in clause 1 and 2. -
Page 11: Tools And Equipment Required For Installation
Certificate & Operation Manual Figure 3. Reader installation behind the metal surface 7.2. Tools and equipment required for installation 1.2÷1.5kW hammer drill; Ø16 mm hard-alloy drill bits; Ø 5 mm hard-alloy drill bits; Phillips head screwdriver №2; ... -
Page 12: Assembly Order
RP-15.2 Proximity Card Reader Figure 4. RP-15.2 reader installation layout (reader housing is dotted) 7.4. Assembly order 1. Unpack the package and check the completeness of reader set. 2. Select the reader mounting place. 3. Make the marking and holes in mounting surface for fixing the base-plate and cable laying from the reader (Ref. -
Page 13: Troubleshooting
Certificate & Operation Manual Attention When mounting the reader please provide the cable bending radius of min. 10 mm at reader basis. 8. Run the cable, attach it and connect to external devices. Layout of reader connection to external devices under Wiegand interface is shown in Fig. 5. Switching the output data format is recommended to carry out directly at the junction of the regular reader cable with an extension cable (see section 5.2). -
Page 14: Perco Warranty
RP-15.2 Proximity Card Reader 9. PERCo WARRANTY PERCo (the Manufacturer) warrants that the RP-15.2 proximity card reader complies with applicable statutory safety requirements, electromagnetic compatibility provided that the instructions on storage, installation and operation, given in the Assembly & Operation Manual and shared PERCo readers and controllers operation documentation, are observed. - Page 15 PLEASE NOTE THAT PERCo PRODUCES TECHNICALLY SOPHISTICATED PRODUCTS THAT, IF NOT FAULTY, CANNOT BE RETURNED BACK IF BY SOME REASON THE CUSTOMER DEEMS THEM UNSATISFACTORY. The RP-15.2 proximity card reader is in conformity with the essential requirements EU’s Machinery, Low-Voltage Directives and carries the CE marking accordingly.
-
Page 16: Warranty Card
WARRANTY CARD RP-15.2 Proximity card reader Serial number Date of manufacture ____________________ 20___ Quality Control Seal _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Date of sale «... - Page 17 PERCo Polytechnicheskaya str., 4, block 2 194021, Saint Petersburg Russia Tel: +7 812 247 04 64 E-mail: export@perco.com support@perco.com www.perco.com...
