- Page 1 Proximity Card Reader IR-10 CERTIFICATE AND OPERATION MANUAL...
- Page 2 PERCo-Web system Proximity Card Reader IR-10 Certificate and Operation Manual TC RU C-RU.МЛ02.В.00273 ТУ 4372-040-88226999-2014...
-
Page 3: Table Of Contents
Selection of reader number in RS-485 interface............8 Operation in Wiegand mode ..................8 5.2.1 Indication setting ....................8 5.2.2 Changing the format of output data ..............9 INSTALLATION......................10 Safety requirements ....................10 Installation features .....................10 Tools and equipment required for installation............10 Required cables....................11 Installation sequence...................11 TROUBLESHOOTING ....................14 PERCO WARRANTY ....................15... -
Page 4: General Information
IR-10 Proximity Card Reader 1 GENERAL INFORMATION IR-10 long range proximity card reader (hereinafter– the reader) is designed for reading and interpretation of proximity card identifier and for transferring of identifier to ACS controller. The reader is designed for the use at automotive check-point. Up to four readers can be installed for each passage direction. -
Page 5: Technical Specifications
Certificate & Operation Manual 2 TECHNICAL SPECIFICATIONS Rated operating voltage ..................12 VDC Operating voltage limits ................10.8–14 VDC Consumption current ....................1.1 A Power consumption .................... max. 14 W Controller connection interface .............. RS-485, Wiegand Card reading distance at the rated operating voltage for different card types: HID ProxCard II cards ................ -
Page 6: Product Description
IR-10 Proximity Card Reader 4 PRODUCT DESCRIPTION 4.1 Design The reader consists of the unit in plastic housing, on the front side of which there are three indicators: green (top), yellow (central), red (down). The mounting arm included in the delivery set can be used for installation. -
Page 7: Data Transmitting Via Wiegand Interface
Certificate & Operation Manual Figure 2. Reader operation When the reader is switched on it radiates low frequency (125 kHz) electromagnetic field. Caught in this field the identifier is activated and starts transmitting individual encoded signal that is received by the reader. Reader transforms the received signal in accordance with an external device interface and sends it to controller of external device via RS-485 or Wiegand interfaces. - Page 8 IR-10 Proximity Card Reader All bytes are transmitted with high-order bits forward. The length of the coded mark depends on the output data format set at assembly and can be either fixed or specified by data dimension received from identifier.
-
Page 9: Configuration
5.1 Selection of reader number in RS-485 interface When connected via RS-485 interface the reader starts operating according to reader connection protocol in PERCo Web system, it can be used as an external reader for controllers of the system. Operation of reader in PERCo Web is similar to operation of IR-xx series readers. The difference is that in this case up to eight readers can be connected to one controller. -
Page 10: Changing The Format Of Output Data
IR-10 Proximity Card Reader Table 2. Reader indication Control signals Indication Blue wire Yellow wire «single line» «double line» Green Red and Green Green Green Yellow Key to Table 2: 0 – control line is connected to negative terminal of power supply;... -
Page 11: Installation
Certificate & Operation Manual 6 INSTALLATION 6.1 Safety requirements Attention! Study the Operation manual thoroughly before beginning the installation work. Reader installation must be carried out by a professional circuit installer. Only serviceable tools should be used. ... -
Page 12: Required Cables
IR-10 Proximity Card Reader 6.4 Required cables Note: Maximum distance between the reader and the controller depends on the cross- section of the cable you use. In case of use of standard cables given here the flawless operation of the reader is guaranteed at the maximum distance of 40 m. - Page 13 Certificate & Operation Manual Figure 4. Mounting hole pattern for installation 4. Mark and prepare mounting holes for the mounting arm and cables in the installation surface according to Fig. 4. 5. Pull cables through required holes in the mounting arm and in the installation surface.
- Page 14 IR-10 Proximity Card Reader Figure 5. Connection layout for RS-485 interface of PERCo Web controller Figure 6. Connection layout for Wiegand interface of ACS...
-
Page 15: Troubleshooting
Section 2. Surge at output of power Section 2, it may be necessary to source unit. energize the reader with a separate power source. In an unlikely event of other faults please consult the PERCo Technical Support Department. -
Page 16: Perco Warranty
IR-10 Proximity Card Reader 8 PERCO WARRANTY PERCo (the Manufacturer) warrants that the IR-10 reader post complies with applicable statutory safety requirements and electromagnetic compatibility provided that the instructions on storage, installation and operation, given in the Certificate & Operation Manual, are observed. - Page 17 Product in case they are in compliance with those stated by the Manufacturer. The Manufacturer does not guarantee that the Product purchased will meet Customer’s requirements and expectations. PLEASE NOTE THAT PERCo PRODUCES TECHNICALLY SOPHISTICATED PRODUCTS THAT, IF NOT FAULTY, CANNOT BE RETURNED BACK IF BY SOME REASON...
- Page 18 WARRANTY CARD IR-10 proximity card reader Serial number Date of manufacture: « » ____________________201__ Quality control seal: _____________________________________________________________ Date of sale: « » ____________________201__ ____________________________________ (signature, seal) Cutting line Warranty repair coupon IR-10 proximity card reader Serial number Date of manufacture: «...
- Page 21 PERCo Polytechnicheskaya str., 4, block 2 194021, Saint Petersburg Russia Tel: +7 812 247 04 64 E-mail: export@perco.com support@perco.com www.perco.com...
- Page 22 www.perco.com...
