Page 2: Specification
DMX LED Hexo moon 360*10 RGB manual A. SPECIFICATION: 1. Size:555×555×180mm 2. Weight:6.3kg 3. Power consumption:45W 4. Power input:AC110~240V/60~50HZ 5. LEDs:360PCS(120R,120G,120B)10mm 6. Beam angle:30 degree(20/40 degree optional) 7. Built-in programs,auto running,DMX mode,M/S,sound-active mode,static color 8. Selectable 2,3,4,7,14,26 channels 9. LED display for easier operation 10. -
Page 3: Auto Run Mode
2. Auto run mode You can press “MODE”button to select auto run mode, it shows , then it will run the built-in programs automatically. Press “SETUP”, it shows n. 001, then you can adjust the running loops number by “UP” “DOWN” If continuing pressing “SETUP”, it will show SPxx, Fdxx, FSxx, then you can set the value for speed, fading and flash by “UP”... - Page 4 Flash frequency DMX mode4：d-P4 0—255 dimming 0—255 dimming 0—255 0—255 0—255 0—25 0—255 0—255 0—255 dimming dimming dimming dimming dimming dimming dimming CH10 CH11 CH12 CH13 CH14 CH15 CH16 CH17 CH18 0—255 dimming 0—255 dimming 0—255 0—255 0—255 0—255 0—255 0—255 0—255 dimming...
- Page 5 168—175 PROGRAM15 176—183 PROGRAM16 184—191 PROGRAM17 192—199 PROGRAM18 200—207 PROGRAM19 208—215 PROGRAM20 216—223 PROGRAM21 224—231 PROGRAM22 Sensitivity 232--255 Sound Mode 0--255 DMX mode6：d-P6 Master DMX value FUNCTION SPEED FLASH dimmer 0—7 NO USE NO USE 8—15 16—23 Yellow 24—31 Green 32—39 Cyan 40—47...
-
Page 6: Slave Mode
216—223 PROGRAM20 224—231 PROGRAM21 Sensitivity 232--255 Sound Mode 0--255 4. Slave mode Press “MODE” button to select SLAv to run the slave mode. 5. Sound active mode Press “MODE” button to select SU31 to be run, now if activated one time, it will run one step, adjust the sensitivity by “UP”...
