Chapter 5

Technical specifications

Power supply
Supply voltage
Current consumption (at 24 VDC)
Detector module
Minimum display module
Command, standard display module
Communications
Display connectivity
Data bus length (RS-485)
SenseNET+
SenseNET
Inputs and outputs
Inputs
Number of inputs
End-of-line resistance
Outputs
Number of outputs
Contact type
Resistive load
ModuLaser Modular Aspirating Smoke Detector Installation Manual
18 to 30 VDC, 24 VDC nominal
21.2 to 27.2 VDC, 24 VDC nominal (UL/cUL
and FM)
260 mA (fan speed 1)
380 mA (fan speed 6)
940 mA (fan speed 16)
204 mA
232 mA (display backlight off)
USB and APIC
1,200 m (4,000 ft.) max. between nodes or
modules
1,200 m (4,000 ft.) max. length (sum of all
single cable sections)
2
15 KΩ 5% 1/4 W
3
C/NO/NC, voltage free
2 A at 30 VDC
