AirSense Aritech APIC Installation Sheet

Aritech APIC Installation Sheet for ModuLaser
Aspirating Smoke Detection Systems
1
3
EN: Installation Sheet
Description
Caution: This product is only compatible for use with
ModuLaser display modules with hardware version 00.00.11
(or later). To confirm compatibility, first check the hardware
version of the display module where the APIC will be installed
(Device Settings > Device Details > [select module] > HW
Version).
The Aritech Addressable Protocol Interface Card (APIC)
provides an interface to connect ModuLaser aspirating smoke
detection systems to compatible Aritech 2X and 2X-A
addressable fire alarm systems.
The APIC includes an integrated short circuit isolator.
© 2023 Carrier. All rights reserved.
2
4
Important:
• This product must be installed and maintained by qualified
personnel adhering to all local or national installation
requirements and any other applicable regulations.
• Always use the NeXT System Builder application to
calculate the maximum number of APICs that can be
installed. See "Calculating the maximum number of APICs
that can be installed" on page 2 for more details.
• You must configure alarms and faults as unlatched at the
display module. See "Configuring the alarm and fault
latching status at the display module" on page 3 for more
details.
• This APIC is not compatible for installation in Stratos
range aspirating devices (and variants) or for use with
Aritech FP1200C-2000C addressable fire systems.
1 / 4 P/N 10-4001-501-1700-02c • ISS 18SEP23
