2 PRODUCT SPECIFICATIONS

2 PRODUCT SPECIFICATIONS
The components specifications of the S5U1C60N15E are listed below.
S5U1C60N15E
Dimensions:
Weight:
Color:
Power supply:
Board:
Operating conditions:
LCD connection cable
S5U1C60N15E connector: J3372-P302VE or equivalent
Cable connector:
Cable:
Interface:
Length:
I/O cable
S5U1C60N15E connector: J3433-P302VE or equivalent
Cable connector:
Cable:
Interface:
Length:
Power cable
S5U1C60N15E connector: MOLEX 5276-03A or equivalent
Cable connector:
Other side connector:
Cable length:
Capacity:
2
203 mm (width) × 275 mm (depth) × 65 mm (height) (Including rubber feet)
About 2.04 kg
Cygnus white
5 V (±10%) DC, 3 A or more
When connected to the ICE, power is supplied by the ICE.
Main board × 1
Sub board × 1
Operating temperature
Storage temperature
Operating humidity
Storage humidity
Resistance to vibration
Resistance to impulse
7960-6500SC
60-pin flat cable × 1
CMOS interface (5 V)
About 50 cm
7950-6500SC
50-pin flat cable × 2
CMOS interface (5 V)
About 50 cm
MOLEX 5196-03
(According to power supply specifications)
About 80 cm
5 V DC, 3 A or more
EPSON
(main unit only)
(from external power supply)
5°C to 40°C
-20°C to 60°C
35% to 80%
20% to 90%
Operating 0.25G max.
Transportation 2G max.
Operating 1G max.
Standby 2G max.
(Two cables are same)
(EVALUATION BOARD FOR S1C60N15)
S5U1C60N15E MANUAL
