  • Page 1 CMOS 16 - BIT SINGLE CHIP MICROCOMPUTER S5U1C17801T1100 Hardware Manual (Software Evaluation Tool for S1C17801)
  • Page 2 No part of this material may be reproduced or duplicated in any form or by any means without the written permission of Seiko Epson. Seiko Epson reserves the right to make changes to this material without notice. Seiko Epson does...
  • Page 3 Configuration of product number Devices 17xxx Development tools S5U1 17000 00E1 Packing specifications 00 : Besides tape & reel 0A : TCP BL 0B : Tape & reel BACK 0C : TCP BR 0D : TCP BT 0E : TCP BD 0F : Tape &...
  • Page 5: Table Of Contents

    16 Infrared Emitting Diode/Receiving Module Connection Circuit ... 38 Emitting and Receiving from/by Infrared Area... 39 17 MMC (Multi-Media Card) Connection Circuit ... 40 18 USB Connection Circuit... 41 S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) - Table of Contents - EPSON...
  • Page 6 J18 Connector... 50 Appendix A How to Measure Current Consumption ... 51 A.1 Measuring V Current Consumption... 51 A.2 Measuring AV Current Consumption... 52 A.3 Measuring RTCV Current Consumption ... 52 EPSON S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801)
  • Page 7: Features

    1 Features S5U1C17801T1100 (Software eValuation Tool for S1C17801. Hereafter referred to as SVT17801)is an evaluation board for MCU S1C17801 manufactured by SEIKO EPSON. The SVT17801, consisting of the three boards, i.e., CPU, ICD and LCD, can debug software by connecting to the ICD and CPU boards without using ICD or other debug tool.
  • Page 8: Contents Of Package

    2 CONTENTS OF PACKAGE 2 Contents of Package The following lists the contents of S5U1C17801T1100 package: (1) SVT17801 CPU Board (Main body) ... 1 (2) SVT17801 ICD Board... 1 (3) SVT17801 LCD Board ... 1 (4) USB Cable ... 1 (5) Coin Battery (CR2032/3V) ...
  • Page 9: Name And Functions Of Each Part

    (1) Power LED (Blue) (2) Speaker (Left) (3) RESET SW (4) USBminiB connector (5) LED (RGB) (6) MIC S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) 3 NAME AND FUNCTIONS OF EACH PART 3.5inch STN QVGA B&W Membrane touch panel...
  • Page 10 3 NAME AND FUNCTIONS OF EACH PART Fig. 3.1.2 Name of Each Surface Mounted Part (without LCD Panel) (1) Infrared emitting module LED (2) FLASH (NOR) (3) SRAM (4) FLASH (NAND) EPSON (SOFTWARE EVALUATION TOOL FOR S1C17801) (5) Expansion connector (LCD board) S5U1C17801T1100 HARDWARE MANUAL...
  • Page 11 (1) Rotary encoder with Switch (2) RESET SW (3) ICDminiI/F (4) ICD board connector (5) Placement of infrared receiver module (substitute) (6) Audio connector (OUT) S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) 3 NAME AND FUNCTIONS OF EACH PART (16) (14) (12) (15)
  • Page 12 3 NAME AND FUNCTIONS OF EACH PART Fig. 3.1.4 Name of Each Part Mounted on Rear Face of LCD Board (1) Connector (to connect LCD panel) (2) Connector (to connect CPU board) EPSON S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801)
  • Page 13: Cpu Board Dimensions

    BAT1 ∗ Precautions • Unit for the above dimensions is millimeter (mm). • Board thickness: 1.6 mm, U23 is not mounted. S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) 3 NAME AND FUNCTIONS OF EACH PART Board Dimensions Parts installed within this dash line must be max. 8 mm in height...
  • Page 14: Icd Board Dimensions

    ∗ Precautions • Unit for the above dimensions is millimeter (mm). • Material: FR4, Board thickness: 1.6 mm JUSB JICD 4.95 Fig. 3.2.2.1 ICD Board Dimensions EPSON (SOFTWARE EVALUATION TOOL FOR S1C17801) 4-φ3.5 through hole 4-φ7 land S5U1C17801T1100 HARDWARE MANUAL...
  • Page 15: Lcd Board Dimensions

    • Unit for the above dimensions is millimeter (mm). • Board thickness: 1.6 mm • Figure 3.2.3.1 is a rear face drawing seen from the board surface. S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) 3 NAME AND FUNCTIONS OF EACH PART...
  • Page 16: Lcd Panel Board Dimensions

    79(active area of touch panel) 77.79±0.3(viewing area of bezel) 79.79±0.01(display area) VIEWING DIRECTION BOTTOM 13(P1.0 13),W=0.7 4.0±0.3 CONDUCTOR A DETAIL Fig. 3.2.4.1 LCD Panel Dimensions EPSON (SOFTWARE EVALUATION TOOL FOR S1C17801) 30.0 8.405 PIN1 ”A” 0.3±0.05 7±1(STIFFER) CONTACT SIDE 2-R0.3 S5U1C17801T1100 HARDWARE MANUAL...
  • Page 17: Main Parts

    Connector (to connect CPU board) (J101) DF9-13P-1V(32) Connector (to connect CPU board) (J102) DF9-9P-1V(32) Connector (to connect LCD panel) (J103) 52207-1485 Connector (to connect LCD panel) (J104) 52207-0485 S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) 3 NAME AND FUNCTIONS OF EACH PART S1C17801 SEIKO EPSON CORP.
  • Page 18: Functions Of Each Part

    Pressing the reset switch on the CPU board (S8 mounted on the rear face) resets the CPU board. Coin Battery A coin cell battery (of CR2032 standard) socket is mounted on the rear face of the CPU board. The socket is used for power supply to RTCV EPSON (SOFTWARE EVALUATION TOOL FOR S1C17801) S5U1C17801T1100 HARDWARE MANUAL...
  • Page 19 (The cell can also be removed by lifting the driver up as a lever.) Fig. 3.4.2.4 Installing/Removing Coin Battery - 4/4 S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) 3 NAME AND FUNCTIONS OF EACH PART...
  • Page 20: Block Diagram

    NAND FLASH USB 2.0(FS) USBminiB SD Card I/f SD Card Speaker Audio output Audio jack Audio AD/DA Microphone Audio input Audio jack Receiving module REMC communi cation Infrared LED External Device FLASH SRAM Key(6) CPU board CPU Board S5U1C17801T1100 HARDWARE MANUAL...
  • Page 21: Operating Environments And Starting Procedures

    (1) Connect the ICD board with the CPU board. Connect JICD 10 pin connector on the ICD board with the counterpart on the CPU board. Then turn on the CPU board. S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) 5 OPERATING ENVIRONMENTS AND STARTING PROCEDURES...
  • Page 22: Installing The Usb Driver

    (1) When the SVT17801 is connected with the host computer via USB cable, the following screen appears. (2) Follow the wizard to install USB driver. For brows directory of the USB driver, specify C:\EPSON\GNU17\utility\drv_usb. ∗ This indicates a directory path where IDE is installed.
  • Page 23 When the USB driver has been installed successfully,it appears on the device manager as shown below. Notes: If the driver does not appears on the device manager as shown above, install the USB driver again. EPSON S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801)
  • Page 24: Standalone Operation Of Svt17801

    The SVT17801 can update the firmware of the ICD board using the debugger on your PC. The ICD board firmware will be provided by EPSON if necessary. An update file has an .sa extension.) The following describes firmware update procedures.
  • Page 25: Difference Between Icd Board And Icd Mini

    ∗2 Only for connection with the CPU board. ∗3 Separate power supply is not required for the S1C17801 to write to flash ROM. ∗4 Operating frequency is 48MHz (DCLK=24MHz) for SVT17801. S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) 6 DIFFERENCE BETWEEN ICD BOARD AND ICD MINI...
  • Page 26: O Port

    Remote control light emitting module P55/FPLINE Expansion I/F (Connector No.: J12) P56/FPSHIFT/#TM0 P57/FPDRDY P60/A0/#BSL Expansion I/F (Connector No.: J18) & SRAM P61/A1 Expansion I/F (Connector No.: J18) & SRAM EPSON (SOFTWARE EVALUATION TOOL FOR S1C17801) Connected to S5U1C17801T1100 HARDWARE MANUAL...
  • Page 27 Memory Memory Memory Memory Memory Memory Memory Memory Memory Memory Memory Memory S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) Signal Name P62/A2 Expansion I/F (Connector No.: J18) & SRAM & NOR Flash P63/A3 P64/A4 P65/A5 P66/A6 P67/A7 P70/A8 P71/A9...
  • Page 28: Jumper Switch Settings

    For details, see the description of RTC control circuit in Chapter 10. Shorting 2-3 on JP1 disables the Wakeup func- tion. Factory default setting for JP1 is Wakeup Enable. To POWER SW To WAKEUP pin To 3.3V regulator SN74LVC1G98DCKR 0.1µF UNR5213 Fig. 8.1.1 JP1 Related Circuit EPSON (SOFTWARE EVALUATION TOOL FOR S1C17801) DIC-149-3P S5U1C17801T1100 HARDWARE MANUAL...
  • Page 29: Setting For Jp2

    Chapter 10. Note that, when 1-2 is shorted, a coin cell battery is required to activate RTCV Factory default setting for JP2 is 1-2 shorted. DIC-149-3P S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) as shown in the following. Short 2-3 on JP2 to se- , whereas 1-3 to select battery.
  • Page 30: Setting For Jp3

    TROL CIRCUIT WITH MFT0. Factory default setting for JP3 is 1-2 and 5-6 shorted. VLSS (LCD module) TS5A3166 DIC-152-6P LED3 LCD_BL_ON LTW-170TK LCD_BL_PWM D201_PWM Fig. 8.3.1 JP3 Related Circuit EPSON (SOFTWARE EVALUATION TOOL FOR S1C17801) MFT0 0.1µF S5U1C17801T1100 HARDWARE MANUAL...
  • Page 31: Connection Circuit To External Memory

    CYPRESS 16M bits SRAM (CY62167DV30) is installed on the SVT17801. The following diagram shows how the EEPROM is connected to the SVT17801. S1C17801 A1 to A20 D0 to D15 WRH/RSH A0/BSL S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) 9 CONNECTION CIRCUIT TO EXTERNAL MEMORY CY62167DV30 D15/A-20 Fig. 9.1.1 SRAM Connection Circuit EPSON 0.1µF...
  • Page 32: Nor Flash Connection Circuit

    SPANION 64M bits NOR Flash (S29JL064H) is installed on the SVT17801. The following diagram shows how the EEPROM is connected to the SVT17801. S1C17801 A1 to A22 D0 to D15 RESET S29JL064H RY/BY WP/ACC RESET Fig. 9.2.1 NOR Flash Connection Circuit EPSON (SOFTWARE EVALUATION TOOL FOR S1C17801) D15/A-1 0.1µF BYTE S5U1C17801T1100 HARDWARE MANUAL...
  • Page 33: Nand Flash Connection Circuit

    MICRON 2G bits NAND Flash (MT29F2G08AACWP) is installed on the SVT17801. The following diagram shows how the EEPROM is connected to the SVT17801. S1C17801 D0 to D7 SMRD SMWR SMWP S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) 9 CONNECTION CIRCUIT TO EXTERNAL MEMORY MT29F2G08AACWP Fig. 9.3.1 NAND Flash Connection Circuit EPSON...
  • Page 34: Eeprom Connection Circuit

    MICROCHIP 256K bits EEPROM (24AA256) is installed on the SVT17801. The following diagram shows how the EEPROM is connected to the SVT17801. S1C17801 I2C_SDA I2C_SCL 24AA256-I/SN Fig. 9.4.1 EEPROM connection circuit EPSON (SOFTWARE EVALUATION TOOL FOR S1C17801) 0.1µF S5U1C17801T1100 HARDWARE MANUAL...
  • Page 35: Power Control Circuit For Battery Backup Function

    Figure 10.2.1 shows the power control circuit for SVT17801 battery backup function. Power switch POWER SW RESET SW Fig. 10.2.1 Power Control Circuit for Battery Backup Function S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) 10 POWER CONTROL CIRCUIT FOR BATTERY BACKUP FUNCTION , AV covers analog circuits (ADC), and RTCV...
  • Page 36 WAKEUP (HIGH Active) GPIO(PC2) HIGH HIGH HIGH HIGH EPSON (SOFTWARE EVALUATION TOOL FOR S1C17801) line) electrically. line to the V line. Therefore, be line (AV line). area. is supplied . For detail of JP set- ) on. S5U1C17801T1100 HARDWARE MANUAL...
  • Page 37 We recommend you review all necessary factors to choose the optimal way when you design a total system. S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) 10 POWER CONTROL CIRCUIT FOR BATTERY BACKUP FUNCTION is running in ON status.)
  • Page 38: Lcd Panel Connection Circuit

    Display data bus Display data bus LCD ON/OFF Control (L:OFF, H:ON) Backlight power supply Backlight power supply EPSON (SOFTWARE EVALUATION TOOL FOR S1C17801) L102 MPZ2012S601A C107 C111 4.7µF 10µF S1C17801 FPFRAME FPLINE FPSHIFT FPDAT4 FPDAT5 FPDAT6 FPDAT7 FPDRDY MFT0 S5U1C17801T1100 HARDWARE MANUAL...
  • Page 39: Touch Panel Controller Connection Circuit

    X-axis and Y-axis AD values while alternately switching between P33 and P34 statuses with a short duration. SVT17801 LCD BOARD EPSON X-axis AIN6 (Voltage HIGH) Fig. 11.1.2 Image of X-axis and Y-axis Analog Values of Touch Panel S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) Q103 UNR31A300L Q104 C110 UNR5213 0.1µF...
  • Page 40: Key Input Circuit On Cpu Board

    "V" value for each switch is obtained by resistance values of R1 and R2 that are obtained when the switch is pressed. Thus the pressed switch can be determined by comparing the "V" value with the value actually entered into AD (AIN7). EPSON S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801)
  • Page 41: Rotary Encoder Connection Circuit

    As a switch is directly connected to a port, pressing the switch turns the port LOW. The LOW zone can be detected by software. S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) 13 ROTARY ENCODER CONNECTION CIRCUIT...
  • Page 42: Tri-Color Led Connection Circuit

    Table 14.1 Color on Tri-color LED Corresponding to Port Status MMBTA42-TP Fig. 14.1 Tri-color LED Connection Circuit S1C17801 EPSON (SOFTWARE EVALUATION TOOL FOR S1C17801) LED1 598-9920-307F Color on Tri-color LED ●(light off) ●(green) ●(blue) ●(aqua) ●(red) ●(orange) ●(purple) ○(white) S5U1C17801T1100 HARDWARE MANUAL...
  • Page 43: Led/Lcd Backlight Control Circuit With Mft0

    ∗ MFT0 is an I/O port with 12 mA of drive current. A circuit shown in the figure 15.1.has a pre-stage switch IC, which however can be replaced simply by a 470Ω resistor for direct drive. (The drive current in this case is ap- proximately 7 mA.) S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) 15 LED/LCD BACKLIGHT CONTROL CIRCUIT WITH MFT0 TS5A3166 0.1µF...
  • Page 44: Infrared Emitting Diode/Receiving Module Connection Circuit

    (GP1UX31QS/GP1UX51QS/PNA4702M) installed on the SVT17801. S1C17801 REMO REMI Infrared Receiver Module Fig. 16.1 Infrared Emitting Diode/Receiving Module Connection Circuit Infrared Emitting Diode MMBTA42-TP ➀ ➂ GP1UX311QS EPSON (SOFTWARE EVALUATION TOOL FOR S1C17801) 4.7µF AN333 ➁ 10µF 4.7µF S5U1C17801T1100 HARDWARE MANUAL...
  • Page 45: Emitting And Receiving From/By Infrared Area

    A spare module can be installed in the area marked by a dotted red circle. (Module is not installed in the area marked by a dotted red circle.) S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) <Receive>...
  • Page 46: Mmc (Multi-Media Card) Connection Circuit

    The SVT17801 is equipped with a MMC card socket being connected to the S1C17801 with SPI mode as shown in the following diagram. SPI_SSI0 SPI_SDO0 SPI_SCK0 SPI_SDI0 For information about controlling the MMC card using SPI mode, see the Application Note. 0.1µF Fig. 17.1 MMC Card Connection Circuit EPSON (SOFTWARE EVALUATION TOOL FOR S1C17801) DM1B-DSF-PEJ(22) S5U1C17801T1100 HARDWARE MANUAL...
  • Page 47: Usb Connection Circuit

    The SVT17801 is equipped with a USB miniB connector being connected to the S1C17801 as shown in the following diagram. 54819-0578 VBUS D– SN65220DBVT For information about controlling USB, see the Application Note. S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) 1.5K 5.1K 1µF BLM21PG600SN1D Fig. 18.1 USB Connection Circuit...
  • Page 48: Audio Connection Circuit

    S are available for 2.2K MIC GND 2.2K MIC1 2.2K EM6022P-42BC10&33-G 2.2K 2.2K 2.2K SJ-3523-SMT 1µF 1µF 1µF 1µF 1µF 1µF SJ-43514-SMT C32 + 47µF 47µF BLM18PG121SN1D BLM18PG121SN1D BLM18PG121SN1D BLM18PG121SN1D – NDT-03B 1000pF 1000pF – NDT-03B 1000pF 1000pF S5U1C17801T1100 HARDWARE MANUAL...
  • Page 49: Exclusive Control Of Ports

    Note that the P45 port becomes an input port immediately after reset has been released. In this status, P45 is pulled down to LOW. The following diagram shows a circuit in this area. S1C17801 S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) NAND Flash NAND Flash...
  • Page 50: Serial

    S serial ports. Each of the ports is multiplexed with GPIO. Table 21.1 Serial Port Connected to SPI | GPIO (P10,P11,P12,P13) SPI | GPIO (P13,P14,P15,P16) UART | GPIO (P40,P41,P42) EPSON S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) Multiplex C | GPIO (P50,P51)
  • Page 51: Specifications For Cpu Board Connectors

    DCLK #RESET_OUT DSIO TGT_EN DST2 (+3.3V) (+3.3V) S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) 22 SPECIFICATIONS FOR CPU BOARD CONNECTORS Table 22.1.1 J6 Connector Pin Assignment Connector J6 〈Upper view of CPU board〉 〈Side view of ICD board〉 Functionalities On-chip debugger clock output port –...
  • Page 52: J7 Connector

    General purpose input port | Analog input port – Analog power ground – Analog power ground – Analog power ground – Analog power ground – Analog power ground – Analog power ground – Analog power ground EPSON (SOFTWARE EVALUATION TOOL FOR S1C17801) 17 18 S5U1C17801T1100 HARDWARE MANUAL...
  • Page 53: J8 Connector

    PA2 (if P45=L) N.C (TP31) P40/SIN0 (TP42) N.C (TP32) P41/SOUT0 (TP43) P42/SCLK (TP44) S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) 22 SPECIFICATIONS FOR CPU BOARD CONNECTORS Table 22.3.1 J8 Connector Pin Assignment Connector J8 〈Front view of CPU board〉...
  • Page 54: J12 Connector

    General purpose I/O port | LCD ON/OFF control (L:OFF, H:ON) Backlight control (V or MFT0 control switch IC) – Power pin – Power pin – Power pin – Power pin – Power pin – Power ground – Power ground EPSON (SOFTWARE EVALUATION TOOL FOR S1C17801) S5U1C17801T1100 HARDWARE MANUAL...
  • Page 55: J13 Connector

    SAMTEC Model number: TSW-106-07-S-D Name P33 (if P45=L) P34 (if P45=L) P05/AIN5 P06/AIN6 S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801) 22 SPECIFICATIONS FOR CPU BOARD CONNECTORS Connector J13 〈Front view of CPU board (without LCD panel)〉 Functionalities – Power pin –...
  • Page 56: J18 Connector

    45 WRL /PA5 46 BSH /PA6 47 BSL /P60 48 P44 General purpose I/O port 49 RESET Reset signal 50 N.C (TP27) – – 51 (GND) – – 52 (GND) – – EPSON S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801)
  • Page 57: Appendix A How To Measure Current Consumption

    To reduce current consumption in Halt or Sleep mode, set P43 to the LOW output port. Then this current is cancelled. However, note that executing this operation while OSCI is used as a system clock causes system to halt S5U1C17801T1100 HARDWARE MANUAL (SOFTWARE EVALUATION TOOL FOR S1C17801)
  • Page 58: Measuring Av Dd Current Consumption

    OSC1 IVRAM Fig. A.2 #STBY Related Circuit Current Consumption ) can be measured by inserting an ammeter into JP5. Current Consumption EPSON (SOFTWARE EVALUATION TOOL FOR S1C17801) (10k ) line. ) can be is supplied from V S5U1C17801T1100 HARDWARE MANUAL...
