2.6
KFE72-DA Adapters and Attached Console
Terminals
One KFE72-DA adapter is required for each logical partition beyond
partition 0. The KFE72-DA provides the port to connect an additional
serial console terminal.
Figure 2–8 KFE72-DA Adapters
Serial Terminal
Connector
2-14
Getting Started with Logical Partitions
H8571-J
2
Connector
1
COM1
0
Front Panel Slot
UN-0302B-99
