Site Considerations

DAS System User Manual
Table 1–3: Power for Modules (with Probes) (Cont.)
Module
92C96D/XD/SD
92A60
92A90/D
92S16
92S32
92SX109
92SX118
92C02
92HS8
92HS8E
1
92C96 Acquisition Module power requirements
reduced to 140 W max. effective SN B061162 and
above.
The system software checks for certain configurations at power-on, and also
prompts you to use the correct power supply and power cord. The power supply
and module cards can be damaged if you have an illegal configuration, the wrong
power supply, or the wrong power cord. For example, if you have more than four
92C96 Modules in one mainframe, the system will display a warning message at
power-on and then shut down.
Information provided here describes the environment in which the mainframe,
terminal, and modules should be operated; the intended site must meet the stated
conditions.
Mainframe Site Considerations. The mainframe will operate in a temperature
environment between +10 C and +40 C (+50 F and +104 F). The maximum
heat dissipation is 3,750 BTUs per hour.
When the mainframe is to be operated on a bench or cart, it should be placed in a
normal, upright position. For proper cooling, allow at least four inches (10.2 cm)
of clearance in front of and behind the mainframe; allow at least two inches
(5.1 cm) of clearance on both sides of the mainframe.
If the need arises, the mainframe can also be operated while on its right side
(media drives down). If positioned on its side, the mainframe must be raised off
the working surface a minimum of two inches (5.1 cm). This permits proper air
flow for cooling purposes.
Power (watts)
1
140
130
130
78
79
78
79
30
20
12
Getting Started
1–11
