Trigger One Module from
Another or Cross Trigger
Two Acquisition Modules
DAS System User Manual
Configuration:
slot 0 Controller
slot 1
slot 2 92A16
92A16 slot 3 92A16
Formation 0
slot 4 92A16E
slot 5 92S16
slot 6 92S32
92S16/32
Formation 0 slot 7 92S32T
slot 8
Configuration:
slot 0 Controller
slot 1
slot 2 92A16
92A16 slot 3 92A16
Formation 1
slot 4 92A16E
slot 5 92S16
slot 6 92S32
92S16/32
Formation 1 slot 7 92S32T
slot 8
Configuration:
slot 0 Controller
slot 1
slot 2 92A16
92A16
slot 3 92A16
Formation 1
slot 4 92A16E
slot 5 92S16
slot 6 92S32
92S16/32
Formation 2 slot 7 92S32T
slot 8
Figure 3–32: Selecting Module Formations
To trigger one module when an event occurs on another module or to cross-trig-
ger two acquisition modules, follow these steps:
1. Form a cluster of two modules appropriate to your application in the Cluster
Definition overlay of the System Configuration menu.
2. Define a signal in the Signal Definition overlay of the Cluster Setup menu.
The signal should be an output signal from one module (92A96-1) and an
input signal to the other module (92A96-2).
To cross trigger two modules, you need to define two signals. Define one
signal as an output from 92A96-1 and as an input to 92A96-2. Define a
second signal as an output from 92A96-2 as and an input to 92A96-1.
Mainframe
92A16-1
92S16-1
Mainframe
92A16-1
92S16-1
Mainframe
92A16-1
92S16-1
Reference
3–63
