Connectors

3 Connectors
Fig. 2 Top-mounted interface
Fig. 3 Bottom-mounted interface

Ethernet Connectors (LAN 1/LAN 2)

The PROFINET IRT interface contains a dual port Ethernet switch. The two LAN ports are labeled
X1.1 and X1.2 if the interface is top-mounted, and X2.1 and X2.2 if the interface is bottom-
mounted.
Pin
1
2
3
6
4, 5, 7, 8
Anybus ® X-gateway ™ PROFINET ®
This product contains parts that can be damaged by electrostatic discharge (ESD). Use
ESD prevention measures to avoid damage.
LAN 1
(X1.1)
LAN 1
(X2.1)
Function
TD+
TD-
RD+
RD-
(reserved)
IRT (2.32) User Manual
LAN 2
(X1.2)
LAN 2
(X2.2)
Fig. 4
6 (28)
1 8
Ethernet connector (RJ45)
