Description

2 Description
2.1

Overview

The Anybus X-gateway PROFINET IRT (2.32) is a multi purpose communication solution offering
industrial protocol support as well as web and email capabilities. It acts as a PROFINET device
(slave), which means that it can be accessed by a PROFINET controller (master) but will not
initiate communication by itself.
The interface exchanges data via two memory buffers that can be accessed via a built in
webserver or via industrial network protocols such as PROFINET IO.
Input Buffer
Output Buffer
Fig. 1 Overview of data flow
See also PROFINET Data Exchange, p.
Anybus ® X-gateway ™ PROFINET ®
Contains data coming to the PROFINET IRT from the X-gateway (data from another
network).
Contains data to be sent from the PROFINET IRT through the X-gateway to another
network.
FTP Server
Email Client
Web Server
PROFINET IO
Server
IRT (2.32) User Manual
Filesystem
Input
Buffer
Output
Buffer
13.
5 (28)
(from Gateway)
(to Gateway)
