PROFINET Data Exchange
Attribute Name and Data Format
Supported attribute names and data formats.
Attribute Name and Data Format
Attribute Name
AM info Type
Location Type
AM Type Identification
IM Hardware Revision
IM Annotation
IM Order ID
IM Serial Number
AM Software Revision
AM Hardware Revision
IM Software Revision
IM Unique Identifier
Location LT
Location SS
AM Device Identification
Anybus ® X-gateway ™ PROFINET ®
Data Format
Unsigned 8
Unsigned 16
String of length X
String of length X
String of length X
String of length X
String of length X
Array of Unsigned 8
Length is 4
Array of Unsigned 8
Length is 16
Array of Unsigned 16
Length is up to 12
elements.
Array of Unsigned 16
Length is 4.
IRT (2.32) User Manual
Description
The value is set as one byte value.
The value is set with two bytes, little-endian format.
Maximum number of elements in array: 64.
Maximum number of elements in array: 64.
Maximum number of elements in array: 16.
Maximum number of elements in array: 64.
Maximum number of elements in array: 64
First byte is a character.
Bytes 2, 3 and 4 represent the version in the format X.Y.Z
where X, Y and Z represent a value between 0 and 255.
C is one character.
X, Y and Z represent a value between 0 and 255.
X – Major version
Y – Minor version
Z – Internal
Format is 16 bytes.
Each Unsigned 16 comprises two bytes, where each two bytes
form an Unsigned 16 in little-endian format.
The number of Unsigned 16's can be up to 12, placed directly
after each other
Each Unsigned 16 comprises two bytes, where each two bytes
form an Unsigned 16 in little-endian format.
The number of Unsigned 16's shall be 4, placed directly after
each other.
