PROFINET Data Exchange
Attribute Name and Data Format
Attribute Name
AM info Type
Location Type
AM Type Identification
IM Hardware Revision
IM Annotation
IM Order ID
IM Serial Number
AM Software Revision
AM Hardware Revision
IM Software Revision
IM Unique Identifier
Location LT
Location SS
AM Device Identification
Anybus ® X-gateway ™ PROFINET ®
Data Format
Unsigned 8
Unsigned 16
String of length X
String of length X
String of length X
String of length X
String of length X
String
Array of Unsigned 8
Length is 16
Array of Unsigned 16
Length is up to 12
elements.
Array of Unsigned 16
Length is 4.
IRT (2.32) User Manual
Description
The value can be set in either of two formats, 0x12 or 18.
The value can be set in either of two formats, 0x1234 or
4660.
Maximum number of elements in array: 64.
Maximum number of elements in array: 64.
Maximum number of elements in array: 16.
Maximum number of elements in array: 64.
Maximum number of elements in array: 64.
Format of the string shall be C.X.Y.Z.
C is one character.
X, Y and Z represent a value between 0 and 255.
X – Major version
Y – Minor version
Z – Internal
Format of the value shall be 0xXX;0xYY...0xZZ.
16 values in hex-format, where each value is separated by a
";".
Format of the value shall be 0xXXXX;0xYYYY...0xZZZZ.
Up to 12 values in hex-format, where each value is separated
by a ";".
Format of the value shall be 0xXXXX;0xYYYY...0xZZZZ.
4 values in hex-format, where each value is separated by a ";".
18 (28)
