CONNECTORS

6.1 Power

Power is applied through a TA3F (Switchcraft) female connector connected as
follows :
Pin

6.2 Computer

"3100i" connects to a serial port of the computer using the supplied spiral
cable.
The 15 pin D-SUB connector has the following pin-outs:
pin 2 : Tx
pin 3 : Rx
pin 5 : CTS
pin 6 : DTR
pin 7 : GND
Leave the rest of the pins unconnected or damage may result!!
Typical Computer to "3100i" cables:
16
1 : + 12-15VDC
2 : 0V
3 : + 20-28VDC (this is an alternative to pin 1)
