high-voltage potential is always at risk of discharging to a lower potential. If this discharge path is through a
semiconductor device, it may result in destructive damage.
SIM8905A must be handled according to the ESD Association standard: ANSI/ESD S20.20-1999, Protection of
Electrical and Electronic Parts, Assemblies, and Equipment.
Table 29: ESD performance parameters（Temperature: 25℃, Humidity: 45%）
Pin
VBAT
GND
Antenna
PWRKEY
Module Operating Frequencies
Table 30: Module operating frequencies
Frequency
LTE B2
LTE B4
LTE B5
LTE B12
Module Output power
Table 31: Conducted transmission power
Frequency
LTE-FDD B2
LTE-FDD B4
LTE-FDD B5
LTE-FDD B12
Contact discharge
±5KV
±5KV
±5KV
±4KV
Receive
1930-1990 MHz
2110-2155 MHz
869-894 MHz
729-746MHz
Power
23dBm +/-2.7dB
23dBm +/-2.7dB
23dBm +/-2.7dB
23dBm +/-2.7dB
Air discharge
±10 KV
±12KV
±10KV
±6KV
Transmit
1850-1910 MHz
1710-1755 MHz
824-849MHz
699-716MHz
Min.
<-40dBm
<-40dBm
<-40dBm
<-40dBm
- 34 -
