Camera Interface
SIM8905A supports two cameras: 2-lane MIPI_CSI primary camera up to 8MP resolution and 1-lane MIPI_CSI
secondary camera up to 5MP resolution.
Table 7: Camera interface pin definitions
Pin Name
MIPI_CSI0_CLK_M
MIPI_CSI0_CLK_P
MIPI_CSI0_LN0_M
MIPI_CSI0_LN0_P
MIPI_CSI0_LN1_M
MIPI_CSI0_LN1_P
MIPI_CSI1_CLK_M
MIPI_CSI1_CLK_P
MIPI_CSI1_LN0_M
MIPI_CSI1_LN0_P
CAM0_MCLK
CAM1_MCLK

CAM0_RST_N

CAM0_PWDN

CAM1_RST_N

CAM1_PWDN
CAM_I2C_SCL
CAM_I2C_SDA
Pin# Type
63 I
64 I
65 I
66 I
67 I
68 I
70 I
71 I
72 I
73 I
74 O
75 O
79 O
80 O
81 O
82 O
83 O
84 I/O
17
Smart Machine Smart Decision
Description
Primary camera serial interface
Secondary camera serial interface
Primary Camera master clock
Secondary Camera master clock
Primary Camera reset
Primary Camera power down
Secondary Camera reset
Secondary Camera power down
Camera I2C clock
Camera I2C data
