- Page 1 IoT Gateway Intel® Apollo Lake N3350, 1.1 GHz Intel® Apollo Lake N4200, 1.1 GHz (Option) EAC Mini EACIL20 Quick Start Guide Version 1.3 Document Part Number: 915211101025 Please read these instructions carefully before using this product, and save this manual for future use.
-
Page 2: Table Of Contents
Winmate EAC Mini EACIL20 IoT Gateway Quick Start Guide V1.1 Contents Preface Chapter 1: Introduction 1.1 Features 1.2 Expansion Module 1.3 Package Contents 1.4 Hardware Specifications 1.5 Description of Parts 1.6 LED Indicators Chapter 2: Mounting 2.1 Wall/ Desk Mount 2.2 DIN-Rail Mount... -
Page 3: Preface
Preface Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners. - Page 4 Winmate EAC Mini EACIL20 IoT Gateway Quick Start Guide V1.1 Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings.
- Page 5 Preface Let service personnel to check the equipment in case any of the following problems appear: o The power cord or plug is damaged. o Liquid has penetrated into the equipment. o The equipment has been exposed to moisture. o The equipment does not work well or you cannot get it to work according to the user manual.
-
Page 6: Chapter 1: Introduction
Chapter 1: Introduction Congratulations on purchasing Winmate® EAC Mini EACIL20 IoT Gateway. The EAC Mini EACIL20 is a compact industrial IoT Gateway with low power consuming Intel® Apollo Lake processor. The EAC Mini EACIL20 provides great expansion including one Mini-PCIe and SIM card support. -
Page 7: Package Contents
Chapter 1: Introduction 1.3 Package Contents Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: Terminal Block Quick Start EAC Mini... -
Page 8: Hardware Specifications
Winmate EAC Mini EACIL20 IoT Gateway Quick Start Guide V1.1 1.4 Hardware Specifications Model Name EACIL20 Intel® Apollo Lake N3350 1.1 GHz Intel® Apollo Lake N4200, 1.1 GHz (Option) Graphics Intel® HD Graphics Engine System BIOS Insyde UEFI Specification Watchdog Programmable 256 levels, timer interval 1 to 255 sec. -
Page 9: Description Of Parts
Chapter 1: Introduction 1.5 Description of Parts Front Side Rear Side 1.6 LED Indicators The EAC Mini IoT Gateway provides one HDD and one Power LED indicators located on the front for status monitoring. LED Type Status Description Power is on Power Power is off... -
Page 10: Chapter 2: Mounting
Winmate EAC Mini EACIL20 IoT Gateway Quick Start Guide V1.1 Chapter 2: Mounting The EAC Mini supports five types of mounting: wall and desk mounting by default, and optional VESA, DIN-rail, Pole mounting solutions. You can purchase mounting kit from Winmate as an optional accessory. 2.1 Wall/ Desk Mount L-shape mounting brackets for wall/ desk mounting are supplied with the EAC Mini. -
Page 11: Din-Rail Mount
Chapter 2: Mounting 2.2 DIN-Rail Mount You can purchase DIN-Rail mounting kit from Winmate as an optional accessory. DIN-Rail Mounting Kit Part Number: 821118551400 Mounting Instruction: ❶ Fasten screws to secure DIN-rail mounting ❷ Place the EAC Mini with the DIN-Rail bracket to the EAC Mini. -
Page 12: Vesa Mount
Winmate EAC Mini EACIL20 IoT Gateway Quick Start Guide V1.1 2.3 VESA Mount You can purchase VESA mounting kit from Winmate as an optional accessory. VESA Mounting Kit Part Number: 821118561001 Mounting Instruction: ❶ Mark the location of the screw holes on the ❷... -
Page 13: Chapter 3: Hardware Installation
Chapter 3: Hardware Installation Chapter 3: Hardware Installation This section explains how to install hardware on the EAC Mini EACIL20. Caution Always remove the power cord before installing the hardware. 3.1 mSATA Installation To insert mSATA: 1. Unscrew the four screws on the bottom cover. -
Page 14: Expansion Module Installation
Winmate EAC Mini EACIL20 IoT Gateway Quick Start Guide V1.1 3.3 Expansion Module Installation Notice that expansion module is an optional feature of the EAC Mini EACIL20. To install expansion module: ❶ Unscrew the three screws, and remove ❷ Attach the 2... -
Page 15: Usb Wire Loop Installation
3.4 USB Wire Loop Installation ❶ Insert USB to the USB slot. ❷ Install copper pillar, USB wire loop, and fasten one screw to secure the USB to the EAC Mini EACIL20. ❸ You have finished the USB Wire Loop installation. -
Page 16: Connecting The Power
Winmate EAC Mini EACIL20 IoT Gateway Quick Start Guide V1.1 3.5 Connecting the Power The DC power supply connector of the EAC Mini IoT Gateway is on the front panel. The DC power input for the EAC Mini allows a voltage input range from 9 V DC to 36 V DC. -
Page 17: Chassis Grounding
The following sections give you information about EAC Mini EACIL20standard connectors and pin assignments. 3.6.1 HDMI Connector Plug HDMI signal cable to the HDMI connector of the EAC Mini EACIL20, and plug the other end to the monitor. Pin Assignment and signal names for HDMI connector Pin №... -
Page 18: Ethernet Connector
Winmate EAC Mini EACIL20 IoT Gateway Quick Start Guide V1.1 3.6.2 Ethernet Connector The EAC Mini EACIL20 has two Ethernet connectors located on the front. Ethernet ports provide a standard RJ45 10/100/1000 Mbps jack connector with LED indicators on the front side to show its Active/ Link status and Speed status. -
Page 19: Chapter 4: Getting Started
Chapter 4: Getting Started 4.1 How to Enable Watchdog To enable Watchdog, you need to download Winmate Watchdog utility. Find more information on Watchdog in “Watchdog Guide” that you can download from Winmate Download Center. To enable watchdog in Watchdog AP follow the instructions below: 1. -
Page 20: Using Recovery Wizard To Restore Computer
Winmate EAC Mini EACIL20 IoT Gateway Quick Start Guide V1.1 4.2 Using Recovery Wizard to Restore Computer Note: Before starting the recovery process, make sure to backup all user data. The data will be lost after the recovery process. Important: Before starting the recovery process, remove the PCI/ PCIe card and CFast card. -
Page 21: Appendix
Appendix Appendix Appendix A: Order Information EAC Mini EACIL20 IoT Gateway available in the following configurations: Model Name Configuration EACIL20-100-A432 Intel N3350, 4G RAM, 32GB eMMC, 2 x USB 3.0, 2 x GbE LAN, 1 x HDMI EACIL20-101-A432 Intel N3350, 4G RAM, 32GB eMMC, 2 x USB 3.0,... -
Page 22: Appendix C: Mechanical Dimensions
Winmate EAC Mini EACIL20 IoT Gateway Quick Start Guide V1.1 Appendix C: Mechanical Dimensions All dimensions are shown in mm (millimeters). Unit without mounting bracket Standard With Expansion Module Unit with mounting bracket... - Page 23 Notes ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________...
- Page 24 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.
