Page 1: Quick Start Guide
IL20EAC-N Quick Start Guide V1.0 For more information on this and other Winmate products, please visit our website at: www.winmate.com Document Part Number: 915211101025 Please read these instructions carefully before using this product, and save this manual for future use. -
Page 2: Table Of Contents
CONTENTS PREFACE - 3 - 1 INTRODUCTION - 8 - 1.1 Features - 8 - 1.2 Expansion Module - 8 - 1.3 Package Contents - 9 - 1.4 Product Overview - 10 - 1.5 LED Indicators - 11 - 2 MOUNTING - 12 - 2.1 Wall/ Desk Mount - 12 -... -
Page 3: Preface
PREFACE FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received including interference that may cause undesired operation. - Page 4 Disclaimer Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. We assume no responsibility or liability for...
-
Page 5: Customer Service
Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance. You may need the following information ready before you call: ... -
Page 6: Safety Information
Safety Information WARNING! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis. - Page 7 Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory.
-
Page 8: Introduction
1 INTRODUCTION Congratulations on purchasing Winmate® EAC Mini IL20EAC-N IoT Gateway. The EAC Mini IL20EAC-N is a compact industrial IoT Gateway with low power consuming Intel® Apollo Lake N3350 1.1 GHz processor. The EAC Mini IL20EAC-N provides great expansion including one Mini-PCIe and SIM card support. -
Page 9: Package Contents
1.3 Package Contents Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: Terminal Block Quick Start EAC Mini 2 pin to 2.5Ø... -
Page 10: Product Overview
1.4 Product Overview Front Side Rear Side - 10 -... -
Page 11: Led Indicators
1.5 LED Indicators The EAC Mini IoT Gateway provides one HDD and one Power LED indicators located on the front for status monitoring. LED Type Status Description Power is on Power Power is off - 11 -... -
Page 12: Mounting
2 MOUNTING The EAC Mini supports five types of mounting: wall and desk mounting by default, and optional VESA, DIN-rail, Pole mounting solutions. You can purchase mounting kit from Winmate as an optional accessory. 2.1 Wall/ Desk Mount Mounting Instruction: 1. -
Page 13: Din-Rail Mount
2.2 DIN-Rail Mount You can purchase DIN-Rail mounting kit from Winmate as an optional accessory. DIN-Rail Mounting Kit Part Number: 821118551400 Mounting Instruction: 1. Fasten screws to secure DIN-rail mounting bracket to the EAC Mini. 2. Place the EAC Mini with the DIN-Rail bracket on the DIN-Rail. -
Page 14: Vesa Mount
2.3 VESA Mount You can purchase VESA mounting kit from Winmate as an optional accessory. VESA Mounting Kit Part Number: 821118561001 Mounting Instruction: 1. Mark the location of the screw holes on the fixture (ex. wall). 2. Align the VESA mounting bracket with the screw location. -
Page 15: Installation
3 INSTALLATION This section explains how to install hardware on the EAC Mini IL20EAC-N. CAUTION Always remove the power cord before installing the hardware. 3.1 mSATA Installation To insert mSATA: 1. Unscrew the four screws on the bottom cover. 2. Plug in mSATA card with into the mPCIe slot. -
Page 16: Expansion Module Installation
3.2 Expansion Module Installation Notice that expansion module is an optional feature of the EAC Mini IL20EAC-N. To install expansion module: 1. Unscrew the three screws on the bottom cover. 2. Remove the I/O module from the 2 layer. Attach module to the 1 layer and fasten five screws inside. -
Page 17: External Antenna Installation
3.3 External Antenna Installation Notice that external antenna is an optional feature of the EAC Mini IL20EAC-N. To install external SMA antenna: 1. Remove the rubber cap on the SMA connector before installing the antenna. 2. Align the antenna with the SMA connector located on the rear side of the EAC Mini and fasten it as shown on the picture. -
Page 18: Connecting The Power
3.4 Connecting the Power The DC power supply connector of the EAC Mini IoT Gateway is on the front panel. The DC power input for the EAC Mini allows a voltage input range from 9 V DC to 30 V DC. WARNING! Ensure voltage and polarity is compliant with the DC input. -
Page 19: External Connectors
The following sections give you information about EAC Mini IL20EAC-N standard connectors and pin assignments. 3.5.1 HDMI Connector Plug HDMI signal cable to the HDMI connector of the EAC Mini IL20EAC-N, and plug the other end to the monitor. Pin Assignment and signal names for HDMI connector Pin №... -
Page 20: Usb Connector
3.5.3 USB Connector The EAC Mini IL20EAC-N provides two USB 3.0 connectors. Use USB 3.0 connector to connect external devices such as mouse or keyboard to the box computer. Pin № Pin № Signal Name Signal Name USB_D- USB_D+ STDA_SSRX-... -
Page 21: Getting Started
To enable Watchdog, you need to download Winmate Watchdog utility. Find more information on Watchdog in “Watchdog Guide” that you can download from Winmate Download Center. Refer to the User Manual for more details. To enable watchdog in Watchdog AP follow the instructions below: 1. - Page 22 3. In Watchdog utility window set countdown time and periodically feed time, or disable watchdog. Example: Every 10 min watchdog will monitor the system, in case any error occurs the system will restart automatically when the countdown time reaches 0. Every 9 min watchdog timer will be reset to 10 min.
-
Page 23: Using Recovery Wizard To Restore Computer
4.2 Using Recovery Wizard to Restore Computer Note: Before starting the recovery process, make sure to backup all user data. The data will be lost after the recovery process. Important: Before starting the recovery process, remove the PCI/ PCIe card and CFast card. To enable quick one-key recovery procedure: 1. -
Page 24: Specifications
5 SPECIFICATIONS Model Name IL20EAC-N Intel® Apollo Lake N3350 1.1 GHz Graphics Intel® HD Graphics Engine System BIOS Insyde UEFI Specification Watchdog Programmable 256 levels, timer interval 1 to Timer 255 sec. Technology 4GB LPDDR3 1866MHz eMMC Onboard 32 GB Storage mSATA Optional... - Page 25 100 (W) x 70 (H) x 31(D) mm (One layer) Dimensions 100 (W) x 70 (H) x 61(D) mm (Double layer) Weight 0.6 kg (One layer), 0.7 kg (double layer) Desk Mounting (Default), Wall Mounting Mechanical Mounting (Default), VESA Mounting (Optional), DIN-Rail Specification Mounting (Optional), Pole Mounting (Optional) Cooling...
-
Page 26: Appendix
APPENDIX Appendix A: System Dimensions Unit without mounting bracket Standard With Expansion Module With 2 Expansion Modules Unit with mounting bracket - 26 -... -
Page 27: Appendix B: Software Developer Support
Center. Winmate Download Center http://www.winmate.com/>Support > Download Center > Embedded Computing > EAC Mini IL20EAC-N Appendix C: Ordering Information EAC Mini IL20EAC-N IoT Gateway available in the following configurations: Item Specifications Storage Option : 32GB mSATA Option : VESA Mounting Kit... - Page 28 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
