MICROLINE MX Series
Quick Setup Guide
Mantenimiento Periféricos Informáticos SL C/Canteras, 15 28860 Paracuellos de Jarama Tel: 00 34 917481604 WEB: https://mpi.com.es

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MICROLINE MX Series and is the answer not in the manual?

Questions and answers

Related Manuals for Oki MICROLINE MX Series

Summary of Contents for Oki MICROLINE MX Series

  • Page 1 MICROLINE MX Series Quick Setup Guide Mantenimiento Periféricos Informáticos SL C/Canteras, 15 28860 Paracuellos de Jarama Tel: 00 34 917481604 WEB: https://mpi.com.es...
  • Page 2 Mantenimiento Periféricos Informáticos SL C/Canteras, 15 28860 Paracuellos de Jarama Tel: 00 34 917481604 WEB: https://mpi.com.es...
  • Page 3 NOTICE This Quick Setup Guide contains a CD-ROM with the following materials: The User’s Manual • Programmer’s Reference Manuals • Useful utility programs • The CD-ROM is in a plastic pocket in the back cover. Save this guide. If you move or pack the printer in the future, you will need to reverse the instructions in this guide.
  • Page 4 Mantenimiento Periféricos Informáticos SL C/Canteras, 15 28860 Paracuellos de Jarama Tel: 00 34 917481604 WEB: https://mpi.com.es...

  • Page 5: Table Of Contents

    Table of Contents Basic Installation Procedures ....7 Printer Component Locations..........8 Remove Packing Materials...........9 Adjust The Paper Supports ..........14 Release The Paper Chains – Cabinet Model .....15 Remove Tags – Cabinet Model..........16 Remove The Shipping Restraints From The Power Paper Stacker (If Equipped)......17 Attach The Control Panel Overlay........20 Connect The Interface And Power Cables ......21 Cabinet Model ...............21...
  • Page 6 Table of Contents Quick Setup Menu..............52 Print A Test Page ...............57 Mantenimiento Periféricos Informáticos SL C/Canteras, 15 28860 Paracuellos de Jarama Tel: 00 34 917481604 WEB: https://mpi.com.es...

  • Page 7: Basic Installation Procedures

    Basic Installation Procedures This Quick Setup Guide provides general information for setting up and testing your printer. For detailed information, refer to your User’s Manual which is on the CD-ROM attached to the back cover of this guide. Mantenimiento Periféricos Informáticos SL C/Canteras, 15 28860 Paracuellos de Jarama Tel: 00 34 917481604 WEB: https://mpi.com.es...

  • Page 8: Printer Component Locations

    Printer Component Locations Printer Component Locations Familiarize yourself with the names and locations of the printer components, shown in Figure 1, before continuing with the rest of the installation procedures. Barcode Ribbon Ribbon Spool Date Code Label Splined Shaft Paper Support Hammer Bank Cover and Tractor (2)

  • Page 9: Remove Packing Materials

    Remove Packing Materials Remove Packing Materials CAUTION To avoid shipping damage, reinstall the shipping restraints whenever you move or ship the printer. Save the cardboard packing, foam blocks, and bubble wrap along with the other packing materials in case you need to move the printer.
  • Page 10 Remove Packing Materials Envelope Blue Tractor Door (2) Blue Tractor Lock (2) Platen Lever Figure 3. Removing the Sample Configuration Printout 2. Open the blue tractor doors. 3. Move the tractor locks to the middle position to unlock them. 4. Raise the platen lever to the fully open (raised) position. 5.
  • Page 11 Remove Packing Materials Hammer Bank Protective Foam Figure 4. Removing the Hammer Bank Protective Foam 8. Remove the hammer bank protective foam between the ribbon mask and the platen. Mantenimiento Periféricos Informáticos SL C/Canteras, 15 28860 Paracuellos de Jarama Tel: 00 34 917481604 WEB: https://mpi.com.es...
  • Page 12 Remove Packing Materials Platen Protective Foam Figure 5. Removing the Platen Protective Foam 9. Rotate the platen protective foam toward the front of the printer and out from under the support shaft. 10. Remove the platen protective foam. Mantenimiento Periféricos Informáticos SL C/Canteras, 15 28860 Paracuellos de Jarama Tel: 00 34 917481604 WEB: https://mpi.com.es...
  • Page 13 Remove Packing Materials Wooden Block (6) Wooden Block Wooden Block Wooden Block Wooden Block Wooden Block Figure 6. Removing the Six Wooden Blocks 11. Remove the six wooden blocks. Mantenimiento Periféricos Informáticos SL C/Canteras, 15 28860 Paracuellos de Jarama Tel: 00 34 917481604 WEB: https://mpi.com.es...

  • Page 14: Adjust The Paper Supports

    Adjust The Paper Supports Adjust The Paper Supports Paper Support Tab (2) Blue Paper Support (2) Blue Tractor Door (2) Figure 7. Adjusting Paper Supports Squeeze the paper support tabs and slide the blue paper supports inward until each one is approximately four inches from its corresponding blue tractor door.

  • Page 15: Release The Paper Chains - Cabinet Model

    Release The Paper Chains – Cabinet Model Release The Paper Chains – Cabinet Model NOTE: Steps 1– 3 in this section are for the passive stacker. If you have the power paper stacker installed, skip this procedure and go to “Remove The Shipping Restraints From The Power Paper Stacker (If Equipped)”...

  • Page 16: Remove Tags - Cabinet Model

    Remove Tags – Cabinet Model Remove Tags – Cabinet Model NOTE: If you have the power paper stacker installed, skip this procedure and go to “Remove The Shipping Restraints From The Power Paper Stacker (If Equipped)” on page 17. Passive Stacker Paper Fence (if equipped) Tie Wrap...

  • Page 17: Remove The Shipping Restraints From The Power Paper Stacker (If Equipped)

    Remove The Shipping Restraints From The Power Paper Stacker (If Equipped) Remove The Shipping Restraints From The Power Paper Stacker (If Equipped) This section applies only to printers with the power stacker installed. Special packaging protects the power stacker mechanisms from damage during shipment.
  • Page 18 Remove The Shipping Restraints From The Power Paper Stacker (If Equipped) Elevator Lift Handle Tie Wrap (5) Plastic Bag (3) Figure 10. Removing the Shipping Restraints 1. Open the rear door panel. 2. Remove the five tie wraps. 3. Raise the power paper stacker frame to its highest position by pulling up on the elevator lift handle.
  • Page 19 Remove The Shipping Restraints From The Power Paper Stacker (If Equipped) Tape Paper Tent Figure 11. Replacing the Paper Tent 5. Remove the tape holding the paper tent. 6. Place the paper tent onto the pull-out drawer. Mantenimiento Periféricos Informáticos SL C/Canteras, 15 28860 Paracuellos de Jarama Tel: 00 34 917481604 WEB: https://mpi.com.es...

  • Page 20: Attach The Control Panel Overlay

    Attach The Control Panel Overlay Attach The Control Panel Overlay Overlay Label Figure 12. Attaching Control Panel Overlay 1. Choose the overlay label in the appropriate language. 2. Open the printer cover. 3. Peel the protective backing off the overlay and the blue tape from the window.

  • Page 21: Connect The Interface And Power Cables

    Connect The Interface And Power Cables Cabinet Model Connect The Interface And Power Cables Cabinet Model Interface Connections I/O Connectors Power Switch I/O Cover Upper and Lower Standoffs AC Power Connection Cable-Routing Notches Figure 13. Routing the I/O Cable and AC Power Cable 1.
  • Page 22 Connect The Interface And Power Cables I/O Cable Grommet Figure 14. Routing the I/O Cable 3. Hold the I/O cable below its connector and gently push the cable through the opening in the grommet seated in the notch. 4. Pull the cable up through the notch until it reaches the I/O plate. Attach the cable connector to the desired printer interface connector as shown on page 23.

  • Page 23: Interface Connections (Cabinet And Pedestal)

    Interface Connections (Cabinet And Pedestal) Interface Connections (Cabinet And Pedestal) Ethernet option (if installed) or Coax/Twinax (if installed) Centronics Parallel RS-422 (if installed) 9 Pin STD Serial RS-232 9 Pin to 25 Pin STD Serial Adapter Diagnostic Coax/Twinax Network 10/100 Base-T Figure 15.

  • Page 24: Pedestal Model

    Connect The Interface And Power Cables Pedestal Model Power Switch AC Power Connector Figure 16. Attaching the AC Power Cable 1. Make sure the printer power switch is set to O (Off). 2. Remove the cover from the I/O connector you have selected. 3.

  • Page 25: Install The Ribbon And Paper

    Load The Ribbon Install The Ribbon And Paper The following sections describe how to install ribbon and load paper. Load The Ribbon The line matrix printer requires ribbons that work with the Integrated Print Management System. Earlier models and other legacy ribbons do not provide this support and will not work.
  • Page 26 Install The Ribbon And Paper Spool Right Hub Figure 18. Loading the Ribbon 4. Place the full spool on the right hub. Be sure the ribbon feeds off the outside of the spool. 5. Press the spool down until it snaps into place. IMPORTANT The full spool has a barcode label on the bottom side and a date code label on the top.
  • Page 27 Load The Ribbon Ribbon Spool Left Hub Hammer Ribbon Loading Bank Cover Instructions (for future reference) Ribbon Mask Ribbon Guide (both sides) Figure 19. Threading the Ribbon Around the Ribbon Guide 6. Thread the ribbon around the ribbon guide and along the ribbon path.

  • Page 28: Load The Paper (Standard Configuration)

    Install The Ribbon And Paper Load The Paper (Standard Configuration) When you start this procedure, verify that the printer cover is open, the platen lever is raised, and the blue tractor doors are open. See “Printer Component Locations” on page 8. Label Figure 20.
  • Page 29 Load The Paper (Standard Configuration) Wire Guide (2) Paper Paper Slot Slot Metal Paper Guide (MX1200 or MX1200+ only) Cabinet Model Pedestal Model Figure 21. Feeding the Paper Through the Paper Slot Pedestal Model a. Place the paper supply on the floor in front of the printer, or on the optional paper shelf, if attached.
  • Page 30 Install The Ribbon And Paper Left Tractor Door Paper Left Tractor Lock Figure 22. Loading Paper onto the Left Tractor Sprockets 4. Load the paper on the left tractor sprockets. 5. Close the tractor door. Mantenimiento Periféricos Informáticos SL C/Canteras, 15 28860 Paracuellos de Jarama Tel: 00 34 917481604 WEB: https://mpi.com.es...
  • Page 31 Load The Paper (Standard Configuration) CAUTION To avoid damage to the printer caused by printing on the platen, always position the left tractor unit directly to the left of the “1” mark on the paper scale. Tractor Splined Shaft Paper Tractor Paper Scale Figure 23.
  • Page 32 Install The Ribbon And Paper Right Tractor Door Figure 24. Loading the Paper onto the Right Tractor Sprockets 7. Unlock the right tractor. 8. Load the paper onto the right tractor sprockets. 9. Close the tractor door. 10. Make sure the leading edge of the first sheet of paper is parallel to the top of the tractors.
  • Page 33 Load The Paper (Standard Configuration) Vertical Position Knob Paper Thickness Indicator Platen Stop Platen Lever Platen Stop Knob Figure 25. Set the Platen Lever based on the Paper Thickness 13. Raise the platen lever all the way. 14. Turn the vertical position knob to feed the paper up into the paper guide assembly.
  • Page 34 Install The Ribbon And Paper 18. Press the PAPER ADVANCE key several times to make sure the paper feeds properly beyond the tractors over the lower paper guide. Feed sufficient paper to ensure the paper stacks correctly. 19. Close the printer cover. 20.

  • Page 35: Set The Top-Of-Form

    Set The Top-Of-Form Load The Paper (Standard Configuration) Set The Top-Of-Form Every time you load paper, you set the top-of-form (TOF) location. This procedure must be performed the first time paper is introduced into the printer, and every time new paper is loaded. 1.
  • Page 36 Set The Top-Of-Form TOF Indicator Perforation Vertical Position Knob Figure 27. Aligning the First Print Line with the TOF Indicator 3. Locate the TOF indicator. It is a small tab located on both the right and left tractor doors. 4. Turn the vertical position knob to align the top of the first print line with the TOF indicator.
  • Page 37 Set The Top-Of-Form Load The Paper (Standard Configuration) Platen Lever Figure 28. Closing the Platen Lever 5. Lower the platen lever until it stops. 6. Press ON LINE/CLEAR to remove any fault messages (such as “LOAD PAPER”) from the message display. 7.

  • Page 38: Adjust The Passive Paper Stacker - Cabinet Model

    Adjust The Passive Paper Stacker – Cabinet Model Adjust The Passive Paper Stacker – Cabinet Model Passive Stacker Handle Figure 29. Adjusting the Passive Stacker 1. Pull the passive stacker handle up. 2. Move the passive stacker forward or back for proper paper adjustment.

  • Page 39: Power Paper Stacker Option

    Power Paper Stacker Component Locations Power Paper Stacker Option This section explains how to set up and use the optional power paper stacker. The power paper stacker mechanically directs the paper from the printer to the paper stacker. NOTE: If your printer does not have either of these options, go to “Checking The Paper Feed –...

  • Page 40: Setting Up The Power Paper Stacker

    Power Paper Stacker Option Setting Up The Power Paper Stacker Elevator Disable Switch Elevator Lift Handle Paper Advance Stacker Up Stacker Down Figure 31. Use the Rear Control Panel to Set Up the Power Stacker 1. Using the rear control panel, press ON LINE/CLEAR to take the printer offline.
  • Page 41 Setting Up The Power Paper Stacker Paper Stacker Rails Wire Paper Tent Figure 32. Power Stacker Components 3. Make sure the wire paper tent is fitted in the pull out paper tray in the base of the stacker. Mantenimiento Periféricos Informáticos SL C/Canteras, 15 28860 Paracuellos de Jarama Tel: 00 34 917481604 WEB: https://mpi.com.es...
  • Page 42 Power Paper Stacker Option Paper Length Indicator Paddle Shaft Bearing Bracket Figure 33. Setting the Paper Length 4. Set the desired paper length (5 to 12 inch range), as follows: Grasping the paddle shaft, push or pull towards the front or the rear of the printer, setting the desired paper length by aligning the indicator notch on the bearing bracket with the paper length indicator.

  • Page 43: Loading And Starting The Power Paper Stacker

    Loading And Starting The Power Paper Stacker Loading And Starting The Power Paper Stacker Wire Paper Tent Figure 34. Stacking Sheets of Paper on the Wire Paper Tent 1. Using the rear control panel, press the PAPER ADVANCE key and hand feed the paper in the paper throat. Continue to advance the paper until it reaches the wire tent and there is an excess of 3 to 5 pages in the stacker.
  • Page 44 Power Paper Stacker Option Rear Control Panel Paper Guide Figure 35. Returning the Stacker Frame to its Proper Position 3. Press the ON LINE/CLEAR key, from either the front or rear control panel, to put the printer in the online state. The stacker frame then returns to its proper position for printing.

  • Page 45: Checking The Paper Feed - Cabinet Model

    Checking The Paper Feed – Cabinet Model Loading And Starting The Power Paper Stacker Checking The Paper Feed – Cabinet Model Paper Guide Figure 36. Side View of the Cabinet Model Showing Paper Feed Route 1. Check that the paper feeds correctly. 2.

  • Page 46: Attach The Input Paper Shelf And Output Basket - Pedestal Model

    Attach The Input Paper Shelf And Output Basket – Pedestal Model Attach The Input Paper Shelf And Output Basket – Pedestal Model Wire Form Back Stop Optional Input Paper Shelf Output Basket Ground Wire Screw Figure 37. Pedestal Model With Output Basket Attachment Mantenimiento Periféricos Informáticos SL C/Canteras, 15 28860 Paracuellos de Jarama Tel: 00 34 917481604 WEB: https://mpi.com.es...
  • Page 47 Attach The Input Paper Shelf And Output Basket – Pedestal Model Loading And Starting The Power Paper Stacker 1. Squeeze the paper support tabs and slide the two blue paper supports toward the center of the support shaft. Position them so that they divide the space between the tractors into three approximately equal segments.

  • Page 48: Quick Access - Pedestal Model

    Quick Access – Pedestal Model Quick Access – Pedestal Model The quick access cover on the pedestal model allows the paper to exit through the top of the printer. Quick Access Cover Paper Paper Tear Bar Figure 38. Paper Exiting the Top of the Printer (Cover Removed) Mantenimiento Periféricos Informáticos SL C/Canteras, 15 28860 Paracuellos de Jarama Tel: 00 34 917481604 WEB: https://mpi.com.es...
  • Page 49 Quick Access – Pedestal Model Loading And Starting The Power Paper Stacker Top Paper Exit Top Cover Paper Exit Slot Blue Captive Screw (2) Quick Access Paper Deflector Quick Access Blue Deflector Cover Thumbwheel Figure 39. The Quick Access Cover on the Pedestal Model 1.

  • Page 50: Checking The Paper Feed - Pedestal Model

    Checking The Paper Feed – Pedestal Model Checking The Paper Feed – Pedestal Model Rear Exit Top Exit Figure 40. Side View of the Pedestal Model Showing Paper Feed Routes NOTE: When using the top exit paper path, paper cannot be stacked.

  • Page 51: The Control Panel

    The Control Panel Loading And Starting The Power Paper Stacker The Control Panel Message Display PRT CONFIG Emulation Status Indicator Circular SET TOF ONLINE <PGL> RIBBON LIFE = 100% JOB SELECT VIEW/EJECT ON LINE/CLEAR CANCEL Ribbon Life PAPER ADVANCE ENTER Indicator Figure 41.

  • Page 52: Printer Self-Test

    Printer Self-Test When printing stops at 0%, and if immediately changing the ribbon is not convenient, you can place the printer back online and printing will resume for a short period. Printer Self-Test Each time you power on the printer, it executes a self-test. The default power-up state is online.
  • Page 53 Quick Setup Menu Loading And Starting The Power Paper Stacker * = Factory Default If LP+ is selected If installed If ANSI is installed QUICK SETUP If Enet is selected If LG is installed If Wireless is selected If PCL-II is installed If VGL is enabled If PGL is selected If VGL is selected...
  • Page 54 Quick Setup Menu * = Factory Default If LP+ is selected If installed If ANSI is installed If Enet is selected If LG is installed If Wireless is selected If PCL-II is installed QUICK SETUP If VGL is enabled (continued) If VGL is selected Select CPI P-Series...
  • Page 55 Quick Setup Menu Loading And Starting The Power Paper Stacker Device ID This parameter defines the printer emulation as IPDS, 4234-2 or 5225. After the emulation has been changed, a POR status is sent to the host. IPDS is the default. Ethernet Address •...
  • Page 56 Quick Setup Menu Save Config This option allows you to save up to eight configurations to meet different print job requirements. This eliminates the need to change the parameter settings for each new job. The configurations are stored in memory and will not be lost if you turn off the printer. If the Protect Configs.

  • Page 57: Print A Test

    Print A Test Page Loading And Starting The Power Paper Stacker Print A Test Page Now you will print the printer’s current configuration by following the instructions below: Step Press Result Notes Make sure the printer is on. ON LINE/CLEAR OFFLINE QUICK SETUP Allows you to make...
  • Page 58 Print A Test Page Step Press Result Notes Press until the desired Print Config. option displays. UNTIL The configuration listing ENTER OFFLINE begins to print, then the QUICK SETUP printer goes back offline. Carefully tear off the configuration printout. Locks the ENTER key. ENTER SWITCH LOCKED ON LINE/CLEAR...
  • Page 59 Notices This information was developed for products and services offered in the U.S.A. Printronix may not offer the products, services, or features discussed in this document in other countries. Consult your Printronix representative for information on the products and services currently available in your area. Any reference to a Printronix product, program, or service is not intended to state or imply that only that Printronix product, program, or service may be used.
  • Page 60 Notices This publication could include technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these changes will be incorporated in new editions of the publication. Printronix may make improvements and/ or changes in the product(s) described in this publication at any time without notice.
  • Page 61 Note! Before using this information and the product it supports, read the information and Communication Statements on page 64. For online versions of this book, we authorize you to: • Copy, modify, and print the documentation contained on the media, for use within your enterprise, provided you reproduce the copyright notice, all warning statements, and other required statements on each copy or partial copy.
  • Page 62 Energy Star Energy Star The Environmental Protection Agency E Computers NERGY program is a partnership effort with manufacturers of data processing equipment to promote the introduction of energy- efficient personal computers, monitors, printers, fax machines, and copiers to help reduce air pollution and global warming caused by electricity generation.
  • Page 63 Trademarks IBM, AS/400, and Proprinter are registered trademarks, and Intelligent Printer Data Stream and IPDS are trademarks of International Business Machines Corporation. Printronix, PGL, LinePrinter Plus, and IGP are registered trademarks, and P7005, P7010, P7015, P7205, P7210, P7215, P7220, and SureStak are trademarks of Printronix, Inc. ANSI is a registered trademark of the American National Standards Institute, Inc.
  • Page 64 Product Recycling and Disposal Product Recycling and Disposal This unit may have lead-containing materials – such as circuit boards and connectors – that require special handling. Before this unit is disposed of, these materials must be removed and recycled or discarded according to applicable regulations. This book contains specific information on batteries and refrigerant where applicable.
  • Page 65 Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. Printronix is not responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications to this equipment. Unauthorized changes or modifications could void the user’s authority to operate the equipment.
  • Page 66 Communication Statements Properly shielded and grounded cables and connectors must be used in order to reduce the potential for causing interference to radio and TV communications and to other electrical or electronic equipment. Printronix cannot accept responsibility for any interference caused by using other than recommended cables and connectors.
  • Page 67 Dieses Gerät ist berechtigt in Übereinstimmung mit dem Deutschen EMVG das EG-Konformitätszeichen - CE - zu führen. Verantwortlich für die Konformitätserklärung nach Paragraph 5 des EMVG ist die: Printronix Deutschland GmbH, 70548 Stuttgart. Informationen in Hinsicht EMVG Paragraph 4 Abs. (1) 4: Das Gerät erfüllt die Schutzanforderungen nach EN 55024 und EN 55022 Klasse A.
  • Page 68 Communication Statements China Declaration: This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may need to perform practical actions. Mantenimiento Periféricos Informáticos SL C/Canteras, 15 28860 Paracuellos de Jarama Tel: 00 34 917481604 WEB: https://mpi.com.es...
  • Page 69 Taiwan Warning: This is a Class A product. In a domestic environment this product may cause radio interference in which case the user will be required to take adequate measures. Mantenimiento Periféricos Informáticos SL C/Canteras, 15 28860 Paracuellos de Jarama Tel: 00 34 917481604 WEB: https://mpi.com.es...
  • Page 70 Lithium Battery Warning Korea CAUTION: This product is equipped with a 3-wire power cord and plug for the user’s safety. Use this power cord in conjunction with a properly grounded electrical outlet to avoid electrical shock. Lithium Battery Warning The controller board contains a lithium battery sealed inside the real-time clock chip.
  • Page 71 Software License Agreement Your printer contains, among other software, Printronix operating software including, but not limited to the Embedded Configurable Operating System (the “eCos Software”) as embedded software. The terms of this Agreement apply only to the eCos Software, and all other embedded software supplied with the printer.
  • Page 72 Software License Agreement 3. No Warranty THE EMBEDDED SOFTWARE IS PROVIDED UNDER THIS LICENSE ON AN "AS IS" BASIS, WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, WARRANTIES THAT THE EMBEDDED SOFTWARE IS FREE OF DEFECTS, MERCHANTABLE, FIT FOR A PARTICULAR PURPOSE OR NON-INFRINGING.
  • Page 73 5. Limitation of Liability UNDER NO CIRCUMSTANCES AND UNDER NO LEGAL THEORY, WHETHER TORT (INCLUDING NEGLIGENCE), CONTRACT, OR OTHERWISE, SHALL RED HAT, PRINTRONIX, ANY OTHER CONTRIBUTOR, OR ANY DISTRIBUTOR OF THE EMBEDDED SOFTWARE, OR ANY PART THEREOF, OR ANY SUPPLIER OF ANY OF SUCH PARTIES, BE LIABLE TO YOU OR ANY OTHER PERSON FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OF ANY CHARACTER INCLUDING, WITHOUT LIMITATION, DAMAGES...
  • Page 74 Software License Agreement 7. Miscellaneous This Agreement represents the complete agreement concerning subject matter hereof. If any provision of this Agreement is held to be unenforceable, such provision shall be reformed only to the extent necessary to make it enforceable. This Agreement shall be governed by California law provisions (except to the extent applicable law, if any, provides otherwise), excluding its conflict-of- law provisions.
  • Page 75 This document contains proprietary information protected by copyright. No part of this document may be reproduced, copied, translated, or incorporated in any other material in any form or by any means, whether manual, graphic, electronic, mechanical, or otherwise, without the prior written consent of Printronix. Printronix makes no representations or warranties of any kind regarding this material, including, but not limited to, implied warranties of merchantability and fitness for a particular purpose.
  • Page 76 Software License Agreement Mantenimiento Periféricos Informáticos SL C/Canteras, 15 28860 Paracuellos de Jarama Tel: 00 34 917481604 WEB: https://mpi.com.es...
  • Page 77 Index Active IGP Emulation, 55 Input Paper Shelf, pedestal model, 46 Adjust Paper Supports, 14 Interface Connections Adjust Passive Paper Stacker, 38 cabinet model, 21 pedestal model, 23, 24 Cabinet Model interface connections, 21 Load Paper, 28 power connections, 21 Load Ribbon, 25 power paper stacker, 39 release paper chains, 15...
  • Page 78 Index Pedestal Model attach input paper shelf, 46 Release Paper Chains, 15 attach output basket, 46 Remove Packing Materials, 9 interface connections, 24 Remove Tags, 16 power connections, 24 Ribbon End Point, 55 quick access, 48 Ribbon Life Indicator, 51 Power Connections Ribbon, load, 25 cabinet model, 21...
  • Page 79 Mantenimiento Periféricos Informáticos SL C/Canteras, 15 28860 Paracuellos de Jarama Tel: 00 34 917481604 WEB: https://mpi.com.es...
