MICROLINE MX Series
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MICROLINE MX Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Oki MICROLINE MX Series

Summary of Contents for Oki MICROLINE MX Series

  • Page 1 MICROLINE MX Series User’s Manual...
  • Page 3 OKI Microline MX Series Line Matrix Printer User’s Manual...

  • Page 5: Table Of Contents

    Table of Contents 1 Introduction ..........11 Printer Overview ..............11 The OKI Microline MX Series Printer ......11 Integrated Print Management System......13 Graphics Enhancements..........15 Taking Care Of Your Printer..........15 Conventions In This Manual ..........16 Warnings And Special Information ........16 Related Documents .............17 2 Setting Up The Printer ......
  • Page 6 Table of Contents 4 The Configuration Menus......51 Configuration Overview ............51 Changing Parameter Settings ........52 Saving Parameter Settings ...........52 Default And Custom Configurations......53 Navigating The Menus ..........54 Changing Parameters Example ........55 Auto Save Configuration ..........58 Saving Your New Configuration ........59 Optimizing Print Quality..........66 Optimizing Print Speed ..........67 Main Menu................68...
  • Page 7 Table of Contents ACTIVE (IGP) EMUL ............123 IGP/PGL Emulation ............124 Features ..............124 Configuring The Emulation With The Control Panel ...126 IGP/PGL Submenu .............127 IGP/PGL Submenu (with PCL-II) ........129 IGP/PGL Submenu (with LG)........130 IGP/VGL Emulation ............144 Features ..............144 Configuring The Emulation With The Control Panel ...145 IGP/VGL Submenu .............146 IGP/VGL Submenu (with PCL-II) ........148 IGP/VGL Submenu (with LG)........150...
  • Page 8 Table of Contents ANSI Emulation ..............246 IPDS Emulation ..............255 PCL - II Emulation .............261 LG Emulation..............267 PRINTER CONTROL ............274 ADVANCED USER............279 DIAGNOSTICS..............287 5 Interfaces ..........291 Overview................291 Dataproducts Parallel Interface .........292 Dataproducts Parallel Interface Signals ......293 Centronics Parallel Interface ..........294 Centronics Parallel Interface Signals ......295 IEEE 1284 Parallel Interface ..........296 Compatibility Mode............296...
  • Page 9 Table of Contents Printing A Hex Dump...........313 Fault Messages............314 A Printer Specifications......343 Ribbon Specifications ............343 Paper Specifications ............344 Printer Weight And Dimensions.........346 Environmental Characteristics ...........346 Electrical Characteristics ...........348 Interfaces................349 Printing Rates ..............349 B ASCII Character Set......351 C Communication Notices ....... 353 Notices................353 Energy Star................356 Product Recycling and Disposal ........357...
  • Page 10 Table of Contents...

  • Page 11: Introduction

    The OKI Microline MX Series Printer The OKI Microline MX Series printer consists of 500, 1000, 1500, lines per minute (lpm) cabinet and pedestal models and a 2000 lpm cabinet model. All printer models are packaged in various configurations that offer software versatility and the latest refinements in printing technology.
  • Page 12 (lpm): 05 for 500 lpm, 10 for 1000 lpm, 15 for 1500 lpm, and 20 for 2000 lpm. Refer to the following table for a complete listing of model numbers and options. Table 1. The OKI Microline MX Series Printer Model Print Model Type...

  • Page 13: Integrated Print Management System

    Integrated Print Management System Integrated Print Management System The P7000 has a new feature that automatically monitors and communicates ribbon life. Using a specially barcoded spool, the printer can automatically detect when a new or used ribbon is loaded, and all ribbon properties. With a sophisticated algorithm, the system monitors all jobs printed and automatically updates the remaining ribbon life on the front panel display.
  • Page 14 Chapter 1 Printer Overview If a lighter setting is selected, the system will extend the amount of printing it takes to reach zero. Ribbon Flipping In some cases, the application’s print pattern is narrow enough where only half of the ribbon is used when printing. In these cases, you can flip the ribbon and use the other half.

  • Page 15: Graphics Enhancements

    Graphics Enhancements Consumable Monitoring With PrintNet Enterprise The Integrated Print Management System works with PrintNet Enterprise (PNE). PNE allows a system administrator to remotely view the current consumable status of all printers. PNE can be configured to deliver alerts on all consumable warnings. When a ribbon reaches the low state, PNE notifies the system administrator remotely via an automated e-mail alert of the low condition.

  • Page 16: Conventions In This Manual

    Chapter 1 Conventions In This Manual Conventions In This Manual All uppercase print indicates control panel keys. Example: Press the CLEAR key, then press the ON LINE key. Quotation marks (“ ”) indicate messages on the Liquid Crystal Display (LCD). Example: Press the ON LINE key.

  • Page 17: Related Documents

    Related Documents Taking Care Of Your Printer Related Documents • Maintenance Manual — Explains how to maintain and repair the line matrix printer at the field service level of maintenance. • Coax/Twinax Programmer's Reference Manual — Covers the host control codes and character sets for the Coax and Twinax emulations.
  • Page 18 Chapter 1 Related Documents...

  • Page 19: Setting Up The Printer

    Setting Up The Printer Before You Begin Read this chapter carefully before installing and operating the printer. The printer is easy to install. However, for your safety and to protect valuable equipment, perform all the procedures in this chapter in the order presented. Power Requirements The printer must be connected to a power outlet that supplies AC 100V to 240V +/- 10% at 50 to 60 Hz.

  • Page 20: Select A Site

    Chapter 2 Select A Site Select A Site Select a printer site that meets all of the following requirements: • Permits complete opening of the printer cover and doors. • For cabinet models, allows at least three feet of clearance behind the printer.

  • Page 21: Printer Dimensions

    Printer Dimensions Printer Dimensions 41.0 in 57.5 in (104 cm) (146.1 cm) 27.0 in (68.84 cm) 29.0 in (73.7 cm) 27.0 in 83.0 in (68.6 cm) (210.8 cm) 27.0 in (68.6 cm) Figure 1. Printer Dimensions - Cabinet Model...
  • Page 22 Chapter 2 Printer Dimensions 59.0 in (149.9 cm) 42.5 in (107.8 cm) 27.0 in (68.6 cm) 32.5 in (82.6 cm) 27.0 in 83.0 in (68.6 cm) (210.8 cm) 32.0 in 27.0 in (81.3 cm) (68.6 cm) Figure 2. Printer Dimensions - Cabinet Model with Paper Stacker...
  • Page 23 Printer Dimensions 25 in. (63.5 cm) 48.0 in. (122 cm) 10.5 in. (26.67 cm.) 30 in. 24.6 in. (76.2 cm.) (62.48 cm) Figure 3. Printer Dimensions - Pedestal Model...

  • Page 24: Printer Component Locations

    Chapter 2 Printer Component Locations Printer Component Locations Barcode Ribbon Ribbon Spool Date Code Label Splined Shaft Paper Support Hammer Bank Cover and Tractor (2) Ribbon Mask Ribbon Hub Vertical Position Knob Blue Tractor Lock (2) Platen Lever Barcode Sensor Platen Stop Ribbon Guide (2) Figure 4.

  • Page 25: Operating The Printer

    Operating The Printer Powering On The Printer When you power on the printer, it executes a self-test. The default power-up state is online. When the self-test completes and the software has initialized successfully, the status indicator light turns on, indicating the printer is online. The default value of the type of emulation you have installed appears upper right corner of the display.

  • Page 26: The Control Panel

    Chapter 3 The Control Panel beeps (if configured to sound), and a descriptive fault message displays. The current operating mode can be selected via control panel keys or can result from routine operations such as powering on the printer. The Control Panel Figure 5 shows the keys, displays, and indicators as they appear on the control panel.

  • Page 27: Control Panel Keys

    Control Panel Keys Control Panel Keys ON LINE / CLEAR Toggles the printer between online and offline modes. If a fault condition exists, pressing this key will clear the fault message and return the printer from fault mode to offline mode. NOTE: If the fault condition is not corrected before pressing this key, the fault message will reappear when attempting to place the printer online.
  • Page 28 Chapter 3 The Control Panel microstep feature. Pressing VIEW/EJECT a second time moves the paper back to the adjusted print position. Eject Function — for pedestal models, when the VIEW/EJECT key is pressed, the bottom of the last printed form will move to the tear bar position.
  • Page 29 Control Panel Keys JOB SELECT In offline mode, this key allows you to change the active configuration if multiple configurations have been saved or the typeface of the printer. ENTER When navigating the configuration menus, ENTER selects the currently displayed option value as the active value. An asterisk (*) appears next to the active value on the display.
  • Page 30 Chapter 3 The Control Panel < PREV or NEXT ( Moves between the options on the current level of configuration menu. In the configuration menu, press to scroll backward or < press to scroll forward through the menu selections on the same level.
  • Page 31 Control Panel Keys + VIEW (IPDS Emulation only) In offline mode, press + VIEW. If there is data in the IPDS printer buffer, the printer will be placed in online mode, print one line, and return to offline mode. This action can be repeated until the end of the job.

  • Page 32: Operational Procedures

    Chapter 3 Operational Procedures Operational Procedures This section contains routine printer operating procedures on how • reload paper • unload paper • cancel a print job. Reload Paper Do this procedure when “LOAD PAPER” displays. (This message occurs when the last sheet of paper passes through the paper slot.) This procedure reloads paper without removing the last sheet of the old paper supply, while retaining the current top-of-form setting.
  • Page 33 Reload Paper 1. Raise the printer cover. Raise the platen lever as far as it will go. (See Figure 4 on page 24 for the location of the lever.) 2. Press ON LINE/CLEAR to turn off the alarm. Do not open the tractor doors or remove the existing paper.
  • Page 34 Chapter 3 Operational Procedures New Paper Existing Paper Figure 7. Loading New Paper into the Printer 6. Pull the new paper above and behind the ribbon mask, but in front of the existing paper. See Figure 4 on page 24 for the ribbon mask location.
  • Page 35 Reload Paper Vertical Position Knob Paper Thickness Indicator Platen Stop Platen Lever Platen Stop Knob Figure 8. Setting the Platen Lever 9. Turn the vertical position knob to feed the paper up into the paper guide assembly, removing the last printed sheet. 10.
  • Page 36 Chapter 3 Operational Procedures 13. Press PAPER ADVANCE several times to make sure the paper feeds properly beyond the tractors and over the lower paper guide. Feed sufficient paper to ensure the paper stacks correctly. 14. Close the printer top cover. Close the cabinet front door. 15.
  • Page 37 Reload Paper Left Tractor Door Paper Left Tractor Lock Figure 10. Loading Paper on the Left Tractor 19. Pull the paper above and behind the ribbon mask. See Figure 4 on page 24 for the ribbon mask location. 20. Load the paper on the left tractor. 21.
  • Page 38 Chapter 3 Operational Procedures Tractor Splined Tractor Shaft Paper Scale Figure 11. Positioning the Left Tractor to Avoid Damage CAUTION To avoid damage to the printer caused by printing on the platen, always position the left tractor unit directly to the left of the “1”...
  • Page 39 Reload Paper Tractor Door Tractor Lock Figure 12. Loading Paper onto the Sprockets 23. Unlock the right tractor. 24. Load the paper onto the sprockets and close the tractor door. If necessary, slide the right tractor to remove paper slack or to adjust for various paper widths.
  • Page 40 Chapter 3 Operational Procedures Upper Paper Upper Paper Guide Guide Upper Paper Guide Wire Guide (2) Paper Slot Cabinet Model Pedestal Model Figure 13. Using the Paper Guide to Orient the Paper 25. Pedestal models: Using the vertical position knob to move the paper up, guide the paper over the upper paper guide and through the slot to the rear of the top cover.
  • Page 41 Reload Paper Perforation TOF Indicator Vertical Position Knob Figure 14. Aligning the Perforation with the TOF Indicator 28. Align the top of the first print line with the TOF indicator on the tractor by rotating the vertical position knob. For best print quality, it is recommended that the top-of-form be set at least one print line or more below the perforation.
  • Page 42 Chapter 3 Operational Procedures Vertical Position Knob Paper Thickness Indicator Platen Stop Platen Lever Platen Stop Knob Figure 15. Adjusting the Platen Lever 29. Turn the Auto Platen Stop Knob clockwise or counterclockwise to match the paper thickness. (The A-B-C scale corresponds approximately to 1-, 3-, and 6-part paper thickness.

  • Page 43: Unload Paper

    Unload Paper Unload Paper 1. Press ON LINE/CLEAR to place the printer in offline mode and open the printer cover. 2. For cabinet models, open the cabinet rear door. For models with the power stacker installed, press the STACKER UP key on the rear control panel.
  • Page 44 Chapter 3 Operational Procedures Paper Power Stacker Figure 17. Removing Stacked Paper from the Printer 6. For cabinet models, remove the stacked paper from the rear cabinet floor. For cabinet models with the power stacker installed, remove the paper from the wire paper tent and press the STACKER DOWN key to lower the stacker mechanism.
  • Page 45 Unload Paper Tractors Doors (2) Platen Lever Figure 18. Completely Removing the Paper 8. To completely remove the paper from the printer: a. Raise the platen lever as far as it will go and open both tractor doors. CAUTION Be careful when pulling any paper backward through the paper path, especially when using a label stock.

  • Page 46: Integrated Print Management System

    Chapter 3 Integrated Print Management System Integrated Print Management System The Integrated Print Management System feature automatically monitors and communicates the status of the ribbon’s life to help the operator know when to change ribbons. Using a special bar coded spool, the printer automatically detects when a new or used ribbon is installed and determines the ribbon’s length, ink color, and expected yield.

  • Page 47: Changing Ribbons

    Changing Ribbons Changing Ribbons Before changing the ribbon, determine whether you want to make the print lighter (extend the ribbon life) or darker (shorten the ribbon life). If you want to make the print lighter, go to “Ribbon End Point” on page 275 and follow the procedures for adjusting the image density.
  • Page 48 Chapter 3 Integrated Print Management System Date Code Label Spool Right Hub Figure 20. Loading the Barcoded Ribbon 5. Place the full spool on the right hand side ribbon hub and press it into place. IMPORTANT The full spool has a barcode label on the bottom side and a date code label on the top.
  • Page 49 Changing Ribbons Ribbon Spool Left Hub Hammer Ribbon Loading Bank Cover Instructions For Future Reference Ribbon Mask Ribbon Guide (Both Sides) Figure 21. Threading the Ribbon Around the Ribbon Guide 6. Thread the ribbon around the ribbon guide and along the ribbon path.

  • Page 50: Cancel A Print Job

    Chapter 3 Integrated Print Management System 9. Turn the left spool by hand to make sure the ribbon tracks correctly in the ribbon path and around the ribbon guides. 10. Close the platen lever. 11. Close the printer top cover. If you want to increase the darkness level of the ribbon at the end of life, go to “Ribbon End Point”...

  • Page 51: The Configuration Menus

    The Configuration Menus Configuration Overview To print data, the printer must respond correctly to signals and commands received from the host computer. Configuration is the process of matching the printer's operating characteristics to those of the host computer and to specific tasks, such as printing labels or printing on different sizes of paper.

  • Page 52: Changing Parameter Settings

    Chapter 4 Configuration Overview Changing Parameter Settings You may change a printer parameter setting, such as line spacing or forms length, either by pressing keys on the control panel or by sending emulation control codes in the data stream from a host attached to the printer.

  • Page 53: Default And Custom Configurations

    Default And Custom Configurations Default And Custom Configurations A configuration consists of a group of parameter settings, such as line spacing, forms length, etc. Your printer provides a fixed default configuration and allows you to define several custom configurations for use with particular print jobs.The factory default configuration can be loaded, but it cannot be altered.

  • Page 54: Navigating The Menus

    Chapter 4 Configuration Overview Navigating The Menus To manipulate configurations review the following instructions about navigating through the menus. You must be offline to move within the menus. Press to toggle between ONLINE and ON LINE/CLEAR OFFLINE. Menus are accessed with the printer offline.

  • Page 55: Changing Parameters Example

    Changing Parameters Example Changing Parameters Example * = Factory Default OFFLINE QUICK PRINTER . . . SETUP CONTROL Ribbon End Open Platen Barcode Tear Bar Point @ BOF Quality Dist. Darker +6 Disable* Dark* 7.46 in.* Darker +5 Enable Draft (4.5-10.5 in.) Darker +4 Darker +3...
  • Page 56 Chapter 4 Configuration Overview Step Press Notes Make sure the printer is on. OFFLINE ON LINE/CLEAR QUICK SETUP ENTER SWITCH Allows you to make UNLOCKED configuration changes. OFFLINE QUICK SETUP OFFLINE PRINTER CONTROL UNTIL PRINTER CONTROL Ribbon End Point PRINTER CONTROL Barcode Quality UNTIL Barcode Quality...
  • Page 57 Changing Parameters Example Step Press Notes Barcode Quality Cycle through the Draft choices. Barcode Quality The * indicates this choice ENTER Draft* is active. PRINTER CONTROL Barcode Quality PRINTER CONTROL Display Language UNTIL Display Language English* Display Language Press until the desired Spanish parameter displays.

  • Page 58: Auto Save Configuration

    Chapter 4 Configuration Overview Step Press Notes ENTER = Save Press ENTER to ON LINE/CLEAR ONLINE = No Save automatically save configuration changes. Press ONLINE to continue without saving. 17A. Cfg = 1* Configuration changes ENTER = Power-Up Cfg have been saved as Configuration 1, and will be set as the Power-Up config.

  • Page 59: Saving Your New Configuration

    Saving Your New Configuration Saving Your New Configuration The Save Config. option allows you to save up to eight custom configurations to meet different print job requirements. Once you have changed all of the necessary parameters, you may save them as a numbered configuration (Example 1 on page 60) or a named configuration (Example 2 on page 63) that can be stored and loaded later for future use.
  • Page 60 Chapter 4 Configuration Overview Example 1 This example shows how to save a configuration as a numbered configuration, then later print it. Step Press Notes Make sure the printer is on. OFFLINE ON LINE/CLEAR CONFIG. CONTROL ENTER SWITCH Allows you to make UNLOCKED configuration changes.
  • Page 61 Saving Your New Configuration Step Press Notes Save Config. Cycle through the choices. Save Config. The * indicates this choice ENTER is active. NOTE: We recommend that you print the configuration. To print the configuration go to Step 9. To skip this procedure and resume printer operation, go to Step 14.
  • Page 62 Chapter 4 Configuration Overview Step Press Notes ENTER SWITCH Locks the ENTER key. LOCKED ONLINE ON LINE/CLEAR Ribbon Life = 100% If you printed out the configuration, store it in a safe place. The printer is ready for operation.
  • Page 63 Saving Your New Configuration Example 2 This example shows how to save a configuration as a named configuration. Step Press Notes Make sure the printer is on. OFFLINE ON LINE/CLEAR CONFIG. CONTROL ENTER SWITCH Allows you to make UNLOCKED configuration changes. OFFLINE QUICK SETUP OFFLINE...
  • Page 64 Chapter 4 Configuration Overview Step Press Notes Name Configs You will rename config 2. UNTIL Cycle through the choices until “T” displays. UNTIL Saves the first character. Cycle through the choices until “E” displays. UNTIL Saves the second character. Cycle through the choices until “S”...
  • Page 65 Saving Your New Configuration Step Press Notes Cycle through the choices TEST until “T” displays. UNTIL Saves the fourth TEST_ character. Name Configs The configuration is ENTER TEST renamed TEST. CONFIG. CONTROL Name Configs CONFIG. CONTROL Save Config. UNTIL Save Config. Save Config.

  • Page 66: Optimizing Print Quality

    Chapter 4 Configuration Overview Step Press Notes ENTER SWITCH Locks the ENTER key. LOCKED ONLINE ON LINE/CLEAR Ribbon Life = 100% Now you have the saved configuration for later use if needed. Optimizing Print Quality LP+, IGP/PGL, and IGP/VGL Emulations You can optimize print quality for darker and sharper barcodes and characters.

  • Page 67: Optimizing Print Speed

    Optimizing Print Speed Optimizing Print Speed LP+, IGP/PGL, and IGP/VGL Emulations The printer has been configured at the factory for optimal print speed. To optimize print quality instead, you can change values for specific configuration parameters such as Barcode Quality and Print Quality.

  • Page 68: Main Menu

    Chapter 4 Main Menu Main Menu OFFLINE QUICK CONFIG. HOST NETWORK ACTIVE SETUP CONTROL INTERFACE SETUP (IGP) EMUL page 71 page 80 page 83 page 106 page 123 Host Interface Load Config. Auto Switching* Adapter Address IGP/PGL* Device ID Save Config. Dataproducts Adapter Params IGP/VGL...
  • Page 69 Main Menu Optimizing Print Speed EMULATION PRINTER ADVANCED DIAGNOSTICS CONTROL USER page 164 page 274 page 279 page 287 CTHI Ribbon End Point Ptx Setup Option Printer Tests LinePrinter+ Eject Function Hex Dump Mode Test Width 44/48XX-ANSI Open Platen @ BOF Power-up State Paper Out Dots IGP/PGL...
  • Page 70 Chapter 4 Main Menu Brief descriptions follow for the first-level configuration menu options: • QUICK SETUP — These options allow quick access to the most frequently changed or inputted parameters during the installation of the printer. • CONFIG. CONTROL — These options allow you to save, print, load, delete, name, and reset entire sets of configuration parameters.

  • Page 71: Quick Setup

    QUICK SETUP Optimizing Print Speed QUICK SETUP * = Factory Default If LP+ is selected If installed If ANSI is installed QUICK SETUP If Enet is selected If LG is installed (from page 68) If Wireless is selected If PCL-II is installed If VGL is enabled If PGL is selected If VGL is selected...
  • Page 72 Chapter 4 QUICK SETUP * = Factory Default If LP+ is selected If installed If ANSI is installed If Enet is selected If LG is installed QUICK SETUP If Wireless is selected If PCL-II is installed (continued) If VGL is enabled If VGL is selected Select CPI P-Series...
  • Page 73 QUICK SETUP Optimizing Print Speed Host Interface The Host Interface menu enables you to select and configure interfaces between the printer and your host computer. Device ID This parameter defines the printer emulation as IPDS, 4234-2 or 5225. After the emulation has been changed, a POR status is sent to the host.
  • Page 74 Chapter 4 QUICK SETUP Ethernet Address • IP Address. A numeric address such as 123.45.61.23 which identifies a printer or server in a LAN or WAN. • Subnet Mask. A binary value used to divide IP networks into smaller subnetworks or subnets. This mask is used to help determine whether IP packets need to be forwarded to other subnets.
  • Page 75 QUICK SETUP Optimizing Print Speed Active IGP Emulation The Active Emulation menu enables you to activate either the PGL or VGL emulation. PGL SFCC You can specify which hex code (1-FF) will be used as the Special Function Control Character (SFCC). The SFCC denotes that the following data is an IGP command.
  • Page 76 Chapter 4 QUICK SETUP Select CPI This parameter lets you specify the characters per inch (cpi) values. Select LPI This parameter lets you specify the lines per inch (lpi) values. P-Series SFCC This parameter allows you to select which ASCII codes will function as the Special Function Control Code (SFCC) command delimiter.

  • Page 77: Form Width

    QUICK SETUP Optimizing Print Speed Form Length Form length is the number of lines that can be printed on a page. You can set the form length in inches, millimeters (mm), or as a function of the current lpi (lines per inch). Form Width The form width can be specified in inches, millimeters, or as a function of the current cpi (characters per inch).
  • Page 78 Chapter 4 QUICK SETUP Horiz Forms • Left Mgr 0.00 (default). This sets the left margin for the forms. You must specify the left margin in 1/10 inch increments, from 0 to 13.1 inches. The default value is 0. Press the right arrow to increase the value, left arrow to decrease the value, and ENTER to change units.
  • Page 79 QUICK SETUP Optimizing Print Speed Save Config This option allows you to save up to eight configurations to meet different print job requirements. This eliminates the need to change the parameter settings for each new job. The configurations are stored in memory and will not be lost if you turn off the printer. If the Protect Configs.

  • Page 80: Config. Control

    Chapter 4 CONFIG. CONTROL CONFIG. CONTROL The CONFIG. CONTROL menu allows you to control your printer’s configurations according to the specifications necessary for your print jobs. * = Factory Default CONFIG. CONTROL (from page 68) Load Print Delete Save Power-Up Protect Config.

  • Page 81: Protect Configs

    CONFIG. CONTROL Optimizing Print Speed Save Config. This option allows you to save up to eight configurations to meet different print job requirements. This eliminates the need to change the parameter settings for each new job. The configurations are stored in memory and will not be lost if you turn off the printer. If the Protect Configs.

  • Page 82: Name Configs

    Chapter 4 CONFIG. CONTROL Name Configs You may specify a 15-character name which can be used to refer to a configuration. The name you enter for a configuration will be used in the Load Config., Save Config., Print Config., Delete Config., and Power-Up Config.

  • Page 83: Host Interface

    HOST INTERFACE Optimizing Print Speed HOST INTERFACE * = Factory Defaultt HOST INTERFACE (from page 68) Auto Twinax Coax IEEE 1284 Centronics Dataproducts Switching* (Available with (Available with (see page 89) (see page 92) (see page 84) (see page 86) CT Option) CT Option) Serial...

  • Page 84: Auto Switching Submenu

    Chapter 4 HOST INTERFACE Auto Switching Submenu * = Factory Default If Installed Auto Switching (from page 83) Parallel Serial Ethernet Hotport Hotport Hotport Hotport Port Type Timeout Port Type Port Type Centronics* RS 232* 10 sec.* Twinax* (see page 89 for options) RS 422 (10-60) Coax...

  • Page 85: Auto Switching

    Auto Switching Submenu Auto Switching Gives the printer the ability to handle multiple data streams sequentially. With Auto Switching, the printer can service hosts attached to the serial, parallel, Ethernet, coax and twinax ports as if they were the only interface connected. For example, if the host computer sends one print job to the RS-232 serial port and a separate print job to the IEEE 1284 parallel port, the printer's Auto Switching is able to handle both...

  • Page 86: Ieee 1284 Parallel (Bidirectional) Submenu

    Chapter 4 HOST INTERFACE Timeout This is the value used by the printer to time out from the current port and check the other selected port types for data to print. When the printer has not received data from the host after a certain period of time, it needs to timeout in order to service the other ports.
  • Page 87 IEEE 1284 Parallel (Bidirectional) Submenu Prime Signal • Disable (default). The parallel port will not perform a warm start (reboot) if the host asserts the prime signal. • Enable. The parallel port will perform a warm start (reboot) if the host asserts the prime signal. TOF Action •...
  • Page 88 Chapter 4 HOST INTERFACE For example, if the printer is printing a job from the serial port, and then receives a second print job from the parallel port, the data from the parallel port will “trickle” bit by bit into the printer buffer to prevent a timeout error from being sent back to the host connected to the parallel port.

  • Page 89: Centronics (Parallel) Submenu

    Centronics (Parallel) Submenu Centronics (Parallel) Submenu * = Factory Default Centronics (from page 83) Data Bit 8 PI Ignored Data Resp. Busy on Latch Data Polarity Polarity Strobe Enable* Enable* Standard* Standard* Enable* Leading* Disable Disable Inverted Inverted Disable Trailing Prime TOF Action Buffer Size...
  • Page 90 Chapter 4 HOST INTERFACE PI Ignored The PI (Paper Instruction) signal is used to control vertical paper motion. • Enable (default). Ignores the PI signal and treats the data as characters or control codes. • Disable. Causes the printer to interpret the eight data lines as VFU commands when the PI signal is true.
  • Page 91 Centronics (Parallel) Submenu Prime Signal • Enable (default). The parallel port will perform a warm start (reboot) if the host asserts the prime signal. • Disable. The parallel port will not perform a warm start (reboot) if the host asserts the prime signal. TOF Action •...

  • Page 92: Dataproducts (Standard) Submenu

    Chapter 4 HOST INTERFACE For example, if the printer is printing a job from the serial port, and then receives a second print job from the parallel port, the data from the parallel port will “trickle” bit by bit into the printer buffer to prevent a timeout error from being sent back to the host connected to the parallel port.
  • Page 93 Dataproducts (Standard) Submenu Data Bit 8 • Enable (default). Allows access to the extended ASCII character set. • Disable. The printer interprets bit 8 of each incoming data character as a zero, regardless of its actual setting. PI Ignored The PI (Paper Instruction) signal is used to control vertical paper motion.
  • Page 94 Chapter 4 HOST INTERFACE Prime Signal • Disable (default). The parallel port will not perform a warm start (reboot) if the host asserts the prime signal. • Enable. The parallel port will perform a warm start (reboot) if the host asserts the prime signal. TOF Action •...
  • Page 95 Dataproducts (Standard) Submenu For example, if the printer is printing a job from the serial port, and then receives a second print job from the parallel port, the data from the parallel port will “trickle” bit by bit into the printer buffer to prevent a timeout error from being sent back to the host connected to the parallel port.

  • Page 96: Serial Submenu

    Chapter 4 HOST INTERFACE Serial Submenu * = Factory Default Serial (from page 83) Interface Data Baud Word Stop Parity Type Protocol Rate Length 8 Bits 1 RS 232* XON/XOFF* 9600 Baud* None* RS 422 ETX/ACK 19200 Baud ACK/NAK 38400 Baud Even Series1 1 Char 57600 Baud...

  • Page 97: Interface Type

    Serial Submenu Interface Type This parameter allows you to select either the RS-232 or RS-422 serial port interface. Data Protocol You can select one of the following serial interface protocols to meet the host interface requirements. • XON / XOFF (default). The printer controls the flow of communication from the host by turning the transmission on and off.
  • Page 98 Chapter 4 HOST INTERFACE SERIES1 1 CHAR. The printer controls the flow of communication from the host by turning the transmission on and off using response characters sent to the host. If the number of valid bytes in the buffer reaches 75 percent of the buffer size, the online or offline and buffer full response character is sent.
  • Page 99 Serial Submenu The response characters are described in Table 3. Table 3. Series1 1 Char Response Characters Printer State Response Online and Buffer Empty Online and Buffer Full Offline and Buffer Empty Offline and Buffer Full • SERIES1 2 CHAR. This protocol behaves exactly the same as the Series1 Char except there is a two-character response to the host.

  • Page 100: Baud Rate

    Chapter 4 HOST INTERFACE Baud Rate Sets the baud rate of the serial interface in the printer. Baud rate is the speed at which serial data is transferred between the host computer and the printer. The choices for the RS-232 and RS-422 interfaces are 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600, and 115200 Baud.

  • Page 101: Data Term Ready

    Serial Submenu Data Term Ready This configuration is part of hardware flow control and determines when the Data Terminal Ready (DTR) signal is generated. This signal indicates if the printer is ready to receive data. • True (default). Continuously asserts the DTR signal. •...

  • Page 102: Poll Character

    Chapter 4 HOST INTERFACE Buffer Size in K This option configures the amount of memory allocated for the serial port buffer. You may specify between 1 and 16 Kbytes, in 1-Kbyte increments. NOTE: If you select a baud rate that is 19200 or greater, you may need to increase the Buffer Size in K parameter to improve performance.

  • Page 103: One Char Enquiry

    Serial Submenu One Char Enquiry The One Char Enquiry mode uses the Poll Character to detect a request from the host and sends a response back to the host. This option also allows you to turn on and off this feature. Table 5.

  • Page 104: E-Net Adapter Submenu

    Chapter 4 HOST INTERFACE E-Net Adapter Submenu * = Factory Default E-Net Adapter (from page 83) Buffer Size in K 1-16 The E-Net Adapter interface allows you to locate the printer on a LAN rather than attach the host directly into the printer. The detailed configuration of this option is given in the PrintNet User's Manual .

  • Page 105: Ethernet Submenu

    Ethernet Submenu Ethernet Submenu * = Factory Default Ethernet (from page 83) Buffer Size in K 1-16 The Ethernet interface allows you to locate the printer on a LAN rather than attach the host directly into the printer. The detailed configuration of this option is given in the Network Interface Card User's Manual .

  • Page 106: Network Setup Menu

    Chapter 4 NETWORK SETUP MENU NETWORK SETUP MENU NETWORK SETUP (from page 68) ADAPTER ADAPTER ETHERNET ETHERNET WLAN ADDRESS PARAMS ADDRESS PARAMS ADDRESS See page 107. See page 108. See page 111. See page 113. See page 115. WLAN WLAN WLAN PARAMS Kerberos...

  • Page 107: Adapter Address

    ADAPTER ADDRESS ADAPTER ADDRESS * = Factory Default ADAPTER ADDRESS (from page 106) DHCP IP Address Subnet Gateway Mask Address Address Disable* xxx.xxx.xxx.xxx xxx.xxx.xxx.xxx xxx.xxx.xxx.xxx hhhhhhhhhhhh Enable IP Address A numeric address such as 123.45.61.23 which identifies a printer or server in a LAN or WAN. Subnet Mask A binary value used to divide IP networks into smaller subnetworks or subnets.

  • Page 108: Adapter Params

    Chapter 4 NETWORK SETUP MENU DHCP You can enable/disable the DHCP protocol using this option, but consult your administrator for the appropriate setting. The options include: • Disable (default) • Enable. ADAPTER PARAMS ADAPTER * = Factory Default PARAMS (from page 106) NetBIOS Novell ASCII...

  • Page 109: Novell Protocol

    ADAPTER PARAMS Novell Protocol This option determines whether the Novell protocol will be available. The selections are as indicated below: • Enable (default). Makes the Novell protocol available with the ethernet installed. • Disable. Makes the Novell protocol unavailable during printer operation.
  • Page 110 Chapter 4 NETWORK SETUP MENU ASCII Data Port This option sets the port number for ASCII print jobs. The data port number needs to match your host system setting. • 9100 (default) • 1023 - 65535 IPDS Data Port This option allows you to set the port number for IPDS print jobs only if the IPDS option is installed.

  • Page 111: Ethernet Address

    ETHERNET ADDRESS • 100 Half Duplex. Tells the 10/100Base-T NIC to communicate at 100 Megabits per second using half duplex. • 100 Full Duplex. Tells the 10/100Base-T NIC to communicate at 100 Megabits per second using full duplex. Job Control The job control mode has three options: •...

  • Page 112: Subnet Mask

    Chapter 4 NETWORK SETUP MENU Subnet Mask A binary value used to divide IP networks into smaller subnetworks or subnets. This mask is used to help determine whether IP packets need to be forwarded to other subnets. Gateway Address A gateway address is the IP address of a hardware device (gateway) that translates data between two incompatible networks, which can include protocol translation.

  • Page 113: Ethernet Params

    ETHERNET PARAMS ETHERNET PARAMS ETHERNET * = Factory Default PARAMS (from page 106) NetBIOS ASCII IPDS Data Keep Alive Ethernet Protocol Data Port Port Timer Speed Enable* 9100* 5001* 3 Minutes* Auto Select* Disable 1023 - 65535 1023 - 65535 2 - 10 Minutes 10 Half Duplex 10 Full Duplex...
  • Page 114 Chapter 4 NETWORK SETUP MENU ASCII Data Port This option sets the port number for ASCII print jobs. The data port number needs to match your host system setting. • 9100 (default) • 1023 - 65535 IPDS Data Port This option allows you to set the port number for IPDS print jobs only if the IPDS option is installed.

  • Page 115: Wlan Address

    WLAN ADDRESS • 100 Half Duplex. Tells the 10/100Base-T NIC to communicate at 100 Megabits per second using half duplex. • 100 Full Duplex. Tells the 10/100Base-T NIC to communicate at 100 Megabits per second using full duplex. Job Control The job control mode has three options: •...
  • Page 116 Chapter 4 NETWORK SETUP MENU Subnet Mask A binary value used to divide IP networks into smaller subnetworks or subnets. This mask is used to help determine whether IP packets need to be forwarded to other subnets. Gateway Address A gateway address is the IP address of a hardware device (gateway) that translates data between two incompatible networks, which can include protocol translation.

  • Page 117: Wlan Params

    WLAN PARAMS WLAN PARAMS WLAN * = Factory Default PARAMS (from page 106) NetBIOS ASCII IPDS Data Keep Alive Ethernet Protocol Data Port Port Timer Speed Enable* 9100* 5001* 3 Minutes* Auto Select* Disable 1023 - 65535 1023 - 65535 2 - 10 Minutes 10 Half Duplex 10 Full Duplex...
  • Page 118 Chapter 4 NETWORK SETUP MENU ASCII Data Port This option sets the port number for ASCII print jobs. The data port number needs to match your host system setting. • 9100 (default) • 1023 - 65535 IPDS Data Port This option allows you to set the port number for IPDS print jobs only if the IPDS option is installed.

  • Page 119: Wlan Kerberos

    WLAN KERBEROS WLAN KERBEROS * = Factory Default WLAN 1 = Only if a Symbol radio card is installed. Kerberos (from page 106) Kerberos Reset Kerberos KDC Port Kerberos Enable Password Number Password Disable* Kerberos Password (01-15) 0-65535 Enable Kerberos Password (16-30) Kerberos Password (31-40) Clock Skew Ticket Lifetime...
  • Page 120 Chapter 4 NETWORK SETUP MENU Kerberos Password • Kerberos Password (01-15). The first 15 characters of the Kerberos password (maximum number of characters is 40). • Kerberos Password (16-30). Characters 16 to 30 of the Kerberos password (maximum number of characters is 40). •...

  • Page 121: Wlan Leap

    WLAN LEAP Renew Lifetime Sets the maximum allowable amount of time in Seconds, Minutes, Hours, or Days before warning that a new Kerberos password is needed. • Seconds. The range is 0-604800, and the default is 0. • Minutes. The range is 0-10080, and the default is 0. •...
  • Page 122 Chapter 4 NETWORK SETUP MENU LEAP Username • LEAP Username (01-15). The first 15 characters of the LEAP user name (maximum number of characters is 32). • LEAP Username (16-30). Characters 16 to 30 of the LEAP user name (maximum number of characters is 32). •...

  • Page 123: Active (Igp) Emul

    ACTIVE (IGP) EMUL WLAN LEAP ACTIVE (IGP) EMUL * = Factory Default ACTIVE (IGP) EMUL (from page 68) IGP/PGL* IGP/VGL (not shown if any below are installed) ANSI (if installed) PCL-II (if installed) LG (if installed) LP+ (with any above) This ACTIVE (IGP) EMUL function allows you to activate the desired emulation.

  • Page 124: Igp/Pgl Emulation

    Chapter 4 IGP/PGL Emulation IGP/PGL Emulation The PGL emulation is the software based Intelligent Graphics Processor (IGP) for the line matrix family of printers. It is based upon, and is compatible with, the IGP-100/200/400 board using the PGL. The IGP graphics processing features are detailed below. Features On-Line Form and Label Generation makes it easy to create forms or labels with a “preprinted”...
  • Page 125 IGP/PGL EMULATION Features Rotated Alphanumerics permit new concepts in form design. Normal, expanded, and compressed character strings can be rotated 90 degrees clockwise or counterclockwise, or they can be printed upside down. Reversed Print permits highlighting and contrasting by printing white characters on a dark background.

  • Page 126: Configuring The Emulation With The Control Panel

    Chapter 4 IGP/PGL Emulation Configuring The Emulation With The Control Panel You can select PGL default parameters directly from the control panel or by control codes as explained in the IGP/PGL Programmer's Reference Manual. The PGL parameters are described on the following pages. Parameters marked with an asterisk (*) indicate the default value.

  • Page 127: Igp/Pgl Submenu

    IGP/PGL Submenu IGP/PGL Submenu IGP/PGL Submenu * = Factory Default EMULATION (from page 68) IGP/PGL Define CR Define LF Autowrap PI Slew CR Edit Code Code SFCC Range CR = CR* LF = LF* Disable* 126* Disable* CR = CR + LF LF = CR + LF Enable (1-255)
  • Page 128 Chapter 4 IGP/PGL Emulation * = Factory Default IGP/PGL (Continued) True Form Printer PI Print Power-on Trunc Dyn Error Slew Line Quality S-Mode Data Report Enable* Enable* Data Processing* Disable* Disable Disable High (0 - 5) Enable Debug Mode Best Fault...

  • Page 129: Igp/Pgl Submenu (With Pcl-Ii)

    IGP/PGL Submenu (with PCL-II) IGP/PGL Submenu (with PCL-II) IGP/PGL Submenu (with PCL-II) * = Factory Default EMULATION (from page 68) IGP/PGL Define CR Define LF Autowrap PI Slew CR Edit Code Code SFCC Range CR = CR* LF = LF* Disable* Disable* CR = CR + LF...

  • Page 130: Igp/Pgl Submenu (With Lg)

    Chapter 4 IGP/PGL Emulation IGP/PGL Submenu (with LG) * = Factory Default EMULATION (from page 68) IGP/PGL Define CR Define LF Autowrap PI Slew CR Edit Code Code SFCC Range CR = CR* LF = LF* Disable* Disable* CR = CR + LF LF = CR + LF Enable Enable...
  • Page 131 IGP/PGL Submenu IGP/PGL Submenu (with LG) Define CR (Carriage Return) Code This parameter forces the printer to insert an automatic Line Feed code into the data stream whenever a Carriage Return code occurs. This is to be used only if the host computer does not send line feeds to the printer.

  • Page 132: Pi Slew Range

    Chapter 4 IGP/PGL Emulation PI Slew Range You can specify how many lines the paper will feed. • 15. A paper slew of 1-15 will move 1-15 lines. A paper slew of 0 will move 1 line. • 16. A paper slew of 0-15 will move 1-16 lines. CR Edit This parameter determines if a carriage return will be followed by a line feed.

  • Page 133: Auto Uppercase

    IGP/PGL Submenu IGP/PGL Submenu (with LG) Select LPI This is the number of lines to be printed per inch. For example, at 6 lpi there is 1/6 inch from the top of one print line to the top of the next print line.

  • Page 134: Ext Execute Copy

    Chapter 4 IGP/PGL Emulation Power On IGP/PGL You can set the IGP feature so that it is enabled or disabled when the printer is powered on. • Enable (default). The PGL is enabled when the printer is powered on. (The PGL feature is initialized in the Normal mode.) •...

  • Page 135: Barcode Options

    IGP/PGL Submenu IGP/PGL Submenu (with LG) Barcode Options The following sub-options help define specific options regarding barcode printing. UPC Descenders This parameter allows you to print barcode descenders when human readable data is not present in the UPC/EAN barcodes. • Always (default).
  • Page 136 Chapter 4 IGP/PGL Emulation I-2/5 Selection This option is added to be compatible with a special IGP-X00 customization. Usually, if I-2/5 barcodes have an odd number of digits, a leading zero is inserted in front of the data. However, this special IGP-X00 customization gives you the option of adding a space character at the end of the barcode instead.

  • Page 137: Host Form Length

    IGP/PGL Submenu IGP/PGL Submenu (with LG) User-Def Ratio • Enable (default). User-defined ratios are accepted for barcodes. This is the default. • Disable. User-defined ratios are ignored and the magnification X1 is used in its place. Host Form Length Determines whether the form length specified in the CREATE command changes the form length designated in the LP+ menu (see “LinePrinter Plus Emulation”...

  • Page 138: Ignore Char

    Chapter 4 IGP/PGL Emulation Var Form Type This menu option applies only to the host command, CREATE;NAME or CREATE;NAME;DISK. The option also applies to the host command CREATE;NAME followed by ;0, ;X or a form length number that always overrides the menu option. •...

  • Page 139: Expanded Font

    IGP/PGL Submenu IGP/PGL Submenu (with LG) Compatbl. Mode This option instructs the PGL to behave similarly to older versions of the IGP with respect to certain commands. All new users with new applications should select the “None” option. Selecting this mode insures the printer will behave as described in this manual.

  • Page 140: Scalable Size

    Chapter 4 IGP/PGL Emulation Scalable Size • Normal (default). Controls the size of scalable characters to be either normal size (as set by the user) or adjusted to match the size of block fonts. This is the default. • Block. Adjusts the size of scalable characters to exactly match its block font alternative.
  • Page 141 IGP/PGL Submenu IGP/PGL Submenu (with LG) Print Quality • Data Processing (default). The emulation prints at 60 x 72 dpi and lets you choose between normal alphanumerics and barcodes and dark mode alphanumerics and barcodes. This mode should be set if you want the highest speed. •...

  • Page 142: Error Report

    Chapter 4 IGP/PGL Emulation Error Report Sets the error reporting capability for IGP/PGL forms. • On (default). Form boundary error checking reported. Any element which falls off the current page is reported as an error. • Debug Mode. The printer is put in debug mode whenever a form is defined in Create Form mode.
  • Page 143 IGP/PGL Submenu IGP/PGL Submenu (with LG) IGP/PGL Font Set Menu * = Factory Default Select Font (see page 127) Standard Arabic Cyrillic European Greek Sets* Sets Sets Sets Sets 0) ASCII* ASMO 449* Code Page 866* Latin 2 8859-2* DEC 256 Greek* 1) German ASMO 449+ Cyrillic CP 437...

  • Page 144: Igp/Vgl Emulation

    Chapter 4 IGP/VGL Emulation IGP/VGL Emulation Code V Graphics language (VGL) is an Intelligent Graphics Printing (IGP) software emulation designed for your Line Matrix printer. The IGP Code V emulation of the QMS Code V Version II programming language produces online forms, barcodes, and alphanumeric text-generation.

  • Page 145: Configuring The Emulation With The Control Panel

    Configuring The Emulation With The Control Panel Logos are easily created using alphanumeric commands and a variety of print and shading features, which provides a “customized” appearance for forms, reports, and labels. The registered ® ® ® trademark, copyright, TUV , GS-Mark, UL , and CSA symbols...

  • Page 146: Igp/Vgl Submenu

    Chapter 4 IGP/VGL Emulation IGP/VGL Submenu * = Factory Default EMULATION (from page 68) IGP/VGL SFCC & Graphics Error Ignore/DB8 Pwrup Options Handling Setup VGL SFCC (see next page) Error Msgs Ignore Chars Enable* Disable* Power up ^X Disable Char 1 Disable* Error Markers Char 2...
  • Page 147 IGP/VGL Submenu * = Factory Default Graphics Options (from page 146) Slash 0 Ignore Dots Append Truncate True Vert Absorb After Rotated Alpha 1/10 Disable* Disable* Disable* Enable* Disable* Absorb Motion* Enable Enable Enable Disable Enable Absorb All Disable Rot. Char Ignore Midline PY Print...

  • Page 148: Igp/Vgl Submenu (With Pcl-Ii)

    Chapter 4 IGP/VGL Emulation IGP/VGL Submenu (with PCL-II) * = Factory Default EMULATION (from page 68) IGP/VGL SFCC & Graphics Error Ignore/DB8 Pwrup Options Handling Setup Control Char (see next page) Error Msgs Ignore Nulls Enable* Disable* Ignore Mode Disable Enable Disable* Error Markers...
  • Page 149 IGP/VGL Submenu (with PCL-II) * = Factory Default Graphics Options (from page 148) Slashes in Ignore Dots Append Truncate True Vert Zeros Rotated Alpha 1/10 Descenders Enable* Disable* Disable* Enable* Disable* Enable* Disable Enable Enable Disable Enable Disable Rot. Char Ignore Midline PY Convert...

  • Page 150: Igp/Vgl Submenu (With Lg)

    Chapter 4 IGP/VGL Emulation IGP/VGL Submenu (with LG) * = Factory Default EMULATION (from page 68) IGP/VGL SFCC & Graphics Error Ignore/DB8 Pwrup Options Handling Setup Control Char (see next page) Error Msgs Ignore Nulls Enable* Disable* Ignore Mode Disable Enable Disable* Error Markers...
  • Page 151 IGP/VGL Submenu IGP/VGL Submenu (with LG) * = Factory Default Graphics Options (from page 150) Slash 0 Ignore Dots Append Truncate True Vert Absorb After Rotated Alpha 1/10 Enable* Disable* Disable* Enable* Disable* Absorb Motion* Disable Enable Enable Disable Enable Absorb All Disable Rot.
  • Page 152 Chapter 4 IGP/VGL Emulation SFCC & Pwrup This option has several sub-options which define the SFCC and power-up configuration used with VGL. VGL SFCC This option selects the Special Function Control Code. The default value 5E. Run a configuration printout to determine the currently selected VGL SFCC.

  • Page 153: Graphics Options

    IGP/VGL Submenu IGP/VGL Submenu (with LG) Graphics Options Following are several options which configure printing output. Slash 0 This parameter allows you to print the numeral “0” with or without the slash. This option applies to all character sets except OCR-A and OCR-B.
  • Page 154 Chapter 4 IGP/VGL Emulation True Vert 1/10 • Enable (default). A vertical 1/10 inch parameter is used as 1/10 inch. Rounding occurs to the nearest 1/72 inch. This can cause ± vertical moves that have the same value to differ by 1/72 inch.
  • Page 155 IGP/VGL Submenu IGP/VGL Submenu (with LG) Ignore Spaces • Disable (default). Trailing spaces are not deleted from alphanumeric elements in a graphics pass. • Enable. Trailing spaces are deleted from alphanumeric elements in a graphics pass. Midline PY (includes ^PN) •...
  • Page 156 Chapter 4 IGP/VGL Emulation MSI Check Digit • Print (default). The check digit is appended at the end of the printable data field for MSI barcodes. • Don't Print. The check digit for MSI barcodes does not print. I25 Selection •...
  • Page 157 IGP/VGL Submenu IGP/VGL Submenu (with LG) Width Limit • Disable (default). • Enable. The system will limit the length and width for expanded characters to a limit shown in Table 6, which displays the maximum width allowed for a specific height in the range of 00 through 40 (0.0 through 4.0 inches).
  • Page 158 Chapter 4 IGP/VGL Emulation Absorb After ^PN • Disable (default). All line terminators that follow the ^PN command are sent to the printer and processed. • Enable. The first motion line terminator that follows the ^PN command is ignored. IGP110 Compatbl. This option instructs the VGL to behave similarly to the IGP-10 with respect to certain commands.

  • Page 159: Error Handling

    IGP/VGL Submenu IGP/VGL Submenu (with LG) Error Handling Following are several options which define how errors are reported. Error Msgs • Enable (default). Command syntax is checked and error messages printed when command parameters are incorrect. • Disable. Error checking and error messages are suppressed. Error Markers •...
  • Page 160 Chapter 4 IGP/VGL Emulation Ignore / DB8 Setup Following are several options which define character filtering and Data Bit 8. Ignore Chars • Disable (default). Character filtering is not enabled. • Char 1. Character 1 will be filtered. Select the option “Ignore CH#1”...
  • Page 161 IGP/VGL Submenu IGP/VGL Submenu (with LG) Data Bit 8 • Enable (default). The PI line is not passed directly from host to printer; all 8 bits are used for data bits, and characters in the hex 80-FF range can be accessed. •...

  • Page 162: Prt To Emulate

    Chapter 4 IGP/VGL Emulation Host PI • Disable (default). The host does not send PI signals. • Enable. The host sends PI signals. The Data Bit 8 configuration option must be disabled to transmit the PI line to the printer. Max PI 16 •...
  • Page 163 IGP/VGL Submenu IGP/VGL Submenu (with LG) IGP/VGL Font Set Menu * = Factory Default Font Set (see page 146) Standard Arabic Cyrillic European Greek Sets* Sets Sets Sets Sets 0) ASCII* ASMO 449* Code Page 866* Latin 2 8859-2* DEC 256 Greek* 1) German ASMO 449+ Cyrillic CP 437...

  • Page 164: Emulation

    Chapter 4 EMULATION EMULATION The EMULATION menu allows you to select the emulation to be used with your printer. The Proprinter XL, Epson FX, P-Series, P-Series XQ, and Serial Matrix emulations are all part of LinePrinter +. You can configure options for the active emulation via the EMULATION menu.

  • Page 165: Coax/Twinax (Cthi) Emulation

    Coax/Twinax (CTHI) Emulation Standard Coax/Twinax (CTHI) Emulation * = Factory Default Coax/Twinax EMULATION Host Interface (from page 68) CTHI Standard* Simp Prot Conv Coax Twinax 3270 5250 SPC Coax SPC Twinax Params Params Params Params Params Params page 167 page 178 page 185 page 194 page 200...

  • Page 166: Simple Prot Conv

    Chapter 4 Coax/Twinax (CTHI) Emulation Simple Prot Conv The Simple Protocol Converter (SPC) option allows those who use third party add-on Coax or Twinax protocol converters to produce the same output on a Line Matrix printer with the Coax/Twinax (CTHI) capability as done using a non-CT printer with the third party converter interfaces.

  • Page 167: Coax Emulation

    Coax Emulation Coax Emulation * = Factory Default CTHI 1 = Valid only when the printer (from page 165) emulates 3287. Standard* Coax Params Char Set Translation Active Char Prt Partial Select Line (see next page) Secondary Set* Enable* Primary Set Disable Cancel Buffer...
  • Page 168 Chapter 4 Coax/Twinax (CTHI) Emulation * = Factory Default Char Set Select (from page 167) Primary Secondary Sets Sets 0037 English US* 0289 Span. Alt 0890 Yugos. Old English US* Portuguese 0037 Eng Nether 0500 Swiss Bil 1097 Farsi English UK Portug.
  • Page 169 Coax Emulation Char Set Select Specifies the print language used by the printer. Character sets are shown in detail in the Character Sets Reference Manual . Translation Tbl Prints out SCS and DSC/DSE tables of the Coax interface's current character set. This operation is valid only when the Coax interface is selected as the current interface (see “HOST INTERFACE”...
  • Page 170 Chapter 4 Coax/Twinax (CTHI) Emulation PA2 is only valid when the printer is in the Offline state and the coax SCS data stream is active. This function displays the “PA2 ENABLED” message when the ENTER key is pressed and sends a special operator request to the host when the printer is put back in online mode.
  • Page 171 Coax Emulation SCS Buffer Cntrl This option is used in Coax LU1/SCS mode only. • Don’t Wait (default). The printer does not wait for the job to be printed before sending the print completion to the host. • Wait Until Done. The printer waits for the job to print before sending the print completion to the host.
  • Page 172 This option is used in Twinax SPC emulation. The range is ASCII character. This option allows users to define ther own lead-in characters for the OKI Specific commands. Select a hex value for the following codes for the User Defined option: •...

  • Page 173: Image Buf Size

    Coax Emulation Image Buf Size Allows you to select 2K or 4K as the image buffer size. This option is valid only when the printer emulates the 3287. For the 4234 emulation, the buffer size is fixed at 4K. A POR status is sent to the host when the printer is placed online.
  • Page 174 Chapter 4 Coax/Twinax (CTHI) Emulation Position Aft FF (4234 only) Allows you to select the location of the print position after a form feed command is sent. • On (default). Sets the printer to print at print position 1 of the first print line on the next form.
  • Page 175 Coax Emulation Auto Skip At End Specifies whether or not to perform an automatic form feed at the end of a print buffer. If form feed is the last character in the print order, the form feed function is supplied by the Auto Skip At End option.

  • Page 176: Translate Table

    Chapter 4 Coax/Twinax (CTHI) Emulation Translate Table Defines which translate table to use for printing. • Default (default). Translates data by using the default table of the current character set. • Downloaded. Translates data from EBCDIC to internal code by using the downloaded translate table. Host Override Determines whether the printer accepts certain commands sent by the host or continues to use the current operator panel settings.
  • Page 177 Coax Emulation Max. Print Width Set the maximum print width at either 13.2 inches or the maximum width of the printer. Buffer Print • Disable (default). The printer will print normally. • Enable. The printer prints the EBCDIC data and control codes received from the host as hex values.

  • Page 178: Twinax Params

    Chapter 4 Coax/Twinax (CTHI) Emulation Twinax Params * = Factory Default CTHI (from page 165) Standard* Twinax Params Char Set Active Char Prt Partial Device ID Device Select Line Address (see next page) Secondary Set* Enable* IPDS* Address 1* Primary Set Disable 5225 Address (0-6)
  • Page 179 Twinax Params * = Factory Default Char Set Select (from page 178) Primary Secondary Sets Sets 0037 English US* 0871 Icelandic English US* Spanish Speak. 0037 Eng Nether 0290 Japan Kata Austrian/German English UK 0500 Swiss Bil 0870 Latin 2 Belgian Old Hebrew 0500 Belg.

  • Page 180: World Trade

    Chapter 4 Coax/Twinax (CTHI) Emulation Prt Partial Line • Enable (default). Forces the printer to print a partial line (i.e., line not ending with a LF) before moving to the top of form on the next page. • Disable. The last partial line of data will not be printed. Device ID This parameter defines the printer emulation as 4234-2 or 5225.
  • Page 181 This option is used in Twinax SPC emulation. The range is ASCII character. This option allows users to define ther own lead-in characters for the OKI Specific commands. Select a hex value for the following codes for the User Defined option: •...

  • Page 182: Lac Option

    Chapter 4 Coax/Twinax (CTHI) Emulation Graphic Chek Err Allows overriding of the host setting for the SGEA (Set Graphic Error Action) command. For more information about the SGEA command, refer to the Coax/Twinax Programmer's Reference Manual . • Enable (default). The host setting for the SGEA used by the printer.

  • Page 183: Lac Approx

    Twinax Params LAC Approx. A process that reorganizes columns of dots so that clean, readable printing is possible. • On (default). Converts the emulated character cells to standard cells for the P7224 model. • Off. Converts character cells byte by byte and not by LAC approximation.
  • Page 184 Chapter 4 Coax/Twinax (CTHI) Emulation Format Control Enables the printer to reflect the same spacing as CTPC model printers after absolute and relative move commands are executed. • Disable (default). Reflects distance, generated by the IGP/VGL feature, IGP/PGL feature, and Hex Transparent control code sequence, in the new position (after absolute and relative move commands are executed).
  • Page 185 3270 Params 3270 Params 3270 Params (from page 165) Char Set Translation Active Char Early Print Prt Partial Select Cmpl Line See the following Secondary Sets* Disable* Enable* page. Primary Sets* Enable Disable Change Set Text Intervention Compatibility Transparent Case Orientn Lead-in Chars CR At MPP + 1...
  • Page 186 Chapter 4 Coax/Twinax (CTHI) Emulation * = Factory Default 3270 Params Char Set Select (from page 185) Primary Sets Secondary Sets 0037 English US* 0890 Yugos. Old English US* 0037 Eng Nether 1097 Farsi English UK 0285 English UK 1025 Cyrillic German 0273 Austr/Germ 0905 Turk.

  • Page 187: 3270 Params

    3270 Params Translation Tbl Prints out a table of the Coax interface’s current character set. This operation is valid only when the TN3270 interface is the current interface. Active Char Set Specifies which character language set will be the active set. •...
  • Page 188 This option is used to set user defined lead-in characters. The range is ASCII character. This option allows users to define ther own lead-in characters for the OKI Specific commands. Select a hex value for the following codes for the User Defined option: •...
  • Page 189 3270 Params Change Case Specifies the font as Mono or Dual case. This option is available only in non-SCS mode. The host will be notified of the change when the printer is placed online. Mono Case prints the same as Dual Case if the character set is one of the following “right to left”...
  • Page 190 Chapter 4 Coax/Twinax (CTHI) Emulation Compatibility Op The Compatibility Options allow you to select special printer functions in the non-SCS mode based on the capabilities of the printer emulated. CR At MPP+1 MPP is Maximum Print Position, which is also known as line length. This option controls a carriage return at the end of a print line and at MPP+1.
  • Page 191 3270 Params Last Char = FF Determines the print line position when a form feed command is the last code encountered in the print buffer. • On (default). Moves to the first print position on the second line of the next form. •...
  • Page 192 Chapter 4 Coax/Twinax (CTHI) Emulation Auto Skip At End Specifies whether or not to perform an automatic form feed at the end of a print buffer. If form feed is the last character in the print order, the form feed function is supplied by the Auto Skip At End option.
  • Page 193 3270 Params Host Override Determines whether the printer accepts certain commands sent by the host, or continues to use the current operator panel settings. • Disable (default). Allows these host commands to override operator panel settings: line length, forms length, lines per inch (LPI), characters per inch (CPI), print quality, and text orientation.
  • Page 194 Chapter 4 Coax/Twinax (CTHI) Emulation 5250 Params 5250 Params (from page 165) Char Set Translation Active Char Prt Partial Transparent Select Line Lead-in Chars See the following Secondary Set* Enable* Set 1 <%>* page. Primary Set Disable Set 2 ¬¬$ Set 3 _%_ User Defined Usr Defined HTRN...

  • Page 195: 5250 Params

    5250 Params * = Factory Default 5250 Params Char Set Select (from page 194) Primary Sets Secondary Sets English US* Spanish Speak. 0037 English US* 0871 Icelandic Austrian/German English UK 0037 Eng Nether 0290 Japan Kata Belgian Old Hebrew 0500 Swiss Bil 0870 Latin 2 Brazilian Hebrew...
  • Page 196 Chapter 4 Coax/Twinax (CTHI) Emulation Active Char Set Selects which group of character sets (Primary or Secondary) will be active. • Secondary Set (default) • Primary Set Prt Partial Line • Enable (default). When this option is enabled, it forces the printer to print if a partial line is in the printer (i.e.
  • Page 197 This option is used to set user defined lead-in characters. The range is ASCII character. This option allows users to define ther own lead-in characters for the OKI Specific commands. Select a hex value for the following codes for the User Defined option: •...
  • Page 198 Chapter 4 Coax/Twinax (CTHI) Emulation Graphic Chek Cod Specifies the replacement character to print in place of any unprintable character that is received from the host. Choose a hex character from 40 through FE. The character becomes the printer default when: •...
  • Page 199 5250 Params Host Override Determines whether the printer accepts certain commands sent by the host, or continues to use the current operator panel settings. • Disable (default). Allows these host commands to override operator panel settings: line length, forms length, lines per inch (LPI), characters per inch (CPI), print quality, and text orientation.

  • Page 200: Spc Coax Params

    Chapter 4 Coax/Twinax (CTHI) Emulation SPC Coax Params * = Factory Default 1 = Option needs to CTHI be selected (from page 165) Simp Prot Conv SPC Coax Params Image Buf Intervention Buffer Print Column 132 Usr Defined Logical Buf Translation Size Size...

  • Page 201: Column 132 Wrap

    This option is used in Twinax SPC emulation. The range is ASCII character. This option allows users to define ther own lead-in characters for the OKI Specific commands. Select a hex value for the following codes for the User Defined option: •...
  • Page 202 Chapter 4 Coax/Twinax (CTHI) Emulation PA1 is only valid when the printer is in the offline state and the Coax Systems Network Architecture Character String (SCS) data stream is active. This function displays the “PA1 ENABLED” message when the ENTER key is pressed and sends a special operator request to the host when the printer is placed online.
  • Page 203 SPC Coax Params SPC Space Supp This option is only available in Coax SPC emulation and is used in LU3/DSC/DSE mode only. • Disable (default). Treats nulls and spaces normally. • Enable. If the entire line consists of spaces and nulls, the line will be discarded.

  • Page 204: Spc Twx Params

    Chapter 4 Coax/Twinax (CTHI) Emulation SPC Twx Params * = Factory Default CTHI (from page 165) Simp Prot Conv SPC Twinax Params Device Translation Buffer Print SPC Type Address Address 1* Disable* Address (0-6) Enable MODE MODE MODE 219* P5000 Printer Type SPC Char Set SPC Char Set...
  • Page 205 This option is used in Twinax SPC emulation. The range is ASCII character. This option allows users to define ther own lead-in characters for the OKI Specific commands. Select a hex value for the following codes for the User Defined option: •...
  • Page 206 Chapter 4 Coax/Twinax (CTHI) Emulation EVFU • Enable. The EVFU parameter allows vertical format control by the host in all four printer type modes. • Disable. Vertical format control is only allowed in IMPACT/P-SERIES mode. SPC Char Set Allows you to select the print language character set. Translation Tbl Prints out a table of the Twinax interface's current character set.

  • Page 207: Lineprinter Plus Emulation

    LinePrinter Plus Emulation SPC Twx Params LinePrinter Plus Emulation NOTE: When the printer is set to SPC Twx Params or SPC Coax Params, no LP+ menu items will take effect on the same offline. The LP+ Emulation resets when the printer is taken offline.
  • Page 208 Chapter 4 LinePrinter Plus Emulation * = Factory Default Printer Protocol (from page 207) P-Series* P-Series Serial Proprinter Epson Matrix (see page 217) (see page 226) (see page 230) (see page 234) (see page 239) Font Attributes (from page 207) Typeface Prop.
  • Page 209 LinePrinter Plus Emulation SPC Twx Params * = Factory Default These menus do not appear if the Coax or Twinax host interface is selected. See page 83. This value is 132 if the Coax or Twinax host Page Format interface is selected. (from page 207) Form Form...

  • Page 210: Lineprinter Plus Emulation (With Pcl-Ii)

    Chapter 4 LinePrinter Plus Emulation (with PCL-II) LinePrinter Plus Emulation (with PCL-II) NOTE: When the printer is set to SPC Twx Params or SPC Coax Params, no LP+ menu items will take effect on the same offline. The LP+ Emulation resets when the printer is taken offline.
  • Page 211 LinePrinter Plus Emulation (with PCL-II) SPC Twx Params * = Factory Default Font Attributes (from page 210) Typeface Prop. Bold Print Italic Print Slashed Spacing Zero Data Processing* Disable* Disable* Disable* Disable* Enable Enable Forward Slant Enable OCR-A Backward Slant OCR-B High Speed NLQ Sans Serif...
  • Page 212 Chapter 4 LinePrinter Plus Emulation (with PCL-II) • Ignore LPI. All LPI commands sent by the host are ignored by the printer. • Ignore Unidir. All Unidirectional commands sent by the host are ignored by the printer. Font Attributes Typeface •...
  • Page 213 LinePrinter Plus Emulation SPC Twx Params • High Speed 64. This font prints at 120 dpi horizontally and 64 vertically. When chosen from the front panel, it defaults to 10 cpi. The cpi can then be varied, but the width will not change.
  • Page 214 Chapter 4 LinePrinter Plus Emulation (with PCL-II) Bold Print • Disable. Text is printed normally. • Enable. Text is printed with a heavy line thickness. Italic Print • Disable. Text is printed normally. • Forward Slant. Text is printed with a forward slant. •...
  • Page 215 LinePrinter Plus Emulation SPC Twx Params Page Format Form Length Forms length is the number of lines that can be printed on a page. You can set the form length in inches, millimeters (mm), or as a function of the current lpi (lines per inch). Form Width The form width can be specified in inches, millimeters, or as a function of the current cpi (characters per inch).

  • Page 216: Set Substitution

    Chapter 4 LinePrinter Plus Emulation (with PCL-II) Reset Cmd CFG Ld When the printer receives a host data stream reset command (ESC @ or ESC[K) in addition to resetting printer variables, the selected configuration is loaded. • Disable (default). The active emulation parameters are loaded when the reset command is executed.

  • Page 217: P-Series Emulation

    P-Series Emulation P-Series Emulation P-Series Emulation * = Factory Default Printer Protocol (from page 207) P-Series Control Code Auto LF Control Code Define CR Overstrike Define LF Code Code 8.0 LPI* Elongated* CR = CR* Disable* Enable* LF = CR + LF* 10.3 LPI Backspace CR = CR + LF...

  • Page 218: P-Series Emulation (With Pcl-Ii)

    Chapter 4 LinePrinter Plus Emulation (with PCL-II) P-Series Emulation (with PCL-II) * = Factory Default Printer Protocol (from page 207) P-Series Control Code Control Code Define CR Auto LF Overstrike Define LF Code Code 8.0 LPI* Elongated* CR = CR* Disable* Enable* LF = CR + LF*...

  • Page 219: P-Series Emulation (With Lg)

    P-Series Emulation (with LG) P-Series Emulation (with LG) * = Factory Default Printer Protocol (from page 207) P-Series Control Code Control Code Define CR Auto LF Overstrike Define LF Code Code 8.0 LPI* Elongated* CR = CR* Disable* Enable* LF = CR + LF* 10.3 LPI Backspace CR = CR + LF...
  • Page 220 Chapter 4 LinePrinter Plus Emulation (with PCL-II) Define CR Code This option controls the action of the printer when it receives a Carriage Return code (hex 0D) from the host computer. If this feature is enabled, each time the printer receives a carriage return, it inserts an additional Line Feed code (hex 0A) into the data stream.
  • Page 221 P-Series Emulation P-Series Emulation (with LG) P-Series SFCC This parameter allows you to select which ASCII codes will function as the Special Function Control Code (SFCC) command delimiter. P-Series codes can use hex 00 through hex 7F. Options include the following: •...
  • Page 222 Chapter 4 LinePrinter Plus Emulation (with PCL-II) Character Set Specifies a character set as shown in the “P-Series Character Set Menu” on page 223. To use one of these sets, choose the desired group heading (such as European Sets) and press ENTER. Then choose the desired set within that group (such as Roman 8) and press ENTER.
  • Page 223 P-Series Emulation P-Series Emulation (with LG) P-Series Character Set Menu Character Set * = Factory Default (from page 217) Arabic Cyrillic European Greek Hebrew Sets Sets Sets Sets Sets ASMO 449* Cyrillic 866* Latin 2 8859-2* DEC 256 Greek* Hebrew Old* ASMO 449+ Cyrillic CP 437 Latin 2 852...
  • Page 224 Chapter 4 LinePrinter Plus Emulation (with PCL-II) P-Series Character Set Menu (with PCL-II) * = Factory Default Character Set (from page 218) IBM PC* Primary Subset ASCII (USA)* French German English Danish Swedish Italian Spanish Japanese French Canadian Latin American Danish II Spanish II Latin Am II...
  • Page 225 P-Series Emulation P-Series Emulation (with LG) P-Series Character Set Menu (with LG) Character Set * = Factory Default (from page 218) IBM PC* DEC Mult. Primary Subset ASCII (USA)* ASCII (USA)* French French German German English English Norw./Danish Danish Swedish Swedish Italian Italian...

  • Page 226: P-Series Xq Emulation

    Chapter 4 LinePrinter Plus Emulation (with PCL-II) P-Series XQ Emulation * = Factory Default Printer Protocol (from page 207) P-Series Control Code Define CR Auto LF Define LF Compressed Elong/Alt. Code Code Font 8.0 LPI* CR = CR* Disable* LF = CR + LF* char 01 SOH* Elng=BS Font=SO* 10.3 LPI...
  • Page 227 P-Series XQ Emulation Define CR Code This option controls the action of the printer when it receives a Carriage Return code (hex 0D) from the host computer. If this feature is enabled, each time the printer receives a Carriage Return, it inserts an additional Line Feed code (hex 0A) into the data stream.

  • Page 228: Compressed Print

    Chapter 4 LinePrinter Plus Emulation (with PCL-II) Compressed Print Controls which host command sets compressed printing. • Char 01 SOH (default) • Char 03 ETX • Char 09 HT Elong/Alt. Font Controls which host command sets elongated (double high) fonts and extended character set.

  • Page 229: Slew Relative

    P-Series XQ Emulation Upr. Case Select Controls how the printer handles lowercase characters it receives from the host computer. When enabled, all characters will be printed in uppercase. • Disable (default). Prints lowercase characters received from the host computer as lowercase, and prints uppercase characters received from the computer as uppercase.

  • Page 230: Serial Matrix Emulation

    Chapter 4 LinePrinter Plus Emulation (with PCL-II) Serial Matrix Emulation * = Factory Default Printer Protocol (from page 207) Serial Matrix Control Code Define CR Auto LF Overstrike Define LF Printer Code Select Code 8.0 LPI* CR = CR* Enable* Enable* LF = LF* Disable*...
  • Page 231 Serial Matrix Emulation Define CR Code This option controls the action of the printer when it receives a Carriage Return code (hex 0D) from the host computer. If this feature is enabled, each time the printer receives a Carriage Return, it inserts an additional Line Feed code (hex 0A) into the data stream.
  • Page 232 Chapter 4 LinePrinter Plus Emulation (with PCL-II) Printer Select • Disable (default). Ignores the ASCII DC1 and DC3 control codes. • Enable. Disables the printer when a DC1 control code is received, and enables the printer when a DC3 control code is received.

  • Page 233: Serial Matrix Character Set Menu

    Serial Matrix Emulation Serial Matrix Character Set Menu * = Factory Default Character Set (from page 230) Arabic Cyrillic European Greek Hebrew Sets Sets Sets Sets Sets ASMO 449* Cyrillic 866* Latin 2 8859-2* DEC 256 Greek* Hebrew Old* ASMO 449+ Cyrillic CP 437 Latin 2 852 ELOT 928 Greek...

  • Page 234: Proprinter Xl Emulation

    Chapter 4 LinePrinter Plus Emulation (with PCL-II) Proprinter XL Emulation * = Factory Default Printer Protocol (from page 207) Proprinter Define CR Auto LF Define LF FF valid at Character Alt. Char Code Code CR = CR* Enable* LF = LF* Enable* (see page 237) Set 1* CR = CR + LF...
  • Page 235 Proprinter XL Emulation Auto LF This option defines the printer action when print data is received past the forms width setting. • Enable (default). Performs an automatic carriage return and line feed when data is received past the forms width. •...
  • Page 236 Chapter 4 LinePrinter Plus Emulation (with PCL-II) Alt. Char Set This option determines if data in the range of hex 80 through hex 9F should be interpreted as a control code or as a printable character. • Set 1 (default). Interprets data in the range of hex 80 through hex 9F as a control code.

  • Page 237: Proprinter Xl Character Set Menu

    Proprinter XL Emulation Proprinter XL Character Set Menu * = Factory Default Character Set (from page 234) Standard European Arabic Cyrillic Greek Hebrew Sets* Sets Sets Sets Sets Sets ASMO 449* Cyrillic 866* Latin 2 8859-2* DEC 256 Greek* Hebrew Old* ASMO 449+ Cyrillic CP 437 Latin 2 852...
  • Page 238 Chapter 4 LinePrinter Plus Emulation (with PCL-II) Proprinter XL Character Set Menu (with PCL-II) Character Set * = Factory Default (from page 234) Code Page 437* Code Page 850 OCR-A OCR-B Latin 2 8859-2 Latin 2 852 Bulgarian Latin 9 8859-15 Polish POL1 Multinational DEC 256 Greek...

  • Page 239: Epson Fx Emulation

    Epson FX Emulation Epson FX Emulation * = Factory Default Printer Protocol (from page 207) Epson FX Define CR Auto LF Define LF Printer Character 20 CPI Code Code Select Condensed CR = CR* Enable* LF = LF* Disable* (see page 242) Enable* CR = CR + LF Disable LF = CR + LF...
  • Page 240 Chapter 4 LinePrinter Plus Emulation (with PCL-II) Auto LF This option defines the printer actions when print data is received past the forms width setting. • Enable (default). Performs an automatic carriage return and line feed when data is received past the forms width. •...
  • Page 241 Epson FX Emulation Character Set This parameter selects a character set for the Epson emulation, as shown in the “Epson FX Character Set Menu” on page 242. Note that when OCR-A or OCR-B is selected as the print language, the Font Attribute Typeface option under the LinePrinter Plus menu (page 212) is changed to OCR-A or OCR-B, respectively.

  • Page 242: Epson Fx Character Set Menu

    Chapter 4 LinePrinter Plus Emulation (with PCL-II) Epson FX Character Set Menu * = Factory Default Character Set (from page 239) Standard Arabic Cyrillic European Greek Hebrew Sets* Sets Sets Sets Sets Sets (See next ASMO 449* Cyrillic 866* Latin 2 8859-2* DEC 256 Greek* Hebrew Old* ASMO 449+...
  • Page 243 Epson FX Emulation * = Factory Default Character Set (from page 242) Standard Sets* Epson Set* ASCII (USA)* French German English Danish I Swedish Italian Spanish I Japanese Norwegian Danish II Spanish II Latin Am I French Canadian Latin Am II OCR-A OCR-B Multinational...
  • Page 244 Chapter 4 LinePrinter Plus Emulation (with PCL-II) Epson FX Character Set Menu (with PCL-II) * = Factory Default Character Set (from page 239) Epson Set* ASCII (USA)* French German English Danish I Swedish Italian Spanish I Japanese Norwegian Danish II Spanish II Latin Am I French Canadian...
  • Page 245 Epson FX Emulation Epson FX Character Set Menu (with LG) * = Factory Default Character Set (from page 239) Epson Set* ASCII (USA)* French German English Danish I Swedish Italian Spanish I Japanese Norwegian Danish II Spanish II Latin Am I French Canadian Latin Am II OCR-A...

  • Page 246: Ansi Emulation

    Chapter 4 ANSI Emulation ANSI Emulation * = Factory Default EMULATION (from page 164) 44/48XX- ANSI CPI/LPI Font Page Define CR Auto LF Define LF Select Attributes Format Code Code Select CPI (see next page) (see next page) CR = CR* Disable* LF = CR + LF* 10.0* CPI...
  • Page 247 ANSI Emulation Epson FX Emulation * = Factory Default Font Attributes (from page 246) Typeface Prop. Bold Print Slashed Spacing Zero Data Processing* Disable* Disable* Disable* Gothic NLQ Enable Enable Enable Char. Graphics High Speed Italics NLQ Character Set Courier NLQ (from page 246) OCR-A OCR-B...
  • Page 248 Chapter 4 ANSI Emulation CPI/LPI Select Defines the default values for the horizontal and vertical character spacing. The number of characters per inch can range from 10.0 through 17.1. The number of lines per inch can range from 3.0 through 8.0. Font Attributes Typeface Choose a typeface from the available options.
  • Page 249 ANSI Emulation Epson FX Emulation Slashed Zero This parameter allows you to print the numeral “0” with or without the slash. This option applies to all character sets except OCR-A and OCR-B. • Disable. Zero is printed without a slash. •...
  • Page 250 Chapter 4 ANSI Emulation IMPORTANT If the form length is set in lines and you change the LPI, the effective page length changes to the form length in characters divided by the new LPI. NOTE: Receipt of a data stream control code which changes the form length overrides the form length previously specified via the operator panel.
  • Page 251 ANSI Emulation Epson FX Emulation Define CR Code The Define CR Code option controls the action of the printer when it receives a Carriage Return code (hex 0D) from the host computer. If this feature is enabled, each time the printer receives a carriage return, it inserts an additional Line Feed code (hex 0A) into the data stream.

  • Page 252: Esc C Sequence

    Chapter 4 ANSI Emulation Character Set This parameter selects a character set for the ANSI emulation. Note that when 0876 OCR-A or 0877 OCR-B is selected as the print language, the Font Attributes Typeface parameter is changed to OCR-A or OCR-B, respectively. Character sets are shown in detail in the Character Sets Reference Manual .

  • Page 253: Received Del

    ANSI Emulation Epson FX Emulation Received CR • Observe (default). A CR code received from the host is handled as a carriage return. • Ignore. A CR code received from the host is ignored. Received DEL • Observe (default). A DEL code received from the host is handled as a Delete command.

  • Page 254: Barcode Darkmode

    Chapter 4 ANSI Emulation Barcode Darkmode • Enable (default). The barcodes are printed at a higher resolution. • Disable. The barcodes are printed at lower resolution but at a higher speed. PUM Default This is the Unit of Measure (UOM) as it is used within the ANSI emulation.

  • Page 255: Ipds Emulation

    IPDS Emulation Epson FX Emulation IPDS Emulation * = Factory Default EMULATION (from page 164) IPDS Print Quality Font Size Graphics Barcode Barcode Quality Quality Speed Select By Host* Select By Host* High* High* High* Standard Default Font Select By Host Select By Host Select By Host Compressed...
  • Page 256 Chapter 4 IPDS Emulation * = Factory Default IPDS Emulation (from page 255) Default VPA Check Hexdump Print IPDS Font Mode Fonts DRAFT 10* Enable* Disable* DRAFT 12 Disable Enable DRAFT 13 DRAFT 15 DRAFT 17 DRAFT 18 DP 10 DP 12 DP 13 DP 15...

  • Page 257: Font Size

    IPDS Emulation Epson FX Emulation Font Size This parameter chooses the font size which will be used by IPDS. • Select By Host (default). The font ID is only affected by host commands. • Standard. The font ID is converted to a decompressed font ID. •...

  • Page 258: Barcode Size

    Chapter 4 IPDS Emulation Barcode Speed This parameter chooses the vertical print quality of barcode labels. • High (default). Barcodes are printed with less vertical dots, increasing printing speed, but decreasing print quality. • Select By Host. The application decides the quality of the labels.

  • Page 259: Graphics Scaling

    IPDS Emulation Epson FX Emulation Graphics Scaling This parameter chooses the scaling factor for graphics when the Mappin. Control option of the IPDS Write Graphics Control command is SCALE TO FIT: • Rounded (default). Calculations are rounded up in the desired output resolution.

  • Page 260: Default Font

    Chapter 4 IPDS Emulation Code Page Subset When the Thai code page is selected as the default, either from the front panel or by a host command, you may choose from three different versions. Default Font Choose a font quality and size from the available selections. All fonts in the Default Font menu are available in standard and compressed vertical resolution (see page 255).

  • Page 261: Pcl - Ii Emulation

    PCL-II Emulation Epson FX Emulation PCL - II Emulation * = Factory Default EMULATION (from page 164) PCL-II Primary Char. Second Char. Face CPI Page Length Max Line Rep. Width Delay Inches/Page* 13.2 inches* Enable* 0* - 109, xx 0* - 109, xx Lines/Page 13.6 inches Disable...
  • Page 262 Chapter 4 PCL - II Emulation PCL-II (Continued) Config. Print Symbol Set Reset Cmd Print CFG Ld Current Config* Factory Config Disable Power Up Config Primary Secondary Char. set Char. Set (from previous (from previous page) page) Symbol Set Symbol Set Roman-8[8U]* OCR-A[0O] Math-8[8M]...
  • Page 263 PCL-II Emulation Epson FX Emulation Primary Char. Set You can select one of 92 pre-defined character sets by ID (although character sets range from 0 - 109, not all sets are available on the LJ500 printer), or you can select pitch, symbol set, and typeface individually.

  • Page 264: Perforation Skip

    Chapter 4 PCL - II Emulation Face CPI Delay Allows the combination of different font densities on the same line. • Enable (default). Different font densities can be used on the same line. • Disable. Only the same font densities are allowed on the same line.

  • Page 265: Ptx Linefeed

    PCL-II Emulation Epson FX Emulation PTX Linefeed • Disable (disable). The default. Linefeed is to be performed as calculated from the bottom of the graphics or barcode, thereby disrupting the vertical text alignment. • Enable. The Linefeed moves to the next line as calculated from the Top of Form position, thereby retaining vertical text alignment.
  • Page 266 Chapter 4 PCL - II Emulation Page L./Inches This parameter allows you to set physical page length from 2 to 16 inches, in increments of half an inch. The default is 11 inches. Config Print This option prints the emulation's parameters and the currently selected values.

  • Page 267: Lg Emulation

    LG Emulation Epson FX Emulation LG Emulation * = Factory Default EMULATION (from page 164) Vert Forms Font Horiz Forms Autowrap See next page. Bot Frm 66/6 Left Mrg 66.0 = CR* Top Mrg 0/6 Right Mrg 13.2 = CR + LF Bot Mrg 66/6 Unsolicited Print Mode...
  • Page 268 Chapter 4 LG Emulation Font (from previous page) Style Character Set DP 10 6* GL Char Set DP 10 8 U.S. ASCII* DP 12 6 DEC Finnish DP 12 8 French DP 15 6 DEC Fr. Can. DP 15 8 German DP 15 10 Italian...
  • Page 269 LG Emulation Epson FX Emulation Font Select a default font style and character set for the LG emulation, as follows: • Style. This option allows you to specify a print quality that includes a characters per inch (cpi) and lines per inch (lpi) setting, in the format Type cpi lpi.
  • Page 270 Chapter 4 LG Emulation • Top Mrg 6/0.This option sets the top margin for the forms. You must specify the top margin in lines (at 6 lines per inch), ranging from 0 to 198 lines (33 inches). The default setting is 0. Press the right arrow to increase the value, left arrow to decrease the value, and ENTER to change units.
  • Page 271 LG Emulation Epson FX Emulation This option controls the action of the printer when it receives a Carriage Return code (hex 0D) from the host computer. If this feature is enabled, each time the printer receives a Carriage Return, it inserts an additional Line Feed code (hex 0A) into the data stream.

  • Page 272: Unsolicited Rpt

    Chapter 4 LG Emulation This parameter forces the printer to insert an automatic Carriage Return code into the data stream whenever a Form Feed code occurs. This can be used in most installations, but it is required if the host computer does not send carriage returns to the printer. •...

  • Page 273: Plot Mode Opt

    LG Emulation Epson FX Emulation Plot Mode Opt When enabled, this option will plot with greater efficiency, particularly with respect to the Postnet barcode. Postnet is printed in the same density as the current print mode font so that reverse motion will be inhibited when possible.

  • Page 274: Printer Control

    Chapter 4 PRINTER CONTROL PRINTER CONTROL * Factory Default PRINTER Not available in LG or PCL-II CONTROL (from page 68) Ribbon End Eject Open Platen Bar Code Tear Bar Point Function @BOF Quality Dist. Darker +6 Standard* Disable* Dark* 7.46 inches.* Darker +5 Simple Tear Enable...

  • Page 275: Eject Function

    PRINTER CONTROL Epson FX Emulation Ribbon End Point This parameter adjusts the point at which the system will declare the ribbon as being expended. The life count will always be from 100% to 0%, but if a darker setting is selected 0% will be reached more quickly.
  • Page 276 Chapter 4 PRINTER CONTROL • Form Saver. Allows near demand printing for forms that do not have pre-printed headers or special application designs. At least one blank page is required to load the paper so that it does not slip out of the tractors. For shorter form lengths, two or more blank pages may be necessary.
  • Page 277 PRINTER CONTROL Epson FX Emulation Bar Code Quality Determines the bar code resolution for all emulations, except IPDS. (See “IPDS Emulation” on page 255 to set the bar code quality for IPDS.) • Dark (default). Bar code resolution is set at 120 x 72. •...

  • Page 278: Display Language

    Chapter 4 PRINTER CONTROL Display Language This parameter chooses the language that will appear on the LCD: English, German, French, Italian, Spanish, or Portuguese. The factory default is English. Accented Char Selects whether the accented characters are standard or tall. See Figure 23 for an example.

  • Page 279: Advanced User

    ADVANCED USER Epson FX Emulation ADVANCED USER * = Factory Default If you have the CT option, Enable is the default value. ADVANCED If installed USER 3 Not available in PCL-II (from page 68) 4 Not available in LG or PCL-II PTX Setup Hex Dump Power-up...

  • Page 280: Ptx Setup Option

    Chapter 4 ADVANCED USER ADVANCED USER (Continued) Set Lock Ribbon Ink Saver Action Mode Stop RBN End* Disable* Ignore RBN Enable PTX Setup Option Selects the Special Function Control Code for the PTX_SETUP command and functions. • Setup Parse. Disables or enables the PTX_SETUP command. •...

  • Page 281: Downloaded Fonts

    ADVANCED USER Epson FX Emulation Power-Up State • Online (default). The printer powers up in the online state. • Offline. The printer powers up in the offline state. NOTE: This option is not available in the PCL-II or LG emulation. Downloaded Fonts Allows you to download a substitution table to replace any character in the current character set with a different character in...

  • Page 282: Power Stacker

    Chapter 4 ADVANCED USER Power Stacker This parameter allows you to enable or disable the power paper stacker (provided this option is installed). Auto Elevator This parameter exists only on printers with the power paper stacker installed. The power stacker has a sensor which detects paper movement and raises the stacker as the printed paper stack grows.

  • Page 283: File System

    ADVANCED USER Epson FX Emulation File System • Overwrite Files. Allows you to prevent files from being overwritten by disabling the overwrite function. • View File List. Displays the list of files in the file system. Pressing the DOWN key displays the file size. •...

  • Page 284: Shuttle Timeout

    Chapter 4 ADVANCED USER In a non-CT system, changing characters sets in LP+ causes the active IGP to change to the same character set if the selected set exists in IGP. If the active IGP has no access to the selected set, no changes are made.

  • Page 285: Power Saver Time

    ADVANCED USER Epson FX Emulation Power Saver Time The time interval you specify for this parameter sets the amount of idle time before the printer goes into Power Saver mode. When Instant is chosen, the printer goes into Power Saver mode as soon as it is able to stop the shuttle properly.

  • Page 286: Set Lock Key

    Chapter 4 ADVANCED USER Set Lock Key Normally, to lock or unlock the printer menu, the UP and DOWN keys are pressed at the same time. The Set Lock Key parameter lets you choose different keys to lock or unlock the printer menu. You may choose almost any group of keys as the new lock and unlock keys.

  • Page 287: Diagnostics

    DIAGNOSTICS Epson FX Emulation Ink Saver Mode The overall image density setting will be maintained at a lower level, equivalent to approximately 0.2 PCS below the default setting. The factory default setting is Disable. Select Enable and press the ENTER key to activate the Ink Saver Mode. DIAGNOSTICS * = Factory Default DIAGNOSTICS...

  • Page 288: Printer Tests

    Chapter 4 DIAGNOSTICS Printer Tests These tests are used to check the print quality and operation of the printer. NOTE: Your authorized service representative will typically run the tests. They are described in more detail in the Maintenance Manual . •...

  • Page 289: Paper Out Dots

    DIAGNOSTICS Epson FX Emulation • Paperout Adj.. Verifies the current Paper Out Dots setting, which determines where the last line of text will print when there is a paper out condition. Setting this parameter correctly prevents printing on the platen. •...

  • Page 290: Print Statistics

    Chapter 4 DIAGNOSTICS Print Statistics You can view various printer statistics and refer to them for preventive maintenance purposes. Printer statistics accumulate continuously; they do not reset when you turn off the printer. All of the printer statistics are set to zero at the factory after burn-in testing.

  • Page 291: Interfaces

    Interfaces Overview This chapter describes the host interfaces provided with the printer. The printer interface is the point where the data line from the host computer plugs into the printer. The interface processes all communications signals and data to and from the host computer. Plus, with the Auto Switching feature, you can configure the printer to accept several interfaces at the same time (see “Auto Switching Submenu”...

  • Page 292: Dataproducts Parallel Interface

    Chapter 5 Dataproducts Parallel Interface Dataproducts Parallel Interface Table 8. Dataproducts Parallel Interface Connector Pin Assignments (with a 50-pin AMP HDH-20 Data Cable Connector) Input Signals Output Signals Miscellaneous Signal Signal Signal DATA LINE 1 READY CABLE VERIFY 45, 46 Return Return DATA LINE 2...

  • Page 293: Dataproducts Parallel Interface Signals

    Dataproducts Parallel Interface Signals Dataproducts Parallel Interface Signals Data Lines 1 through 8. Provides eight standard or inverted levels from the host that specify character data, plot data, or a control code. Data Line 8 allows access to the extended ASCII character set. You can enable or disable this line via the Data Bit 8 parameter on the Dataproducts submenu (see page 92).

  • Page 294: Centronics Parallel Interface

    Chapter 5 Centronics Parallel Interface Centronics Parallel Interface Table 9. Centronics Interface Connector Pin Assignments Input Signals Output Signals Miscellaneous Signal Signal Signal DATA LINE 1 ACKNOWLEDGE CHASSIS GROUND Return Return DATA LINE 2 ONLINE GROUND Return Return DATA LINE 3 FAULT Spares Return...

  • Page 295: Centronics Parallel Interface Signals

    Centronics Parallel Interface Signals Centronics Parallel Interface Signals Data Lines 1 through 8. Provides eight standard or inverted levels from the host that specify character data, plot data, or a control code. Data Line 8 allows access to the extended ASCII character set. You may enable or disable this line via the Data Bit 8 parameter on the Centronics submenu (see page 89).

  • Page 296: Ieee 1284 Parallel Interface

    Chapter 5 IEEE 1284 Parallel Interface IEEE 1284 Parallel Interface The 1284 supports three operating modes, which are determined by negotiation between the printer and the host. Compatibility Mode This mode provides compatibility with Centronics-like host I/O (see Table 10). Data is transferred from the host to the printer in 8-bit bytes over the data lines.

  • Page 297: Signals

    Signals Signals Table 10 lists each of the signals associated with the corresponding pins on the 1284 interface. Descriptions of the signals follow. Table 10. 1284 Signals Type of Mode Source of Data Compatible Nibble Byte Host nStrobe HostClk Host/Clk Host/Printer Data 1 (LSB) Host/Printer...
  • Page 298 Chapter 5 IEEE 1284 Parallel Interface Table 10. 1284 Signals (continued) Type of Mode Source of Data Compatible Nibble Byte Signal Ground (nStrobe) Signal Ground (Data 1) Signal Ground (Data 2) Signal Ground (Data 3) Signal Ground (Data 4) Signal Ground (Data 5) Signal Ground (Data 6) Signal Ground (Data 7) Signal Ground (Data 8)
  • Page 299 Signals Host Clock / nWrite. Driven by host. Data transferred from host to printer. When printer sends data, two types are available. If Nibble mode, signal is set high. If Byte mode, signal is set low. Data 1 through Data 8. These pins are host-driven in Compatibility mode and bidirectional in Byte mode.

  • Page 300: Terminating Resistor Configurations

    Chapter 5 IEEE 1284 Parallel Interface Host Logic High—Driven by the host. When set to high, the host indicates all of its signals are in a valid state. When set to low, the host indicates its power is off or its signals are in an invalid state. nInit —Resets init interface from the host.
  • Page 301 Terminating Resistor Configurations The shipping kit for this printer includes 220 ohm pull-up and 330 ohm pull-down alternate terminating resistors. If you install the 220 ohm pull- up resistor, you must also install the 330 ohm pull-down resistor. Table 11 lists the three terminating resistor configurations you can install: Table 11.

  • Page 302: Rs-232 And Rs-422 Serial Interfaces

    Chapter 5 RS-232 And RS-422 Serial Interfaces RS-232 And RS-422 Serial Interfaces NOTE: The RS-232 and RS-422 serial interface circuit characteristics are compatible with the Electronic Industry Association Specifications EIA-232-E and EIA-422-B. The RS-232 and RS-422 serial interfaces enable the printer to operate with bit serial devices that are compatible with an RS-232 controller.

  • Page 303: Rs-232

    RS-232 RS-232 Table 12. Standard 500, 1000, 1500 lpm Models RS-232 Serial Interface Connector Pin Assignments Input Signals Output Signals Miscellaneous Signal Signal Signal Receive Data (RXD) Transmit Status & Control Chassis Ground Data (TXD) Clear To Send (CTS) Request To Send (RTS) Signal Ground Data Set Ready (DSR) Data Terminal Ready (DTR)

  • Page 304: Rs-422

    Chapter 5 RS-232 And RS-422 Serial Interfaces Clear To Send (CTS). Status signal to the printer indicating the host is ready to receive data/status signals from the printer. Data Set Ready (DSR). Status signal to the printer indicating the host is in a ready condition.

  • Page 305: Reprogramming The Security Key

    Reprogramming The Security Key Reprogramming The Security Key The security key on the PSA3 controller board can be reprogrammed with a Software Program Exchange (SPX) module. The SPX is an intelligent module that plugs into the debug port on the back of printers equipped with the PSA3 “Hurricane”...
  • Page 306 Chapter 6 Reprogramming The Security Key Debug Port Figure 25. Inserting The SPX into the Debug Port 4. Power on the printer. The printer will begin its boot-up sequence. 5. When the printer detects a valid SPX, the control panel displays: “NEW SPX DETECTED PRESS ENTER”...
  • Page 307 How To Program The Security Key 9. Press the ENTER key. The printer will reboot itself and you may resume normal printing. 10. You may need to download a new program file to use the new feature. 11. You may need to set additional menu parameters for any new features that have been added or enabled.
  • Page 308 Chapter 6 Reprogramming The Security Key...

  • Page 309: Troubleshooting

    Troubleshooting Cleaning Requirements Clean the printer every six months or after every 1000 hours of operation, whichever occurs first. If the printer is located in a dusty area or is used for heavy duty printing, clean it more often. WARNING Disconnect the power source before cleaning the printer.

  • Page 310: Interior Cleaning

    Chapter 7 Cleaning Requirements Interior Cleaning Over time, particles of paper and ink accumulate inside the printers. This is normal. Paper dust and ink build-up must be periodically removed to avoid degraded print quality. Most paper dust accumulates around the ends of the platen and ribbon path. Barcode Ribbon Ribbon Spool...
  • Page 311 Interior Cleaning To clean the interior of the printer perform the following steps. 1. Power off the printer and unplug the printer power cord. 2. Open the printer cover. 3. Fully raise the platen lever. 4. Unload the paper. 5. Unlatch the ribbon and ribbon spool and carefully lift them off the hubs.

  • Page 312: Diagnosing Problems

    Chapter 7 Diagnosing Problems 11. Brush and vacuum the accumulated dust or residue inside the lower cabinet. 12. Wipe the lower cabinet interior with a clean, lint-free cloth dampened (not wet) with water and mild detergent or window cleaning solution. Dry the lower cabinet interior by wiping it down with a clean, lint-free cloth.

  • Page 313: Printing A Hex Dump

    Printing A Hex Dump Printing A Hex Dump A hex code printout (or hex dump) is a translation of all host interface data to its hexadecimal equivalent, listing all ASCII character data received from the host computer with their corresponding two-digit hexadecimal codes. Hex dumps are used to troubleshoot printer data reception problems.

  • Page 314: Fault Messages

    Chapter 7 Diagnosing Problems Fault Messages If a fault condition occurs in the printer, the status indicator on the control panel flashes on and off, and the message display indicates the specific fault. Fault messages are summarized in Table 15. Displayed faults fall into one of two categories: •...
  • Page 315 Fault Messages Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? 06 HOST REQUEST Host attention The host computer or message. printer controller requires attention. 08 HOLD PRINT Printer was offline Press ON LINE to put TIMEOUT more than 10 printer in online state.
  • Page 316 Chapter 7 Diagnosing Problems Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? 32 PAPER JAM A timeout message Clear paper jam and TIMEOUT is sent to the host if reload paper. no paper motion has occurred for 10 minutes after CLEAR was pressed to clear...
  • Page 317 Fault Messages Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? ACTIVATE LOST Printer detects The printer reports the twinax protocol error. communication errors. B10 ERROR: NO SDRAM DIMM Cycle power to see if the DRAM DETECTED* may not be message clears, if not, properly installed.
  • Page 318 Chapter 7 Diagnosing Problems Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? B19 ERROR: DC The boot code Cycle power to see if the RETURNED* calls the DC (the message clears, if not, printer software contact your authorized that runs on the service representative.
  • Page 319 Fault Messages Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? B23 ERROR: FLASH SIMM may Cycle power to see if the DECOMPRESS not be properly message clears, if not, CKSUM* installed. contact your authorized service representative. B30-STATUS: Status message No action is required.
  • Page 320 Chapter 7 Diagnosing Problems Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? B42 ERROR: SDRAM DIMM is Cycle power to see if the SDRAM ROWS NOT not compatible with message clears, if not, ALLOWED* the computer. contact your authorized SDRAM DIMM service representative.
  • Page 321 Fault Messages Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? B47 ERROR: SDRAM DIMM is Cycle power to see if the SDRAM LARGER not compatible with message clears, if not, THAN 256M* the computer. contact your authorized SDRAM DIMM service representative.
  • Page 322 Chapter 7 Diagnosing Problems Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? B51 STATUS: XX% Status message No action is required. PROGRAMMING... file sucessfully loaded and is being saved in flash memory. B55 STATUS: SEND EC program No action is required.
  • Page 323 Fault Messages Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? CLEAR PAPER JAM No paper motion. Clear jam and reload paper. If this message recurs, contact your authorized service representative. CLEARING Status message: No action is required. PROGRAM FROM emulation software FLASH...
  • Page 324 Chapter 7 Diagnosing Problems Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? DO NOT POWER This is a standard Do not power off the warning message printer until downloading that displays while is complete. the printer is downloading software.
  • Page 325 Fault Messages Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? ERROR: EC XXXX is a number Contact your authorized STOPPED AT from 0000 to 0010. service representative. STATE XXXX The Engine Controller has stopped and is in the state identified by the number displayed.
  • Page 326 Chapter 7 Diagnosing Problems Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? ERROR: NVRAM The non-volatile Contact your authorized FAILURE SRAM on the service representative. controller board has failed. ERROR An interim Contact your authorized OCCURRED message that service representative.
  • Page 327 Fault Messages Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? ERROR: SHORT AT Hardware failure in Contact your authorized ADDRESS XXXX SDRAM or service representative. controller circuitry. ERROR: WRITING Hardware or Contact your authorized TO FLASH software fault in service representative.
  • Page 328 Chapter 7 Diagnosing Problems Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? EXHAUST FAN FLT Sensors cannot Power off the printer and (Cabinet model only) detect current in remove the paper path (see Maintenance fan circuit. Manual).
  • Page 329 Fault Messages Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? FREEFORM OFF A control panel key Press the key again. is stuck in the down position. FREEFORM ON: This message Contact your authorized OFF HOLD KEY @ appears if the service representative.
  • Page 330 Chapter 7 Diagnosing Problems Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? HMR BANK FAN Sensors cannot Check that fan cable is detect current in connected. Check for fan circuit. obstruction of vents and fan airway; remove any obstructions.
  • Page 331 Fault Messages Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? INTERRUPT The controller Cycle power. If this UNUSED VECTOR board receives an message occurred once interrupt it does not and never again, you can understand. ignore it.
  • Page 332 Chapter 7 Diagnosing Problems Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? LOADING The printer has No action is required. PROGRAM INTO deleted the FLASH previous program from flash memory and is loading the new program into flash memory.
  • Page 333 Fault Messages Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? ONLINE Enable poll Check cable connection CU TIMED OUT timeout. The and host system. printer was not enabled for one minute. (Coax interface) PAP BAD TABLE* Fatal firmware Contact your authorized error on controller...
  • Page 334 Chapter 7 Diagnosing Problems Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? PAP NOT SCHED* Fatal firmware Contact your authorized error on controller service representative. board. PAP NT AT SPEED* Fatal firmware Contact your authorized error on controller service representative.
  • Page 335 Fault Messages Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? PLEASE WAIT... The printer finished No action is required. RESET IN loading the PROGRESS program into flash memory and is automatically resetting itself. POWER SAVER Status message: No action is required.
  • Page 336 Chapter 7 Diagnosing Problems Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? PROTECTED Fatal firmware Contact your authorized INSTR* error on controller service representative. board. PWR SUPP VOLT * Power supply Replace power supply failed. board.
  • Page 337 Fault Messages Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? RIB INVLD STATE* Ribbon Invalid Contact your authorized State. service representative. RIBBON DRIVE The controller Contact your authorized board does not service representative. detect a ribbon drive motor.
  • Page 338 Chapter 7 Diagnosing Problems Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? SECURITY KEY The security key is Contact your authorized NOT DETECTED not present or has service representative. failed. SENDING Status message: No action is required. PROGRAM the printer is TO EC...
  • Page 339 Fault Messages Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? SHUTTLE STALL The shuttle is not Set the platen lever to moving. match the thickness of paper, but not too tightly. Check and adjust the platen gap.
  • Page 340 Chapter 7 Diagnosing Problems Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? STACKER FAULT Stacker is not Check for obstructions in functioning the stacker area. If fault correctly. persists, contact your authorized service representative. STACKER FULL Power stacker is Remove paper.
  • Page 341 Fault Messages Table 15. LCD Message Troubleshooting Table Can User Displayed Message Explanation Solution Correct? UNDEF Fatal firmware Contact your authorized INTERRUPT* error on controller service representative. board. UNDFNED Fatal firmware Contact your authorized OPCODE* error on controller service representative. board.
  • Page 342 Chapter 7 Diagnosing Problems...

  • Page 343: A Printer Specifications

    Printer Specifications Ribbon Specifications Standard Ribbons Part Number Ultra Capacity 179499-001 (recommended for most text and barcode OCR) High Label 179488-001 (recommended for coated or shiny label stock) Specialty Ribbons Red Ribbon 179490-001 Blue Ribbon 179491-001 Green Ribbon 179492-001 Security Ribbon 179493-001 Quick Dry Ribbon 179494-001...

  • Page 344: Paper Specifications

    Appendix A Paper Specifications Paper Specifications Type: Edge-perforated, fan-fold, 3 to 17 inches (7.62 to 43.18 cm) wide, 2 to 12 inches (5.08 to 30.48 cm) long. SureStak Power Stacker option is works with forms 5 to 12 inches (12.7 to 30.48 cm) long and up to 16 inches (41 cm) wide without the paper tent or 15.5 inches (39.5 cm) wide with the paper tent installed.
  • Page 345 Paper Specifications Labels On Backing: One-part continuous perforated fanfold back form. Labels must be placed at least 1/6 inch (0.42 cm) from the fan-fold perforation. Backing adhesive must not be squeezed out during printing. Sheet Size: 3 to 17 inches (7.62 to 43.18 cm) wide, including the two standard perforated tractor feed strips.

  • Page 346: Printer Weight And Dimensions

    Appendix A Printer Weight And Dimensions Printer Weight And Dimensions Cabinet Type Dimensions Weight Height Width Depth Unpacked Packaged Floor Cabinet 42.5 inches 27 inches 29 inches* 225 lbs. 285 lbs.* Pedestal 35 inches* 26 inches 21 inches 105 lbs.** 115 lbs.** * With a power stacker, the weight increases by 21 lbs.
  • Page 347 Electrical Characteristics Acoustic Noise Level Acoustic Noise Levels Pedestal Cabinet Models per ISO 9296 Models Printing 50 dB (500 lpm/1000 lpm) 65 dB 52 dB (1500 lpm) 65 dB 54 dB (2000 lpm) 6.8 Bel 8.0 Bel Standby 48 dB 50 dB 6.3 Bel 6.5 Bel...

  • Page 348: Electrical Characteristics

    Appendix A Electrical Characteristics Electrical Characteristics Voltage (+/-10%) Freq (+/-10%) Amps Watts BTU/Hr 500 lpm AC 100-120V 50-60 Hz 275W pedestal AC 200-240V 50-60 Hz 1.5A 275W 1000 lpm AC 100-120V 50-60 Hz 3.5V 300W 1025 pedestal AC 200-240V 50-60 Hz 1.6A 300W 1025...

  • Page 349: Interfaces

    Interfaces Type: Standard: IEEE 1284 Parallel, Centronics Parallel, RS-232 serial, Dataproducts Parallel Optional: Coax, Twinax, RS-422 serial, Ethernet 10/100Base-T. Logic Levels: TTL/EIA ® -232E/EIA-422B Transfer Rates: Up to 200 Kilobytes on parallel interface. Up to 19.2K baud on RS-232 serial interface. Up to 115.2K baud on RS-422 serial interface Printing Rates The printing speed of text is measured in lines per minute (lpm) and...
  • Page 350 Appendix A Printing Rates...

  • Page 351: B Ascii Character Set

    ASCII Character Set B7 B6 BITS OCTAL equivalent DECIMAL equivalent 1 0 1 1 HEX equivalent ASCII Character Name BITS COLUMN (XON) 0 0 1 0 " 0 0 1 1 (XOFF) 0 1 0 0 0 1 0 1 0 1 1 0 &...
  • Page 352 Appendix B...

  • Page 353: C Communication Notices

    Communication Notices Notices This information was developed for products and services offered in the U.S.A. Printronix may not offer the products, services, or features discussed in this document in other countries. Consult your Printronix representative for information on the products and services currently available in your area.
  • Page 354 Appendix C Notices The following paragraph does not apply to the United Kingdom or any other country where such provisions are inconsistent with local law: PRINTRONIX PROVIDES THIS PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
  • Page 355 Printronix encourages owners of information technology (IT) equipment to responsibly recycle their equipment when it is no longer needed. Printronix offers a variety of programs and services to assist equipment owners in recycling their IT products. Information on these product recycling offerings can be found on Printronix’s Internet site at http://www.printronix.com.

  • Page 356: Energy Star

    Appendix C Energy Star Energy Star The Environmental Protection Agency E Computers NERGY program is a partnership effort with manufacturers of data processing equipment to promote the introduction of energy- efficient personal computers, monitors, printers, fax machines, and copiers to help reduce air pollution and global warming caused by electricity generation.

  • Page 357: Product Recycling And Disposal

    Product Recycling and Disposal This unit may have lead-containing materials – such as circuit boards and connectors – that require special handling. Before this unit is disposed of, these materials must be removed and recycled or discarded according to applicable regulations. This book contains specific information on batteries and refrigerant where applicable.

  • Page 358: Communication Statements

    Appendix C Communication Statements Communication Statements Federal Communications Commission (FCC) Statement This equpment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 359 European Union (EU) Conformity Statement Hereby, Printronix declares that this product is in compliance with the essential requirements and other relevent provisions of Directive 1999/5/EC. Printronix cannot accept responsibility for any failure to satisfy the protection requirements resulting from a non-recommended modification of the product, including the fitting of non-Printronix option cards.

  • Page 360: German Conformity Statement

    Appendix C Communication Statements Statement of CISPR 22 Edition 2 Compliance Attention: This is a Class A Product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Japanese VCCI Class A German Conformity Statement Handbuchtexte: FCC class A entspricht: EMVG Klasse A...
  • Page 361 EN 55024 Hinweis: Wird dieses Gerät in einer industriellen Umgebung betrieben (wie in EN 55024 festgelegt), dann kann es dabei eventuell gestört werden. In solch einem Fall ist der Abstand bzw. die Abschirmung zu der industriellen Störquelle zu öergrvßern. Anmerkung: Um die Einhaltung des EMVG sicherzustellen sind die Geräte, wie in den Printronix Handbüchern angegeben, zu installieren und zu betreiben.
  • Page 362 Appendix C Communication Statements Taiwan Warning: This is a Class A product. In a domestic environment this product may cause radio interference in which case the user will be required to take adequate measures.

  • Page 363: Lithium Battery Warning

    Korea CAUTION: This product is equipped with a 3-wire power cord and plug for the user’s safety. Use this power cord in conjunction with a properly grounded electrical outlet to avoid electrical shock. Lithium Battery Warning The controller board contains a lithium battery sealed inside the real-time clock chip.

  • Page 364: Software License Agreement

    Appendix C Software License Agreement Software License Agreement Your printer contains, among other software, Printronix operating software including, but not limited to the Embedded Configurable Operating System (the “eCos Software”) as embedded software. The terms of this Agreement apply only to the eCos Software, and all other embedded software supplied with the printer.
  • Page 365 3. No Warranty THE EMBEDDED SOFTWARE IS PROVIDED UNDER THIS LICENSE ON AN "AS IS" BASIS, WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, WARRANTIES THAT THE EMBEDDED SOFTWARE IS FREE OF DEFECTS, MERCHANTABLE, FIT FOR A PARTICULAR PURPOSE OR NON-INFRINGING.
  • Page 366 Appendix C Software License Agreement 5. Limitation of Liability UNDER NO CIRCUMSTANCES AND UNDER NO LEGAL THEORY, WHETHER TORT (INCLUDING NEGLIGENCE), CONTRACT, OR OTHERWISE, SHALL RED HAT, PRINTRONIX, ANY OTHER CONTRIBUTOR, OR ANY DISTRIBUTOR OF THE EMBEDDED SOFTWARE, OR ANY PART THEREOF, OR ANY SUPPLIER OF ANY OF SUCH PARTIES, BE LIABLE TO YOU OR ANY OTHER PERSON FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OF ANY...
  • Page 367 7. Miscellaneous This Agreement represents the complete agreement concerning subject matter hereof. If any provision of this Agreement is held to be unenforceable, such provision shall be reformed only to the extent necessary to make it enforceable. This Agreement shall be governed by California law provisions (except to the extent applicable law, if any, provides otherwise), excluding its conflict-of- law provisions.

  • Page 368: Trademark Acknowledgements

    Appendix C Trademark Acknowledgements This document contains proprietary information protected by copyright. No part of this document may be reproduced, copied, translated, or incorporated in any other material in any form or by any means, whether manual, graphic, electronic, mechanical, or otherwise, without the prior written consent of Printronix.
  • Page 369 IEEE is a registered service mark of the Institute of Electrical and Electronics Engineers, Inc. QMS is a registered trademark, and Code V is a trademark of Quality Micro Systems, Inc. TUV is a registered certification mark of TUV Rheinland of North America, Inc.
  • Page 370 READ THIS SOFTWARE LICENSE AGREEMENT BEFORE USING THIS PRINTER Software License Agreement Disclaimer of Warranties and Limitation of Remedies CAREFULLY READ THE FOLLOWING TERMS AND THE PARTIES AGREE THAT ALL OTHER WARRANTIES, CONDITIONS BEFORE USING THIS PRINTER. USING THIS EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF PRINTER INDICATES YOUR ACCEPTANCE OF THESE TERMS FITNESS FOR A PARTICULAR PURPOSE AND AND CONDITIONS.
  • Page 371 Index Numerics 5225 World Trade, 180 5250 Params, 194 06 HOST REQUEST message, 315 5250 Params menu 08 HOLD PRINT TIMEOUT message, 315 Active Char Set, 196 15 COMM CHECK message, 315 Format Control, 199 15V PWR FAIL * message, 315 Graphic Chek Cod, 198 20 CPI Condensed Graphic Chek Err, 197...
  • Page 372 Index Adapter Address, 73 Slow Paper Slew, 284 ADAPTER ADDRESS menu, 107 AI 00 Spaces, 136, 156 DHCP, 108 Alarm, ADVANCED USER menu, 284 Gateway address, 107 Alt. Char Set, Proprinter XL Emulation, 236 IP address, 107 Alt. Set 80-9F, 172, 221 MAC address, 107 Epson FX Emulation, 241 Subnet mask, 107...
  • Page 373 Index ASCII data port, Ethernet Parameters Auto Uppercase, 133 menu, 114 Autowrap, 131 ASCII data port, WLAN Parameters Autowrap, LG Emulation, 270 menu, 118 Auth Method, WLAN LEAP menu, 121 B10 ERROR NO DRAM DETECTED* Auto Elevator, ADVANCED USER message, 317 menu, 282 B11 ERROR RAM TEST FAILED* Auto FF at ^PN, 158...
  • Page 374 Index B44 ERROR SDRAM NOT 64 BITS WIDE* Barcode Quality, IPDS Emulation, 257 message, 320 Barcode Size, IPDS Emulation, 258 B45 ERROR SDRAM IS WRONG Barcode Speed, IPDS Emulation, 258 VOLTAGE* message, 320 Baud Rate, Serial submenu, 100 B46 ERROR SDRAM HAS MIXED SIZES* BC Check Digit, ANSI Emulation message, 320 menu, 253...
  • Page 375 Index Cancel Key, ADVANCED USER ANSI Emulation menu, 252 menu, 285 ASCII, 351 Centronics (Parallel) submenu, 89 Epson FX Emulation, 241 Auto Trickle, 91 Proprinter XL Emulation, 235 Buffer Size in K, 91 Serial Matrix Emulation, 232 Busy On Strobe, 90 Characteristics, environmental, 346 Data Bit 8, 89 Cleaning...
  • Page 376 Index PA2, 170 Config Print, PCL-II Emulation, 266 Prt Partial Line, 169 CONFIG. CONTROL menu, 80 PTX Transparent, 171 Delete Config., 81 SCS Buffer Cntrl, 171 Load Config., 80 Set Text Orientn, 172 Name Configs, 82 Translate Table, 176 Power-Up Config., 81 Translation Tbl, 169 Print Config., 81 Coax/Twinax (CTHI) Emulation menu, 165...
  • Page 377 Index UP + DOWN, 29 Data Strobe UP or DOWN, 29 Centronics Parallel Interface VIEW/EJECT key, 27 Signals, 295 Conventions, manual, 16 Dataproducts Parallel Interface CPI/LPI Select, 211 Signals, 293 ANSI Emulation menu, 248 Data Term Ready, Serial submenu, 101 CR at MPP+1, 173, 190 Data Terminal Ready (DTR), RS-232, 304 CR Edit, 132...
  • Page 378 Index Default Code Page, IPDS Emulation, 259 System Memory, 289 Default configurations, 53 Test Width, 287 Default Font, IPDS Emulation, 260 Dimensions, printer, 21, 346 Define CR Code, 131, 220 Display Functions, PCL-II Emulation, 264 ANSI Emulation menu, 251 Display Language, PRINTER Epson FX Emulation, 239 CONTROL, 278 Proprinter XL Emulation, 234...
  • Page 379 Index Epson FX Character Set menu, 242, 243 Error Msgs, 159 LG, 245 ERROR NO DRAM DETECTED PCL-II, 244 message, 325 Epson FX Emulation, 239 ERROR NVRAM FAILURE message, 326 20 CPI Condensed, 241 ERROR OCCURRED FLUSHING Alt. Set 80-9F, 241 QUEUES* message, 326 Auto LF, 240 ERROR PROGRAM NEEDS MORE...
  • Page 380 Index ETHERNET ADDRESS menu, 111 DHCP, 112 Face CPI Delay, PCL-II Emulation, 264 Gateway address, 112 Fault messages, 314 IP address, 111 06 HOST REQUEST, 315 MAC address, 112 08 HOLD PRINT TIMEOUT, 315 Subnet mask, 112 15 COMM CHECK, 315 ETHERNET DETECTED message, 327 15V PWR FAIL *, 315 ETHERNET PARAMETERS menu...
  • Page 381 Index B23 ERROR DECOMPRESS BARCODE MISSING, 322 CKSUM*, 319 BUFFER OVERRUN, 322 B30 STATUS INITIALZING, 319 CLEAR PAPER JAM, 323 B35 STATUS WAITING FOR EC CLEARING PROGRAM FROM STATUS, 319 FLASH, 323 B40 ERROR SDRAMEE PROM CLOSE PLATEN, 323 CKSUM BAD*, 319 COIL HOT, 323 B41 ERROR DIM MEMORY NOT CTL VOLT FAIL *, 323...
  • Page 382 Index ERROR PROGRAM NEEDS MORE ILL EXT BUS ACC *, 330 DRAM, 326 ILLGL OPR ACCSS *, 330 ERROR PROGRAM NEEDS MORE INCOMPAT E-NET, 330 FLASH, 326 INTAKE FAN FAULT, 330 ERROR PROGRAM NOT INTERRUPT UNUSED COMPATIBLE, 326 VECTOR 00, 331 ERROR PROGRAM NOT VALID, 326 INVALID ACTIVATE, 331 ERROR SECURITY KEY NOT...
  • Page 383 Index PAP UNEXP INT *, 334 SHUTL INV CMD *, 338 PARAMETER ERROR, 334 SHUTL INV PARM *, 338 PARITY ERROR, 334 SHUTL OVR SPEED*, 338 PLAT INV CMD *, 334 SHUTTLE JAM, 338 PLAT INV PARM *, 334 SHUTTLE STALL, 339 PLAT INV STATE *, 334 SOFTWARE ERROR* CYCLE PLEASE WAIT...RESET IN...
  • Page 384 Index FF Valid at TOF, Proprinter XL Graphic Chek Cod, 5250 Params Emulation, 235 menu, 198 FF Validity, 174, 191 Graphic Chek Err, 182 FF, LG Emulation, 272 Graphic Chek Err, 5250 Params menu, 197 File System, ADVANCED USER Graphics Density, PCL-II Emulation, 264 menu, 283 Graphics enhancement, 15 FIRMWARE ERROR message, 328...
  • Page 385 Index GRF CHECK ERROR PRESS STOP IEEE 1284 Parallel (Bidirectional) message, 329 Submenu, 86 Auto Trickle, 87 Buffer Size in K, 87 HAM. COIL OPEN * message, 329 Offline Process, 88 HAMMER COIL BAD, ### Message, 329 Prime Signal, 87 HB NOT INSTALLD * message, 329 TOF Action, 87 Hex Dump Mode, MAINT/MISC menu, 280...
  • Page 386 Index Compressed CPI, 138 IGP/VGL submenu, 146 CR Edit, 132 Error Handling, 159 Define CR (Carriage Return) Font Set, 161 Code, 131 Graphics Options, 153 Define LF (Line Feed) Code, 131 Ignore/DB8 Setup, 160 Error Report, 142 LG, 150 Expanded Font, 139 LPI, 152 Ext Execute Copy, 134 PCL-II, 148...
  • Page 387 Index INVALID ACTIVATE message, 331 INVALID COMMAND message, 331 Job Control, Adapter Params menu, 111 IP address Job Control, Ethernet Parameters Adapter Address menu, 107 menu, 115 Ethernet Address menu, 111 JOB SELECT key, 29 WLAN Address menu, 115 IPDS Data Port, Adapter Params KDC Port Number, WLAN Kerberos menu, 110 menu, 120...
  • Page 388 Index LG Emulation message, 332 Autowrap, 270 Loading Used Ribbon, 14 CR, 271 Logical Buf Size, 200 FF, 272 LP+ Font, 155 Font, 269 LP, LG Emulation, 271 Horiz Forms, 270 LPI, 152 I-2/5 Guard Bars, 273 LPI Adjust, PCL-II Emulation, 265 LP, 271 Plot Mode Opt, 273 MAC address...
  • Page 389 Index Menu Nibble Mode, IEEE 1284 Parallel ACTIVE IGP EMUL, 123 Interface, 296 ADVANCED USER, 279 NL At MPP+1, 173, 190, 203 CONFIG. CONTROL, 80 noise level, acoustic, 347 DIAGNOSTICS, 287 NON VOLATILE MEMORY FAILED EMULATION, 164 message, 332 HOST INTERFACE, 83 Novell frame, Adapter Params menu, 109 IGP/PGL Font Set, 143 Novell protocol, Adapter Params...
  • Page 390 Index Operational procedures Paper cancel a print job, 50 reload, 32 reload paper, 32 unload, 43 unload paper, 43 PAPER ADVANCE key, 27 Optimized Ratio, 135 Paper Empty (PE) Optimizing print quality, 66 Centronics Parallel Interface Optimizing print speed, 67 Signals, 295 Output Darkness, 13 Paper Instruction (PI)
  • Page 391 Index Line Terminator, 264 Poll Response, Serial submenu, 102 LPI Adjust, 265 Port Type, Auto Switching submenu, 85 Max Line Width, 263 Pos. on BC/OvrSz, ANSI Emulation Page L./Inches, 266 menu, 253 Page L./Lines, 265 Position Aft FF (4234 only), 174, 190 Page Length Rep, 263 Power Consumption, 348 Perforation Skip, 264...
  • Page 392 Index Prime, Centronics Parallel Interface Ribbon Action, 286 Signals, 295 Ribbon End Point, 275 Print Char. Set, 215 Tear Bar Dist. (Distance), 277 Print Config., 81 Unidirectional, 277 Print IPDS Fonts, IPDS Emulation, 260 PRINTER HOT * message, 335 Print job, cancel, 50 Printer interfaces, 291 Print Mode Opt, LG Emulation, 272 Printer PI, 161...
  • Page 393 Index Define LF Code, 235 P-Series XQ Emulation, 226 FF Valid at TOF, 235 Auto LF, 227 Protect Configs., 81 Compressed Print, 228 PROTECTED INSTR * message, 336 Control Code 06, 226 PRT CONFIG key, 28 Define CR Code, 227 Prt Partial Line, 169, 180 Define LF Code, 227 3270 Params menu, 187...
  • Page 394 Index Horiz Forms, 78 Requirements Host Interface, 73 power, 19 Margins, 76 printer site, 20 Max Line Width, 78 Reset Cfg Names, 82 Page Length Rep, 78 Reset Cmd CFG Ld, 216 PGL SFCC, 75 ANSI Emulation menu, 252 Power-Up Config, 79 Reset Cmd CFG Ld, PCL-II Emulation, 266 Printer Protocol, 75 Reset Kerberos Password, WLAN...
  • Page 395 Index RIBBON STALL message, 337 PROCESSOR message, 338 RIBBON UNDER 2% message, 337 Serial Interfaces Ribbons, changing, 47 RS-232, 302 Rot. Char Size, 154 RS-422, 302 RS-232, 303 Serial Matrix Character Set menu, 233 Clear to Send (CTS), 304 Serial Matrix Emulation, 230 Data Carrier Detect (DCD), 304 Alt.
  • Page 396 Index Set Sharing, ADVANCED USER SOFTWARE ERROR* CYCLE POWER menu, 283 message, 339 Set Text Orientn, 172, 183 SPC Char Set, SPC Type, 206 3270 Params menu, 189 SPC Coax Params, 200 5250 Params menu, 198 Buffer Print, 201 SET TOF key, 28 Buffer Reprint, 202 SFCC &...
  • Page 397 Index Specifications interfaces, 349 TABLE MISMATCH DOWNLOAD AGAIN label, 345 message, 340 paper, 344 TCB CORRUPTED* message, 340 Speed print, 349 TCP PORT BUSY message, 340 SPX FOUND, ERROR KEY NOT Tear Bar Dist. (Distance), PRINTER DETECTED message, 339 CONTROL, 277 SPX NOT NEEDED OPTIONS ENABLED Terminating resistor configurations, 300 message, 339...
  • Page 398 Index Trunc Dyn Data, 141 UP or DOWN key, 29 Truncate Alpha, 153 UPC Descenders, 135, 154 Truncate PI Slew, ANSI Emulation Upr. Case Select, P-Series XQ menu, 254 Emulation, 229 Twinax Params menu, 178 User-Def Ratio, 137 5225 World Trade, 180 Usr Defined HTRN, 172, 201 Active Char Set, 179 Usr Defined HTRN, PTX Transparent, 181...
  • Page 399 Index MAC address, 116 Subnet mask, 116 WLAN Kerberos menu Clock Skew, 120 KDC Port Number, 120 Kerberos Enable, 119 Kerberos Password, 120 Renew Lifetime, 121 Reset Kerberos Password, 120 Ticket Lifetime, 120 WLAN LEAP menu Auth Method, 121 LEAP Password, 122 LEAP Username, 122 Reset LEAP Password, 122 Reset LEAP User, 122...
  • Page 400 Index...
  • Page 402 OKI Europe Limited Central House Balfour Road Hounslow TW3 1HY United Kingdom Tel: +44 (0) 208 219 2190 Fax: +44 (0) 208 219 2199 OKIPRINTINGSOLUTIONS *250011-001* 250011-001A...
