GPS Antenna
Follow the steps below to connect the GPS cable.
Table 29. GPS Cable Connection
Classification
Installation section
Cable
Connector
Recommended
torque value
Working tools
Installing GPS Line Amplifiers
The allowed length of a cable is limited depending on the GPS cable
configuration. You must compensate for the loss by installing a line amplifier if
the cable exceeds the length allowed. Because the required number of line
amplifiers and installation method may vary depending on the extended length of
the LMR-400 cable and line amplifier specifications, you must refer to the
installation instructions provided with the line amplifier.
In addition, you must install the line amplifier within 32.8 ft. (10 m) from the GPS
antenna.
Line Amplifier Usage Guideline for GPS Cable Configuration
The total length of the LMR-400 cable should be no longer than 328.08 ft.
(100 m).
Verizon 4G LTE Network Extender 2 for Enterprise User Guide v1.0
Copyright © 2019, All Rights Reserved.
Description
The Network Extender, GPS arrestor, GPS antenna
The Network Extender
GPS arrestor
GPS arrestor
GPS antenna (or line amplifier)
The Network Extender
Connection part between
RG-316D and LMR-400
GPS arrestor
Line amplifier
GPS antenna
SMA-male
N type-male
TNC-male
Cable cutter, wire stripper, nipper, torque wrench, spanner, knife, soldering iron, and
lead
Appendix A Outdoor GPS Antenna Installation
9.84 ft. (3 m) or less
More than 9.84 ft. (3
m)
LMR-400
SMA-male
RG-316D
LMR-400
N type-male
N type-male
TNC-male
0.18 ft.lb. (2.5 kgf.cm)
1.45 ft.lb. (20 kgf.cm)
0.65 ft.lb. (9 kgf.cm)
RG-316D
RG-316D (9.84 ft. or less)
+LMR-400
N type-male
N type-female
