- Page 1 Instruction PT260 Manual Planer Thicknesser IMPORTANT For your safety read instructions carefully before assembling or using this product. Save this manual for future reference. Holywell Road Sheffield S4 8AS Tel: 0114 244 4238 Fax: 0114 244 9098 www.tt-hire.co.uk email sales@tedbartinkerhire.co.uk...
- Page 2 Contents Terms & Conditions Of Usage Health & Safety Guidance page 4 Additional Safety Instructions For Planer Thicknessers page 5 Record Power Guarantee page 6 EU Declaration Of Conformity page 29 User Manual Getting to know your planer thicknesser page 7 Machine specification...
-
Page 3: Health & Safety Guidance
Health & Safety Guidance READ ALL THE INSTRUCTIONS IN THIS MANUAL 15. Maintain tools with care. CAREFULLY BEFORE ASSEMBLY, INSTALLATION AND USE • Follow instructions for lubrication and changing accessories. OF THIS PRODUCT. KEEP THESE INSTRUCTIONS IN A • Inspect electric cords periodically and, if damaged, have them SAFE PLACE FOR FUTURE REFERENCE. -
Page 4: Additional Safety Instructions For Planer Thicknessers
Additional Safety Instructions For Planer Thicknessers SAFETY IS A COMBINATION OF OPERATOR mounted on the Planer. COMMON SENSE AND ALERTNESS AT ALL 18. Clear everything except the work piece and related support devices off the table before turning the planer on. TIMES WHEN THE PLANER THICKNESSER 19. -
Page 5: Getting To Know Your Planer Thicknesser
Wheel kit operating pedal Cutter guard rise and fall Motor rating plate Machine frame Machine Specification PT260 SPECIFICATION Thicknesser feed rate: 5m per min Cutter block speed: 6500rpm Number of cutter block knives: 2 Max depth of cut: 3mm Planing table length: 1000mm... -
Page 6: Dust Extraction
Operation & Planer Thicknesser Practice 6.1 Chip removal when planing Fig.6.1 Set thicknessing bed to approximately 2/3 capacity and place extraction connector on to it. Raise thicknessing bed to secure extraction connector in position Fig.6.1 Note: Ensure that the notches in top of the connector locks in the spacer shaft &... - Page 7 Operation & Planer Thicknesser Practice - cont. 6.3 Planing Fig.6.5A Fig.6.7A This operation is carried out for straight- ening a workpiece and for trimming the long side of panels. Place workpiece flush on to in-feed table, with your left hand set the cutter guard to the required height (workpiece should be run clear of the guard.
- Page 8 The purpose of the microswitch is to enhance the safety of the machine by ensuring that the cutterblock is inaccessible whilst the machine is in operation. The PT260 is equipped with 3 safety micro switches. 1. In thicknesser mode, the extraction Fig.6.13...
- Page 9 Clean regularly with white spirit, then coat with a light film of silicone spray such as Record Power CWA195 to enhance passage of workpiece on table Fig.8.1. This machine will perform in conformity with the description contained in this...
-
Page 10: Planer Blade
Maintenance - cont. Replacing Blades Fig.8.2 CAUTION! This procedure involves close contact with the planer blade. Ensure that gloves are worn at all times to prevent injury to the hands. To remove the planer knives 1. Disconnect the machine from the electricity supply. - Page 11 Maintenance - cont. 5. To set the knife projection, turn the Fig.8.7 grub screws in the planer knife lockbar with a 3mm Allen key as required. 6. To tighten, turn the four screws of the planer knife lockbar fully out. To prevent distortion of the planer knife lockbar start with the screws in the centre, moving out to the edges Fig.8.7.
- Page 12 Trouble Shooting Symptom Possible Causes Solutions THICKNESSER 1. Thicknesser drive belt worn / broken 1. Check and replace as necessary WILL NOT FEED 2. Drive chain tension spring broken 2. Check and replace spring WORKPIECE 3. Workpiece sticking on Thicknesser 3.
- Page 13 EU Declaration of Conformity Cert No: EU / PT260 / 1 RECORD POWER LIMITED, Unit B, Ireland Industrial Est. Adelphi Way, Staveley, Chesterfield S43 3LS declares that the machinery described:- Type: Planer Thicknesser Model No: PT260 Serial No ................. Conforms with the following directives:-...
- Page 14 Woodworking Machines & Accessories Record Power Limited Telephone: 0870 770 1777 Email: sales@recordpower.co.uk Unit B, Adelphi Way http://www.recordpower.co.uk Facsimile: 0870 770 1888 Ireland Industrial Est. Staveley S43 3LS page13...
