Product ratings

Electrical

Environmental

Testing criteria

© Danfoss | January 2017
Supply voltage
Description
DC supply voltage
DC supply current (circuit board only)
Power supply interruption
(without rebooting)
W
Warning
Output pins produce high voltage. High voltage can cause fire and/or electrical shock, if flammable
gasses or chemicals are present, can cause an explosion. To protect against product damage and possible
injury, do not exceed power supply voltage ratings and do not store this product where flammable
gasses or chemicals are present.
General
Description
Operating temperature
Storage temperature
Ingress Protection (IP) rating
W
Warning
Excessive high/low operating/storage temperatures can damage electronics. Damaged electronics can
result in performance failure. To protect against product damage and possible injury, do not operate/
store product in a environment that exceeds specified temperature ratings.
Climatic
Condition
Cold/heat storage and operation
Temperature change
Moisture ingress
Sunlight radiation
Temp humidity voltage
Mechanical
Condition
Vibration, resonance
Vibration, operation
Unit Minimum
V 9
A 0
0
ms —
Units Minimum Maximum
˚C [˚F] -20 [-4] +60 [+140]
˚C [˚F] -30 [-22] +80 [+176]
IP67
Rating
IEC 60068-2-1, IEC 60068-2-2
IEC 60068-2-14
IEC 60529
ISO 16750-4
IEC 60068-2-38
Rating
IEC 60068-2-6
IEC 60068-2-64
Maximum Comment
36 With reverse polarity protection
— UBat = 12 V
— UBat = 24 V
— 200 ms
Comment
—
—
With mating connector installed and
sealing plugs in unused connections.
