USER MANUAL- INFINEA MPOS TAB

Operational Modes

Configuration, system test, and status modes for the Infinea mPOS:
• System
• Service
• Application Download
Note:
Service and Application Download modes should only be accessed by Infinite Peripherals. Selecting specific keys or options in these modes may render
the unit unusable and require reactivation of the Infinea mPOS.

System Mode Navigation

Turn on the Infinea mPOS, and then tap System Mode on the keyboard. The menu options available are:
• Info Version
• Info Hardware
• Settings
• Test Display
• Test Keyboard
• Test MSR
• Test SCR
• Test Font0
• Test Font1
Info Version
• TDEV SN displays the serial number of your unit
• USIP SN shows the USIP serial number
• USIP VER is the current USIP version
• ISBL VER is the current USIP boot loader version
• HAL VER is the current Hardware Abstraction Layer or
Hardware Annotation Layer (HAL) version
• LOAD VER current Secure Boot Loader (SBL)
• FW VER current firmware version and name
• PINUTIL indicates the current library version
• PKFA VER displays the current version of the public key used for
firmware authentication
• PKAA VER displays the current version of the public key used for
application authentication
• PKKA VER displays the current version of the public key used
for manufacturing key authentication
info version
load ver: 2.2.7.0
ld bluepad500
fw ver: 2.4.35.0
10
