ASSEMBLY INSTRUCTIONS / INSTRUCTIONS D'ASSEMBLAGE
STEP 12
1. Attach Hinges on Doors K into pre-drilled holes on Sides E using Phillips Screw 9 .
2. Attach Hinges on Doors L into pre-drilled holes on Divider F using Phillips Screw 9 .
3. Attach available hinges on Centre Shelf I to Flip Down Door N using Phillips Screw 12 .
4. Attach 4 Magnet Plates 6 to bottom corner of Door K and Door L using Phillip Screw 10 into guide holes.
5. Attach 4 Magnets 6 using Phillip Screw 10 into guide holes on Bottom shelf B .
6. Attach Latch 11 into hole on Divider G and Flip Down Door N using Phillip Screw 10 .
7. Use a Phillips screwdriver to attach Handles 4 into guide holes on Doors K , L & Flip Down Door N .
Please use a screwdriver for the screws. The screwdriver is not included in the pack. Please use a screwdriver for the screws. The screwdriver is not included in the pack.
SVP utilisez un tournevis pour les vis. Le tournevis n'est pas fourni avec le produit. SVP utilisez un tournevis pour les vis. Le tournevis n'est pas fourni avec le produit.
B
ARTISAN
/ HOLDEN / STRATFORD
72 INCH TV MEDIA
72 PO
MEUBLE - TÉLÉ MEDIA
STAND
NOTICE / AVIS
13/16
