Schaffert Rebounder Mounting Instructions

SCHAFFERT MFG. CO., INC.
REBOUNDER
SCHAFFERT MFG. CO. INC. - phone: 800-382-2607 - fax: 308-364-2410
Before working on your planter or drill
When storing or working on the planter always install cylinder stops or place the planter on stands to prevent personal injury or damage to the attachments.
DANGER:
Read instructions completely and verify all package contents before beginning installation.
PLEASE:
If applying liquids in furrow with the Rebounder, attach either Y-Not Split It, Hose Holder, or Straight
Before working on your planter or drill
Shot kit by following kit directions.
DANGER: when storing or working on the planter always install cylinder stops or place the planter on stands to prevent personal injury or

INSTALL KIT BEFORE INSTALLING REBOUNDER TO PLANTER UNIT
damage to the Rebounder. WARNING: do not roll back or back up the planter in or on the ground as this can result in damage to the
Rebounder.
Mounting Instructions

STEP #1:

Before you begin, verify all items listed in the "package contents" table.
Remove the 1-1/4" x 3/8" carriage bolt that holds the bottom of the seed tube and seed boot in place.
NOTE: See HELPFUL HINTS FOR MOUNTING REBOUNDERS TO DRILLS.
Step #1:
remove the 1 1/4" x 3/8" carriage bolt that holds the bottom of the seed

STEP #2:

tube and seed boot in place.
Slide 5/16" x 1" carriage bolt in from the back through the square hole on the mounting bracket. From the
top side of the bracket, place the Rebounder then fender washer, and hold in place with 5/16" lock nut.
Step #2: place Rebounder on bracket with fender washer on 5/16" lock nut.

Step #3:

slide bracket with Rebounder mounted up between 18" disc and seed
STEP #3:
boot. Replace 1 1/4" x 3/8" carriage bolt and install lock nut and tighten
Slide bracket with Rebounder mounted up between 18" disc and seed boot. Replace original 1-1/4" x
in place.
3/8" carriage bolt and install lock nut and tighten in place.

Step #4:

slide Rebounder up and down in slotted hole until trailing end of
Rebounder is 3/8" to 1/2" off ground when drill is sitting on the floor.
STEP #4:
Slide Rebounder up and down in slotted hole until trailing end of Rebounder is 3/8" to 1/2" off ground
Optional fittings are available for fertilizer/chemical applications. Options
when drill is sitting on the floor.
include, Y-Not Split-It, or Hose Holder, each available for an additional charge.
bracket
5/16" bolt
Rebounder covered by one or more of the following U.S. patents: 5,640,915; 5,918,557; 6,082,275; 6,283,050; 6,453,832; 6,763,773 and 7,121,216.
71495 rd. 397 ∙ indianola, ne 69034 ∙ 308-364-2607 or 800-382-2607 ∙ fax: 308-364-2410 ∙ sales@schaffert.com ∙ www.schaffert.com ∙ 14 mar 2017
Rebounder covered by one or more of the following U.S. patents: 5,640,915; 5,918,557; 6,082,275; 6,283,050; 6,453,832, 6,763,773 and 7,121,216.
71495 rd. 397 - indianola, ne 69034 - phone: 800-382-2607 - fax: 308-364-2410 - info@schaffert.com - www.schaffert.com - Setp 18,2009
MOUNTING INSTRUCTIONS
®
FSO Opener Flexicoil Drills
REBOUNDER MOUNTING INSTRUCTIONS
TM
FSO Opener Flexicoil Drills
(Read Instructions Completely before Beginning Installation)
washer & 5/16" lock nut
Rebounder
Rebounder mounted
on bracket
