Schaffert Rebounder Mounting Instructions

SCHAFFERT MFG. CO., INC.
REBOUNDER
Before working on your planter or drill
When storing or working on the planter always install cylinder stops or place the planter on stands to prevent personal injury or damage to the attachments.
DANGER:
Read instructions completely and verify all package contents before beginning installation
PLEASE:
NOTE:
If applying liquids in furrow with the Rebounder, attach either Y-Not Split It, Hose Holder, or
Straight Shot kit by following kit directions.
INSTALL KIT BEFORE INSTALLING REBOUNDER TO PLANTER UNIT
Rebounder covered by one or more of the following U.S. patents: 5,640,915; 5,918,557; 6,082,275; 6,283,050; 6,453,832; 6,763,773 and 7,121,216.
71495 rd. 397 ∙ indianola, ne 69034 ∙ 308-364-2607 or 800-382-2607 ∙ fax: 308-364-2410 ∙ sales@schaffert.com ∙ www.schaffert.com ∙ 6 mar 2017
MOUNTING INSTRUCTIONS
®
Kinze EdgeVac Seed Tube
. See kit instructions.
308-364-2607
OR

Rebounder Package Contents

(per single row)
Item
Sawtooth Rebounder . . . . . . . . . . . . . . . 1
Sawtooth Insert . . . . . . . . . . . . . . . . . . . 1
Tie Strap . . . . . . . . . . . . . . . . . . . . . . . . . 2
Instruction Sheet . . . . . . . . . . . . . . . . . . 1

Bracket Package Contents

(per single row)
Item
Mounting Bracket . . . . . . . . . . . . . . . . . . 1
Horseshoe Clip with Set Screw . . . . . . . 1
Guard . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
final assembly
800-382-2607
Quantity
Quantity
tie straps
