CDB43131-GBK
1 CDB43131-GBK Kit Overview
The CDB43131-GBK kit consists of an evaluation board, a high dynamic range (HDR) measurement board, and a USB
cable. Each of these component boards is described in the following sections.
1.1 CDB43131 Board
The CDB43131 is shown in the following figure.
Figure 2 CDB43131 Base Board
1.2 CDB-HDR-MEAS Board
The CDB-HDR-MEAS is shown in the following figure. This board is used for measuring the very low HDR of the device
with an Audio Precision SYS-2700 or APx555 audio analyzer.
Figure 3 CDB-HDR-MEAS Board
DS1155V2DB1
3
