  • Page 1 Honeywell Ultrakey Lite User Guide Rev. A P/N: 800-00530...

  • Page 3: Table Of Contents

    Specifications........................4 Front Panel, Interfaces and Terminal Box ..............5 Front Panel ........................5 Interfaces ........................... 7 Terminal Box........................8 System Configuration ....................10 Starting Ultrakey Lite .......................10 Login ..........................10 Mode Selection ........................11 Configurations........................11 Serial Port ........................12 Network........................14 Language........................
  • Page 4 Honeywell Fusion DVR ........................29 Keyboard Setup......................29 Operations ........................32 HRHD DVR........................34 Keyboard Setup......................34 Operations ........................34 Cascade Control ......................36 Connection........................36 Cascade Setup ......................37 PTZ Control (Direct Control)....................37 Keyboard Setup......................37 Camera Selecting ....................... 38 Operations ........................38 Web System ........................40...

  • Page 5: About This Document

    Honeywell 1 About This Document Thank you for purchasing Ultrakey Lite! This user guide is designed to be a reference tool for mounting or operating the Ultrakey Lite. Overview of Contents This document contains the following chapters: • Chapter 1, About This Document, a brief introduction of “UltraKey Lite User Guide”.
  • Page 6 • The manual has been reviewed and the accuracy is guaranteed. If there is any uncertainty or controversy, please refer to the final explanation of Honeywell. Honeywell does not take any responsibility for any consequences caused by misunderstanding of the manual or improper operations.

  • Page 7: Introduction

    Honeywell 2 Introduction Overview Ultrakey Lite is a remote control keyboard for Maxpro, VideoBloX, PTZ and DVR. It can be used in three modes: Maxpro mode, VideoBloX mode and Standalone Mode (DVR and PTZ). Ultrakey Lite is compatible with the following products: •...

  • Page 8: Specifications

    Introduction Specifications Parameter Value Power Requirements 10.8 to 13.2 VDC @ 1 Ampere (A) or POE (48VDC, Class 3) 1×Ethernet (10Base-T, 100Base-TX) RJ45 With LED Connector Types 1×RS232/422/485 RJ45 With LED Type: STN, Positive Image Backlight: Blue-White Characters: 122×32 Dots Type: A Version: USB1.1 (For USB PC Keyboard) Type: CR2032...

  • Page 9: Front Panel, Interfaces And Terminal Box

    Honeywell 3 Front Panel, Interfaces and Terminal Box This chapter provides the names and detailed information of all buttons, function keys, interfaces and terminal box on the Ultrakey Lite. Front Panel Icon Description Icon Description Alarm Iris Recycle...
  • Page 10 Front Panel, Interfaces and Terminal Box Backward Review Stop Search Forward Tour View Split Number keys Monitor Camera PTZ call Slider Slider_Left Slider_Right Focus Slider_Up Slider_Down Joystick Focus MonB MonA F1 F2 F3 F4 Login F5 F6 F7 F8 F1~F10 F9 F10 Key_Left, Key_Up, Select, Key_Down, Key_Right...

  • Page 11: Interfaces

    Honeywell Interfaces Name Description DC Power Jack supports 12V (±10%) DC/1A power input. (Apply the provided DC Power Jack power adapter. When plugging the power adapter plug, please rotate it to lock the plug.) 10/100M Ethernet (POE input) Ethernet Port Note: For using POE as the power input, it is not recommended to connect the POE network with an outside plant.

  • Page 12: Terminal Box

    Logitech Y-UR83 (Logitech Classic New Touch Keyboard 200 USB), Y-BP62a and Dell L110 Terminal Box Ultrakey Lite can be connected with other devices by using the Terminal Box. Ultrakey Lite Serial Port (RJ45) can be connected with Terminal Box’s Back (RJ45) by using a network cable.
  • Page 13 Honeywell...

  • Page 14: System Configuration

    System Configuration 4 System Configuration This chapter describes how to start, login and configure Ultrakey Lite. Starting Ultrakey Lite Connect the keyboard with a power adapter (12V (±10%) DC/1A, attached in the package) or a network cable with POE. Then the following figure displays on the LCD.

  • Page 15: Mode Selection

    Figure 4-5 Mode There are three mode options: MAXPRO, VIDEOBLOX and STANDALONE. In Standalone mode, Ultrakey Lite can control DVR and PTZ. Before the keyboard is used, the mode must be selected. Press Slider_Right to enter the Mode Selection menu.

  • Page 16: Serial Port

    System Configuration Figure 4-12 System Configuration – Language Figure 4-13 System Configuration – Back Light Figure 4-14 System Configuration – Bridge Linkage Figure 4-15 System Configuration – Slider Update Figure 4-16 System Configuration – Hardware Test Figure 4-17 System Configuration – About Serial Port Figure 4-10, press Slider_Right and the following figure is displayed.
  • Page 17 Honeywell Selecting the type Figure 4-19, press Slider_Right. There are three options of the serial port type: RS232, RS485 and RS422. Select one of them by rotate the slider and press Slider_Right. Figure 4-24 Type – RS232 Figure 4-25 Type – RS485 Figure 4-26 Type –...

  • Page 18: Network

    System Configuration Figure 4-34 Baud Rate – 9600 Figure 4-35 Baud Rate – 19200 Setting the data bit Figure 4-22, press Slider_Right. There are two options: 8 bit and 7 bit. Select the proper data bit by rotate the slider and press Slider_Right to complete the configuration. Figure 4-36 Data Bit –...
  • Page 19 Honeywell Figure 4-44 IP address menu Use the number keys to input an appropriate IP address and rotate the slider to move the cursor. When the correct IP address is entered, press Slider_Right and the following message is displayed. Figure 4-45 IP Address Changed Press Slider_Right to complete the modification.

  • Page 20: Language

    System Configuration Figure 4-51 DNS Changed Press Slider_Right to complete the modification. Language Figure 4-12, press Slider_Right to enter the language setup menu. There are two language options: English and French. Figure 4-52 Language – English Figure 4-53 Language – French Rotate the slider to select a language and then press Slider_Right to complete the configuration.

  • Page 21: Hardware Test

    Honeywell Figure 4-57 Slider Update Press Slider_Right to confirm the update. Hardware Test Hardware Test is used to test the components of the keyboard including the keyboard, the serial ports, the slider and the joystick. Press Slider_Right in Figure 4-16 to enter Hardware Test menu.

  • Page 22: Videoblox Mode

    VideoBloX Mode 5 VideoBloX Mode This chapter describes how to connect, configure and operate the Ultrakey Lite when it is used with VideoBloX. Overview Ultrakey Lite can control the remote VideoBloX via either the serial port or the Ethernet. Connection...

  • Page 23: System Configuration

    Honeywell Figure 5-2 Connecting VideoBloX by Ethernet VideoBloX * Keyboard is running VideoBlox TCP/IP keyboard Protocol * Keyboard address range should be 1 to 32 NETWORK TCP\IP TCP \IP Network cable Network cable Ethernet Port Ethernet Port Keyboard 1 Keyboard 32...

  • Page 24: Operations

    Ultrakey Lite and PCKZ-CAS keyboard. Operations When the Ultrakey Lite is powered on, it displays on the LCD the current software revision number, then its address, baud rate and finally the mode of operation which has been setup.

  • Page 25: User Function Keys

    Honeywell Select "Camera" operation mode. Select "Monitor" operation mode. Device Select "Device" operation mode. Select "Sequence" operation mode. Login Mode Enter the password on the numeric keypad, then press Ent. Correct mistakes using the “Clr” Key. The system is in “Camera” mode by default.

  • Page 26: Maxpro Mode

    Maxpro Mode 6 Maxpro Mode This chapter describes how to connect, configure and operate the Ultrakey Lite when it is used with Maxpro-Net. Connection Ultrakey Lite can control the remote Maxpro via either the serial port or the Ethernet. To connect Ultrakey Lite with Maxpro by the serial port, refer to the following figures, normally, you can select RS232 by menu to connect with Maxpro directly.
  • Page 27 2- TXD, 3- TXD, 5- GND RS422( COM1) RS232( COM2) RS232( COM2) RJ45 Terminal Box Network cable Serial Port(RS422) Ultrakey Lite To connect Ultrakey Lite with Maxpro by Ethernet, refer to the following figure: Figure 6-3 Connecting Maxpro by Ethernet...

  • Page 28: System Configuration

    Maxpro Mode System Configuration Refer to “Mode Selection” on page to set the mode as Maxpro. Figure 4-6, press Ent and the following figure is displayed. Figure 6-4 Loading Maxpro If the keyboard connects the Maxpro server with Ethernet unsuccessfully, the offline menu displays: Figure 6-5 Maxpro Offline If the Maxpro server sends messages to keyboard, the keyboards will display the messages in...

  • Page 29: Setting The Keyboard Baud Rate

    Honeywell When the keyboard ID menu shows on the LCD screen, rotate the slider to select the keyboard address, then press Slider_Right to confirm the selection. Figure 6-13 keyboard ID Setting the Keyboard Baud Rate Figure 4-10, press Slider_Right and the following figure is displayed.

  • Page 30: Setting Maxpro Serial Port Mode

    Figure 6-20 Maxpro Serial Port Mode – 1 Figure 6-21 Maxpro Serial Port Mode – 2 When all above has been set, press Alt followed by Clr to exit the setup menu. Maxpro Key Code Maxpro Ultrakey Lite Maxpro Ultrakey Lite Maxpro Ultrakey Lite...
  • Page 31 Honeywell counter-clockwise View ● Forward Search backward...

  • Page 32: Standalone Mode

    Standalone Mode 7 Standalone Mode This chapter describes connection and configuration instructions of UltraKey Lite in Standalone mode. Standalone Mode Setup The Standalone Mode is used to control DVR and PTZ. Refer to “Mode Selection” on page to set the mode as STANDALONE.

  • Page 33: Fusion Dvr

    Network cable Serial Port Ultrakey Lite Fusion DVR Keyboard Setup Before using the Ultrakey Lite keyboard Fusion DVR function, it must be set-up to meet the systems requirements. Set COM2 according to the table below: Type RS232 Baud Rate 9600...
  • Page 34 Standalone Mode DVR Type Press Select to enter the DVR Settings menu. Figure 7-4 DVR TYPE Press Slider_Right and rotate the slider, the following figure is displayed. Figure 7-5 DVR Selection Then press Slider_Right to select the DVR type as FUSION. DVR and Camera Connection Press Slider_Right to enter the Basic Set menu.
  • Page 35 Honeywell 4 way DVR (DVR 1) 4 way DVR (DVR 2) 16 way DVR (DVR 3) 9 way DVR (DVR 4) PTZ Mode Figure 7-6, press Slider_Down to enter the following menu. Figure 7-8 PTZ Control Press Slider_Right to enter the following menu.

  • Page 36: Operations

    Standalone Mode Figure 7-10 DVR Control Rotate the slider to select the needed user type, and then press Slider_Right to confirm. Refer to Figure 7-3 for connecting PTZ by direct control. Note Refer to Figure 7-2 for connecting PTZ by DVR control. Operations DVR selection Pressing a number followed by the DVR key selects a DVR to control.
  • Page 37 Honeywell Full screen The function can toggle Full Screen on specified channel. Press number key, and Camera. Then press Ent. Reverse play The function can make DVR play backwards in search. Press Backward to play backwards in search. Stop function The function can make DVR halt play movement.

  • Page 38: Hrhd Dvr

    Standalone Mode HRHD DVR Keyboard Setup The HRHD DVR function setup is just like the FUSION DVR function setup except that the HRHD type must be selected. Operations DVR selection Pressing a number followed by the DVR key selects a DVR to control. Number entry (for entering passwords) To enter numbers, press and hold the Alt key and then press the number keys.
  • Page 39 Honeywell Press Seq to put the DVR output into a sequence (the sequence depends on the current display mode and set-up). If the key is pressed again, the sequence stops (displaying the current step in the sequence). Press F10 to freeze the current display. Press the key again to return to the ‘live’ picture(s).

  • Page 40: Cascade Control

    Standalone Mode Fast Forward The function can make DVR playback fast. User can directly press Forward to realize this function. Rewind The function can make DVR rewind fast. User can directly press Backward to realize this function. Zoom Press Set to zoom the picture on the screen. PTZ control The function can let HJC5000 to control PTZ of HRXD.

  • Page 41: Cascade Setup

    PTZ Control (Direct Control) Keyboard Setup For connecting of Ultrakey Lite and PTZ, refer to Figure 7-3. Certain settings should be done to use the direct control of PTZ with Ultrakey Lite. • Set COM1 (in Figure 4-10) according to the table below:...

  • Page 42: Camera Selecting

    Standalone Mode Type RS485 Baud Rate 1200, 9600, 19200 and so on Parity None/even/odd Data 7/8 bit Stop 1/2 bit • In Standalone main menu (in Figure 7-1), press Select, and rotate the slider to enter “PTZ” Settings or Press PTZ. You can set PTZ Name, Address and Protocol. Figure 7-15 PTZ set Camera Selecting After keyboard setup and return to standalone main menu.
  • Page 43 Honeywell Figure 7-17 PTZ – Tour Figure 7-18 PTZ – Preshot Menu Figure 7-19 PTZ – Sector Menu Figure 7-20 PTZ – Main Menu Figure 7-21 PTZ – List Preshot Figure 7-22 PTZ – List Vector Figure 7-23 PTZ – List Sector Figure 7-24 PTZ –...

  • Page 44: Web System

    Internet Explorer. Login Input the IP address of Ultrakey Lite in the address bar and the following interface is displayed: Figure 8-1 Honeywell Video System Main Page Enter user name and password (default user name and password: admin/ultralite) and click Login.

  • Page 45: Configuration

    Figure 8-3 System Configurations System Mode – select one mode among Standalone, VideoBloX and Maxpro. System Language – select the menu language of Ultrakey Lite. Background Light – disable or adjust the background light brightness of the LCD: Off, Low, Middle and High.

  • Page 46: Maxpro Configuration

    Web System • Type – select one DVR type to be used. • User – set the DVR as master or slave. • Channel allocation – click Display to view channels of all the DVRs and Cameras, as shown in Figure 8-5.

  • Page 47: Videoblox Configuration

    Honeywell Figure 8-6 Maxpro Configuration Keyboard ID Setting – set the ID of the keyboard (range: 1~99). Maxpro Device Network Setting – set the IP address and port number of the Maxpro device. Serial Port Setting – set the baud rate and connection mode of the serial port.

  • Page 48: Serial Port Configuration

    Web System Serial Port Configuration Click Serial Port Configuration in the left pane and the following figure is displayed: Figure 8-8 Serial Port Configuration Serial Port1 Settings • Baud Rate – select the proper baud rate of for the serial port. •...

  • Page 49: Upgrade

    Honeywell Enter IP address, subnet mask, gateway and DNS. Click Apply to save the configuration; Cancel to give up the configuration; Default to restore all default values. Upgrade To upgrade the firmware of the keyboard, click the UPGRADE tab and the following figure is...

  • Page 50: System Reboot

    Web System Figure 8-12 Upgrade status (Copying new files) The following figure displays when the upgrade is completed successively, and then the system will reboot. Figure 8-13 Upgrade status (Upgrade success) System Reboot In the SYSTEMREBOOT tab, the operator can reboot the keyboard from network. Figure 8-14 System Reboot Click Reboot to restart the keyboard.

  • Page 51: Change Password

    Honeywell Change Password To change the password of the current user, click Change Password at the top right corner and the following figure is displayed: Figure 8-15 Change Password Enter the current password, the new password and confirm it. Click Apply to set the new...

  • Page 52: Appendix 1: Pckz-Cas Keyboard Map

    The following table shows the key value map between Ultrakey Lite and PCKZ-CAS keyboard. As the Ultrakey Lite include all the functions the PCKZ-CAS keyboard has, pressing the certain key on the Ultrakey Lite will have the same effect as pressing the corresponding key on the PCKZ-CAS keyboard.

  • Page 53: Appendix 2: Usb Keyboard Map

    Honeywell 10 Appendix 2: USB Keyboard Map The general USB keyboard is supported. USB keyboard Ultrakey Lite F1~F10 F1~F10 LOGIN Setup Left Left Right Right Down Down A~Z (it is not case sensitive) The keys, which are not listed in the table, are not used.
  • Page 54 +1.800.796.CCTV (North America only) HVSsupport@honeywell.com © 2008 Honeywell International Inc. All rights reserved. No part of this publication may be reproduced by any means without written permission from Honeywell Video Systems. The information in this publication is believed to be accurate in all respects.
