Mindray BeneVision N22 Service Manual page 88

ITEM NO. Description
9 Display interface board PCBA (FRU)
10 Alarm LED board interconnection line
Speaker bracket
11 Speaker
Speaker pad
12 D19 rear housing
Display rear housing cover assembly
13
Cable management cover (silkscreen)
14 Encoder assmebly
15 Handle assembly (without an encoder)
Long side handle cover
16 Display USB cover (overmold)
Short side handle cover (D19)
17 Key seat
18 Switch keypad board PCBA
19 Switch key assembly
20 USB interface board interconnection line
Display interface board and keypad board
21
interconnection line
Display interface board and indicator & light sensor
22
board line
23 USB interface board PCBA
24 Indicator and light intensity sensor board PCBA
25 Indicator light lamp shade
26 D19 ornamental belt(FRU)
7-4
Qty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
BeneVision N22/BeneVision N19 Patient Monitor Service Manual
FRU part number
115-044999-00
009-005109-00
115-037489-00
043-005820-02
043-006465-01
043-008962-00
115-050303-00
115-033716-00
115-035457-00
043-006119-00
051-001920-00
049-001031-00
009-005106-00
009-005104-00
009-005124-00
051-001933-01
051-001918-00
049-000872-00
115-045003-00
