Installation Instructions
Mounting adapter A
1
Mounting holes for the frequency converter. Use the
screws supplied with the adapter plate.
2
Mounting holes for the adapter plate. Use the
screws from the VLT
3
Front view
Illustration 1.1 Dimensions for Mounting Adapter A, Units in mm [in]
2
Mounting Adapter to VLT
®
VLT
Midi Drive FC 280
®
2800.
Danfoss A/S © 02/2016 All rights reserved.
®
2800
4
Side view
5
Back view
MI07F102
